SHINPO
OPERATION MANUAL
Thank you for purchasing SHINPO Smokeless Roaster.
● Before operating this product, please read and understand the instructions
contained in this manual.
● Keep this manual in a place where it can be reached for immediate references.
● If necessary, please contact your distributor from whom you have purchased the
product or us for clarification and/or further instructions.
Parts & Accessories
SMOKELESS ROASTER
ＳＰＲＷ
CONTENT
１
２
３
７
９
11
14
15
16
Advertisement
Table of Contents
Related Manuals for SHINPO SPRW
Summary of Contents for SHINPO SPRW
-
Page 1: Table Of Contents
SMOKELESS ROASTER ＳＰＲＷ OPERATION MANUAL Thank you for purchasing SHINPO Smokeless Roaster. ● Before operating this product, please read and understand the instructions contained in this manual. ● Keep this manual in a place where it can be reached for immediate references. -
Page 2: Parts Identification Main Unit
SPRW_ENGLISH _101 Rating Label Parts Identification-Main Unit LPG Model Label Natural Gas Model Model SPRW SPRW Gas Type NT Gas ＬＰG Power Table Top 220V 220V Source OOOOOO OOOOOO ID No. Cabinet Burner Control Knob Slim Control... -
Page 3: Parts Identification
SPRW_ENGLISH _101 Parts Identification-Parts & Accessories ＜The following four items are not included in Top Ring SPRW, may be purchased separately＞ 「Optional Parts」 Radiant Plate Grill Plate Gripper Radiant Plate Stand Grill Plate Drain Pan Drain Pan Gripper Burner Head... -
Page 4: Safety Precautions
Safety Precauti ons Safety Precautions We are providing these instructions with illustrations for clarity and easy understanding in order to avoid any harm to the users or damage to the properties. Insure proper installation and servicing. Have the product installed and grounded by a qualified technician. Please make sure to understand fully the meaning of each illustration before you proceed further. - Page 5 Safety Precauti ons W A R N I N G P ow er S ource ▽D o not use other than the pow er source speci fi ed for thi s product. ▼Fai l ure to observe thi s m ay resul t i n a ri sk of f i re or expl osi on. ...
- Page 6 Safety Precauti ons W A R N I N G Em ergenci es ▽ I f you sense an abnorm alcom busti on,odor or sound,i m m edi atel y stop the use, shut off the gas m ai n of the uni t and refer to the “...
- Page 7 Safety Precauti ons W A R N I N G D i sassem bl i ng ▽ D o not di sassem bl e thi s roaster,rem ovabl e parts excepted. (See P . 2 for the l i st of rem ovabl e parts) ▼...
-
Page 8: Preparation Before Use
SPRW_ENGLISH _101 Preparation before use ◆ Setting up parts (Refer to P.1,2) 1. Place the Filter Set on the bottom of the Outer Casing. 2. Mount the Inner Casing onto the Outer Casing. 3. Mount the Burner Body onto the Inner Casing. Note: ▼... - Page 9 SPRW_ENGLISH _101 6. Pour water into the Drain Pan ▼ Appropriate amount is approx 1 liter. ▼ Do not splash water on the Burner. ▼ If water accidentally splashes on the holes of the Burner, remove the Burner and wipe it dry with a piece of cloth.
-
Page 10: Operation Instructions
SPRW_ENGLISH _101 Operating Instructions(Slim Control Type) Before you turn on the power and open the Gas Shutoff, make sure the Burner Control Knob is at Off position and that every direction in the “Preparation before use” section of this manual has been precisely followed. Also make sure that the Exhaust Fan is operating normally. - Page 11 SPRW_ENGLISH _101 ◆ Extinguishing Fire ① Slowly slide the Burner Control Knob to OFF position to turn off the burner. ② Make sure the Burner Control Knob is at OFF position ③ Make sure the Burner is off. Close the Gas Shutoff Cock and turn off the power. ▼...
