OWNER'S MANUAL
LG Digital
Signage
(MONITOR SIGNAGE)
Please read this manual carefully before operating your set and retain it
for future reference.
65EE5PC
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 65EE5PC and is the answer not in the manual?

Questions and answers

Related Manuals for LG 65EE5PC

Summary of Contents for LG 65EE5PC

  • Page 1 OWNER’S MANUAL LG Digital Signage (MONITOR SIGNAGE) Please read this manual carefully before operating your set and retain it for future reference. 65EE5PC www.lg.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS ....3 - Precautions In Installing the Product .....3 - Precautions to the AC Adapter and Electrical Power ..................5 - Precautions In Moving the Product ......7 - Precautions In Using the Product ......8 - Precautions When Cleaning the Product ..10 - Precautions When Experiencing Image Sticking ................10 - Precautions When Using the Remote...

  • Page 3: Safety Precautions

    WARNING - This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. SAFETY PRECAUTIONS Please read these safety precautions carefully before using the product. WARNING If you ignore the warning message, you may be seriously injured or there is a possibility of accident or death.
  • Page 4 • Do not leave the power or signal cable, etc. in walkways. - If you step on or fall over the cable, it may cause fire, electric shock, product damage or personal injury. • Do not use the product in a damp place such as a bathroom where it is likely to get wet. - This may cause fire, electric shock or product malfunction.

  • Page 5: Precautions To The Ac Adapter And Electrical Power

    Also, avoid touching the power plug immediately after pulling it out of the wall outlet. - This may cause electric shock. • Be sure to use power cords and AC adapters provided or approved by LG Electronics, Inc. - The use of non-approved products may cause fire or electric shock. •...
  • Page 6 • When unplugging the power cord, always pull it by the plug. Do not bend the power cord with excessive force. - A damaged cable may result in electric shock or fire. • Be careful not to step on or place heavy objects (electronic appliances, clothing, etc.) on the power cord or AC adapter.

  • Page 7: Precautions In Moving The Product

    Precautions In Moving the Product WARNING Failure to observe these instructions may result in serious injury or death. • Before moving the product, disconnect the power cord and all other cables connected. - Otherwise, this may result in electric shock or product damage. •...

  • Page 8: Precautions In Using The Product

    Precautions In Using the Product WARNING Failure to observe these instructions may result in serious injury or death. • Do not disassemble, repair or modify the product by yourself. - Otherwise, the product may cause fire or electric shock. If the product needs to be checked, reset or repaired, contact the customer service center.
  • Page 9 CAUTION Failure to observe these instructions may result in minor injury or damage to the product. • Do not use or store the product near inflammables. - This may result in fire or explosion. • Take a break to protect your health and vision when using the product for long periods of time. •...

  • Page 10: Precautions When Cleaning The Product

    Precautions When Cleaning the Product WARNING Failure to observe these instructions may result in serious injury or death. • Do not spray water directly onto the product and do not use inflammable materials such as thinner or benzene to wipe the product. - Attempting repair or modification yourself may cause a fire hazard or result in electric shock.

  • Page 11: Precautions When Using The Remote Control

    Precautions When Using the Remote Control CAUTION Failure to observe these instructions may result in minor injury or damage to the product. • Remove any obstacles. • The remote control may not function properly in sunlight or under a strong lamp. Move the product if it is being used in these conditions.

  • Page 12: Assembly And Preparation

    • SuperSign Software & Manual - Downloading from the LG Electronics website. - Visit the LG Electronics website (www.lgecommercial.com/supersign) and download the latest software for your model. • The warranty will not cover any damage caused by using the product in an excessively dusty environment.

  • Page 13: Remote Control

    REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully to use the monitor correctly. To install batteries, open the battery cover, place batteries (1.5 V AAA) matching terminals to the labels inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse.
  • Page 14 PSM Selects the Picture Mode. HOME Activates the Launcher. W.BAL Enters the White Balance menu. SETTINGS Accesses the main menus or saves your input and exit menus. S.MENU SuperSign menu key. Navigation Buttons Scrolls through menus or options. OK Selects menus or options and confirms your input. BACK Allows you to move back one step in the user interaction function.

  • Page 15: Making Connections

    MAKING CONNECTIONS You can connect various external devices to your monitor. Change the input mode and select the external device you want to connect. For more information about external device connections, see the user manual provided with each device. Connecting to a PC Some of the cables are not provided.
  • Page 16 NOTE • The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. • For the best image quality, using the monitor with HDMI connection is recommended. •...

  • Page 17: Using The Input List

    Using the Input List HOME → • HDMI → DISPLAYPORT NOTE • DISPLAYPORT is applied to the set’s internal connections.

  • Page 18: Troubleshooting

    TROUBLESHOOTING No image is displayed. Problem Action Is the product power cord connected? • Check if the power cord is correctly plugged into the power outlet. Does the “Invalid Format” message • The signal from the PC (Graphics card) is out of the vertical or appear? horizontal frequency range of the product.
  • Page 19 Screen color is abnormal. Problem Action Screen has poor color resolution (16 • Set the number of colors to more than 24 bits (true color). Select colors). [Control Panel] → [Display] → [Settings] → [Color Table] in Windows. (The settings may differ depending on your operating system.) Screen color is unstable or mono-colored.
  • Page 20 CAUTION • Image sticking may occur when displaying a fixed image for an extended period of time. It is recommended that you display videos for 12 hours or less per day to decrease the likelihood of image sticking. • A few horizontal lines may appear on the screens while running the Clear Panel Noise feature (OFF-RS). This is normal, so there is no need for concern.

  • Page 21: Product Specifications

    PRODUCT SPECIFICATIONS The product specifications below may be changed without prior notice due to upgrade of product functions. “ ” refers to alternating current (AC), and “ ” refers to direct current (DC). OLED screen Screen type Thin Film Transistor (TFT) OLED Screen Video signal Maximum resolution...
  • Page 22 65EE5PC OLED screen Pixel pitch 0.372 mm (H) x 0.372 mm (V) Power 1 x 1 Rated power AC 100-240 V ~ 50/60 Hz (One sides) Power On Mode: 230 W (Typ.) consumption Sleep Mode (DisplayPort, HDMI): ≤ 3 W Off Mode: ≤...
  • Page 23 HDMI/ DisplayPort (PC) Support Mode Resolution Horizontal frequency (kHz) Vertical frequency (Hz) Remark 800 x 600 37.879 60.317 1024 x 768 48.363 60.0 1280 x 720 44.772 59.855 1366 x 768 47.712 1280 x 1024 63.981 60.02 1920 x 1080 67.5 3840 x 2160 67.5...
  • Page 24 NOTE • PC resolutions available for the Input Label option in HDMI input modes: 640 x 480/60 Hz, 1280 x 720/60 Hz, 1920 x 1080/60 Hz; 480p, 720p, and 1080p DTV resolutions. • Vertical frequency: The product display functions by the screen image changing dozens of times every second like a fluorescent lamp.
  • Page 25 Make sure to read the Safety Precautions before using the product. The model and serial numbers of the SET are located on the back and one side of the SET. Record it below should you ever need service. Temporary noise is normal when powering ON or OFF MODEL this device.
