Linear Logic scangauge2 Quick Start Manual page 6

4) Calibrating Your ScanGauge
The accuracy of your ScanGauge can be improved
by calibrating the fuel consumption. Calibrating your
ScanGauge to accurately report fuel consumption is a
2-step process; Your First Fill-Up, Your Second Fill-Up.
For more detail information about calibrating your fuel
consumption as well as how to calibrate your ScanGauge
to your vehicle's speed, please refer to the ScanGauge
User Manual or go online to www.scangauge.com/support.
Step 1 - Your First Fill-up
1) Fill up the tank, letting the pump shut off
automatically.
2) Use the FILLUP function to tell ScanGauge
you have filled the tank. From the Home
Screen, follow the sequence shown to the
right.
3) On your first fill-up, DO NOT make any
adjustments to the indicated fuel. Simply
press the lower right button to move to
the next screen.
4) Next, the Fuel Cost Screen will appear. Use
the upper left and right function buttons to
adjust the cost per gallon/liter, and press the
lower right function button next to SAVE.
5) Keep the ScanGauge connected to your
vehicle and use the vehicle normally.
6) Once you reach approximately 1/4 tank of
fuel left, follow the directions in Step 2.
After following the initial calibration
procedure, you should follow Step 2
for each subsequent fill up.
If you miss a full up procedure after
filling your tank, start with Step 1 of
the calibration process on your next
fill up to maintain accuracy .
Home Screen
<SCAN
<TRIP
<DISPLAY FILLUP>
<SETUP
< 0.1 GALLONS
0.0%
< $3.00
Fuel Cost
Once you have set the fuel
cost, press SAVE
GAUGE>
MORE>
MORE>
>
DONE>
>
SAVE>