-
Page 12: Daily Inspections & Maintenance
SPRW_ENGLISH _101 Daily Inspections & Maintenance ▼ For safe operation of this product, make sure to carry out daily inspections and maintenance. ▼ Make sure to close the Gas Shutoff Cock , turn off the power, check the Exhaust Fan is not operating and allow the appliance to cool down before you attempt any inspections or maintenance work. - Page 13 SPRW_ENGLISH _101 ＜Burner Inspection＞ Install the Burner correctly and check the burner flames by comparing to the drawings below. If necessary, adjust the Damper attached to the Gas Intake of the Burner. ※Be extremely careful not to burn yourself or your clothes. Make sure the Burner and other parts have cooled down to a safe level before you touch them.
- Page 14 SPRW_ENGLISH _101 ＜Burner Maintenance＞ Clogged Burner Holes (with water, grease, ashes) often causes the Burner to rust shortening the operational life span of the Burner. It also causes gas to flow backward, which may result in a risk of fire or explosions.
-
Page 15: Troubleshooting
SPRW_ENGLISH _101 Troubleshooting Trouble Solution Cause Position the Burner Control Knob to ○ ○ ○ ○ ９ Gas Shutoff Cock is closed Off. Open the Gas Shutoff Cock. Follow the directions described in ○ ○ ○ ９ Air is present in the gas pipe this manual. -
Page 16: Safety Features
SPRW_ENGLISH _101 Safety Features ▽ Misfiring Detector Prevents gas being discharged when the burner is not lit. ▼ When fire goes out for any reasons, this devise detects it and shuts off the supply of gas to the Burner, preventing gas being discharged into the air. ▽... -
Page 17: Specifications
SPRW_ENGLISH _101 Specifications Model SPRW Radiant Plate Roaster Product Natural Gas:3.26kw LPG：3.14kw Consumption Gas Connection R1/2 Screw Connection Power Less than 5W Consumption 220V Power Source （ ）V Ignition Method Spark Discharge Ignition Safety Feature Overheating Detector/Misfiring Detector Articles of consumption... - Page 18 Memo...
- Page 19 Memo...
- Page 20 ＳＨＩＮＰＯ ＣＯ.，ＬＴＤ． ＯＶＥＲＳＥＡＳ ＤＥＰＡＲＴＭＥＮＴ ２－３０－２ ＭＩＴＳＵＩ ＳＵＭＩＴＯＭＯ ＫＡＩＪＯ ＯＨＪＩ ＢＬＤＧ.，８/Ｆ.，ＯＨＪＩ，ＫＩＴＡ-ＫＵ，ＴＯＫＹＯ １１４－０００２，ＪＡＰＡＮ TEL：８１-３-５９５９-６７６１／FAX：８１-３-５９５９-６８３０ ＨＥＡＤ ＱＵＡＲＴＥＲＳ １１０ ＷＡＫＡＢＡＤＡＩ，ＭＥＩＴＯＫＵ，ＮＡＧＯＹＡ ４６５－００１５，ＪＡＰＡＮ TEL：８１-５２-７７６２２３１／FAX：８１５２７７６２２６３ ＮＡＧＯＹＡ ＦＡＣＴＯＲＹ ３－１ ＴＯＩＡＧＥ，ＦＵＫＵＤＡ-ＣＨＯ, ＭＩＹＯＳＨＩ-ＳＨＩ，ＡＩＣＨＩ ４７０－０２２５，ＪＡＰＡＮ TEL：０５６１３-２-３２２１／FAX：０５６１３-２-３１７７ Ｔｅｃｈｎｏｌｏｇｙ＆Ｄｅｖｅｌｏｐｍｅｎｔ Ｄｅｐｔ． ３－１ ＴＯＩＡＧＥ，ＦＵＫＵＤＡ-ＣＨＯ, ＭＩＹＯＳＨＩ-ＳＨＩ，ＡＩＣＨＩ ４７０－０２２５，ＪＡＰＡＮ TEL：０５６１３-２-３２６７／FAX：０５６１３-２-９５８０ SALES AGENT・DISTRIBUTOR 2011.07.11...
