User Manual
Electric Ovens
AUPL-F65SS
AUPL-M609SS
AUPL-FP65BK
IMPORTANT
Please ensure that you read through this manual prior to installation and use. This user
manual contains important information to ensure optimal performance and keep you safe.
Please retain your proof of purchase, as this will be needed in the event that you require a
warranty service. Remember to keep this user manual for future reference.
| platinumappliances.com.au
TM
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Platinum AUPL-F65SS
Summary of Contents for Platinum AUPL-F65SS
-
Page 1: Electric Ovens
User Manual Electric Ovens AUPL-F65SS AUPL-M609SS AUPL-FP65BK IMPORTANT Please ensure that you read through this manual prior to installation and use. This user manual contains important information to ensure optimal performance and keep you safe. Please retain your proof of purchase, as this will be needed in the event that you require a warranty service. -
Page 2: Table Of Contents
Contents Contents Warning & Safety Instructions 3 - 4 Product Specifications Product Overview Operating Instructions 7 - 10 Maintenance 11 - 12 Installation 13 - 15 Contact Details Page 2 Electric Oven User Manual... -
Page 3: Warning & Safety Instructions
Warning & Safety Instructions IMPORTANT // To ensure best performance, avoid risk of damage or accidents. Please read the operating instructions prior to first time use. To maintain the efficiency and safety of this WARNING // Accessible parts may become appliance, we recommend that you do the hot when the grill is in use. -
Page 4: Warning & Safety Instructions
Warning & Safety Instructions Avoid the following: the entire assembly. Only use temperature probes recommended for this oven. • Touching the appliance with wet parts of • If in doubt about the soundness of the the body. appliance after removing it from its •... - Page 5 Model: AUPL-F65SS & AUPL-FP65BK (5 Function Electric Oven) Dimensions W595 x D575 x H595mm Voltage / Frequency 220-240V~ / 50Hz Power 2100W Capacity 70L (Gross) Model: AUPL-M609SS (9 Function Electric Oven) Dimensions W595 x D575 x H595mm Voltage / Frequency...
-
Page 6: Product Overview
Product Overview Control Panel Model: AUPL-F65SS & AUPL-FP65BK 1. Function Selector 2. Manual Timer 3. Thermostat Control Panel Model: AUPL-M609SS Remind Start Timer LED Display Pause/Stop 1. Remind Button 5. Knob 1 (“K1”) – Functions & Settings selection 2. Time Button 6. -
Page 7: Operating Instructions
Operating Instructions IMPORTANT // recommended that you select the Natural Convection function and set it to work at its highest temperature (250ºC) for half an hour without anything inside the oven and with its door shut. At the end of this process, open the oven door and leave it open for a few minutes to allow fresh air to circulate inside the oven. - Page 8 Operating Instructions 2. Selecting The Cooking Function Note: 5F = 5 Function / 9F = 9 Function Oven Model) Note: Default temperatures presented on this table does not apply to the 5 Function oven models Function Description LIGHT - The light function enables the user to observe the progress of cooking without opening the door.
-
Page 9: Setting The Timer
NOTE // The default temperature of the function 3. Setting The Timer selected is displayed prior to any temperature adjustments. Model: AUPL-F65SS & AUPL-FP65BK 3. Press “ ” to start cooking. The This model is equipped with a mechanical corresponding function symbol and set temperature should be displayed. - Page 10 “ ” will be displayed. Model: AUPL-F65SS & AUPL-FP65BK To unlock the oven functions, press “ ” and Simply turn the Manual Timer knob clockwise “ ” simultaneously for 3 seconds. You will until you reach the desired time.
-
Page 11: Maintenance
Maintenance ATTENTION // Before cleaning your oven, or performing maintenance, turn the appliance off and disconnect it from the power supply. Cleaning your oven frequently will extend its life. with aluminium foil as the consequent When cleaning your oven: accumulation of heat could compromise the cooking and even damage the enamel. -
Page 12: Maintenance
Maintenance 3. Grip the door on its sides, as shown on the image below, and start to shut it slowly until the levers (doorstops) engage in the slots of the oven door (B). Do not try to close the door completely as it could damage the doorstops. -
Page 13: Installation
Installation IMPORTANT // This appliance must be NOTE // When connecting the cable directly to the mains, install an omnipolar circuit breaker accordance with the instructions presented with a minimum contact gap of 3mm, which in this manual. The manufacturer will not be should be sized according to the load and held responsible for any damage caused by should comply with current regulations (the... - Page 14 In particular, be assembled with adhesives suitable for temperatures of up to 120ºC. of the appliance and cabinet cut-out for installation of the built-in oven. AUPL-FP65BK AUPL-F65SS & AUPL-M609SS FASCIA DIMENSIONS FASCIA DIMENSIONS Page 14 Electric Oven User Manual...
-
Page 15: Installation
Installation (ventilation gap) OVERALL DIMENSIONS CUT-OUT DIMENSIONS the oven to the side walls of the housing unit through the holes in the over trim as indicated in the image below. NOTE // Removable silicone covers are placed on top of the screw heads. Electric Oven User Manual Page 15... -
Page 16: Contact Details
NSW 1755 1300 985 815 customercare@platinumappliances.com.au platinumappliances.com.au Platinum is committed to ongoing research and development. Every e to ensure all information in this user manual is correct at time of going to print. Dimensions should be used as reference only and actual dimensions should be taken form the phyical product only.
