  • Page 1 IP24GESP 24 Port PoE Ethernet Switch User Manual...
  • Page 2 CONTENTS PAGE (IF IT IS A LARGE MANUAL)

  • Page 3: Key Features

    1. Introduction The IP24GESP 24 ports managed modular Gigabit Ethernet switch, which provides 24x Gigabit downlink Ethernet ports or optical fiber ports, 2x Gigabit uplink optical fiber ports and 2x Gigabit uplink Ethernet ports. Downlink ports support Ethernet or optical fiber ports optional (8 Ethernet & 8 SFP pluggable moules).

  • Page 4: Technical Specification

    -40℃ ~ 85℃ Humidity (Non-Condensing) 0 ~ 95% Dimension (L x W x H) 442 x 315 x 44 mm Weight 4. 35 Kg *Design and Specifications are subject to change without notice. IP24GESP - 24 Port PoE Ethernet Switch...

  • Page 5: Shipping List

    Interface cables should be arranged indoor rather than outdoor to prevent over-voltage or over-current damage to the signal port. Types of Installation There are 3 ways to install the switch: • Rack installation • Workbench installation • Wall installation IP24GESP - 24 Port PoE Ethernet Switch...

  • Page 6: Rack Installation

    2. Remove the stickers on the foot pad, paste the foot pad in backplane groove. 3. Carefully put the device upright on the workbench. IP24GESP - 24 Port PoE Ethernet Switch...

  • Page 7: Cable Connection

    1. Connect one side of switch’s power cable with the switch’s AC power port, and connect the another side with external AC power socket 2. Turn on the power, check if the switch’s AC power LED is on which means power is connected correctly. Figure 6: Connect power cable IP24GESP - 24 Port PoE Ethernet Switch...

  • Page 8: Function Configuration Guide

    4. This product can’t assign the IP address for the management PC, you need to set the management static IP by yourself. Set Static IP for the Management Computer IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 9 3. Function Configuration Guide IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 10 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 11 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 12 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 13 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 14 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 15 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 16 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 17 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 18 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 19 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 20 IP24GESP - 24 Port PoE Ethernet Switch...
  • Page 21 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-February 2015...
