- Page 1 USER MANUAL MODEL 3004 MTE Series Miniature Self-Powered Tail End Adapters SALES OFFICE Part# 07M3004MTE-A Doc# 011051UA (301)975-1000 Revised 08/22/00 TECHNICAL SUPPORT (301)975-1007 An ISO-9001 http://www.patton.com Certified Company...
-
Page 2: Warranty Information
However, there is no guarantee that interference will not occur in a particular installation. If the Model 3004- MTE does cause interference to radio or television reception, which... -
Page 3: General Information
DCEs in a "tail circuit" configuration. A tail circuit adapter is required to couple two DCE devices whose clocks are of the same frequency but are not in phase. The Model 3004-MTE utilizes a single auto-centering buffer to prevent data errors caused by clock jitter and clock phase differences. -
Page 4: Operation
(terminal timing) of the tail device. Data from the tail circuit is loaded into the 3004-MTE buffer using the receive clock of the tail device. Data is transferred from the 3004-MTE buffer to the system using the system transmit clock. -
Page 5: Technical Specifications
Tail circuit, DCE to DCE Wiring: Internal "cross-over" wiring Transmission format::Synchronous, transparent to protocol Data rate: Up to 2.304 Mbps Functional interface: 3004-MTE/V.35- CCITT V.35 3004-MTE/530- EIA/RS-530 3004-MTE/V.36- EIA/RS-449 Electrical/Physical Interface: 3004-MTE/V.35- V.35 compatible. Male or female 34-pin V.35 connectors on 6 foot cables 3004-MTE/530- RS-422/V.11 compatible. -
Page 6: Interface Pin Assignment
APPENDIX C PATTON ELECTRONICS MODEL 3004-MTE/530 INTERFACE PIN ASSIGNMENT RS-530 Interface Pin Description (DB-25 Connector) Pin # Signal FG (Frame Ground) TD (Transmit Data-A) RD (Receive Data-A) RTS (Request to Send-A) CTS (Clear to Send-A) DSR (Data Set Ready-A) SGND (Signal Ground)
