BUILT-IN OVEN
GL 662 Gas
USER S GUIDE

Advertisement

Table of Contents
loading

Related Manuals for Glen GL 662 Gas

Summary of Contents for Glen GL 662 Gas

  • Page 1 BUILT-IN OVEN GL 662 Gas USER S GUIDE...

  • Page 2: Table Of Contents

    Thank you for choosing our product. We advise you to read this manual carefully. It contains all necessary instructions for maintaining unaltered the appearance and functional qualities of the appliance. Table of Contents 1. PRECAUTIONS FOR USE 2. DISPOSAL INSTRUCTIONS-OUR ENVIRONMENT POLICY 3.

  • Page 3: Precautions For Use

    Precautions for Use 1. PRECAUTIONS FOR USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE. TAKE GOOD CARE OF IT AND KEEP I T TO HAND THROUGHOUT THE OVEN'S LIFE CYCLE. WE URGE YOU TO READ THIS MANUAL AND ALL THE INFORMATION IT CONTAINS CAREFULLY BEFORE USING THE APPLIANCE.

  • Page 4: Safety Precautions

    Important: deliver the appliance to your local organization authorized to collect scrapped appliances. Proper disposal allows the intelligent recovery of valuable materials. Before scrapping your appliance it is important to remove doors and leave shelves in position as for use, to ensure that children cannot accidentally become trapped inside the oven during play.
  • Page 5 If a permanent connection is used, the appliance's power supply line must be fitted with an omni polar breaking device with contact gap of at least 3 mm, located in an easily accessible position close to the appliance itself. If a socket and plug connection is used, check that they are of the same type. Do not use reducers, adapters or junctions since they may cause overheating or burns.
  • Page 6 Never use the door for leverage when inserting the oven in the cabinet. Never apply excessive pressure to the open door. 4.3 Room ventilation The appliance may only be installed in a permanently ventilated room as specified by the relevant regulations. The air flow into the room where the appliance is installed must be sufficient for proper gas combustion and room ventilation.

  • Page 7: Adapting To Different Types Of Gas

    4.4 Combustion gas discharge Combustion gases must be discharged by means of hoods connected to a flue with reliable natural draught, or a fan extraction system. An effective extraction system requires careful design by an authorized specialist, and must comply with the regulation distances and positions. After installation, the engineer must issue a certificate of compliance.
  • Page 8 natural gas you should turn one of a circle while 1/8 circle for LPG. When using bottled gas, the adjuster screw must be turned fully clockwise. The diameter of the by-pass is stated in point“5.2 Burner and Nozzle Data Tables”. When using town or natural gas, adjust the screw so that when the thermostat knob is turned from the maximum to the minimum setting, the flame always remains stable and uniform.

  • Page 9: Description Of Front Panel Controls

    5.2 Burner and Nozzle Data Table GAS CATEGORY: I3+(28-30/37) I3B/P(30) I3B/P(37) I3B/P(50) □G30 □G31 □G30 □G30 □G30 TYPES OF GAS: GAS PRESSURE（mbar）: 29 HEAT Top burner: Top burner: Top burner: Top burner: INPUT(Hs) 1.7kW(124g/h) 1.7kW(124g/h) 1.7kW(124g/h) 1.5kW(109g/h) Bottom burner: Bottom Bottom burner: Bottom burner: 2.5kW(182g/h)
  • Page 10 THERMOSTAT KNOB (ON SOME MODELS ONLY) This knob lights the gas burner inside the oven. The cooking temperature is set by turning the knob anti- clockwise to the value required, between Min. and Max. For instructions for lighting the gas oven, refer to point"7.3 Using the Gas Oven".
  • Page 11 FUNCTION SWITCH KNOB (ON SOME MODELS ONLY) setting turns on the light inside the oven during normal Operation. setting turns on the light and the turnspit inside the oven during normal operation. 6 KEYS ELECTRONIC TIMER (ON SOME MODELS ONLY) Digital clock Showing time:(0:00-24:00) and minutes.

  • Page 12: Using The Oven

    button is ressed the time displaced will be seen. When the set time is reached, disappears and the alarm will ring again. To stop the alarm, press the button. Notice : after pressing the related button, setting is supposed to be done in 5 seconds. In case of blackout, the set process as well as the real time (hour, minute) will disappear.

  • Page 13: Cleaning And Maintenance

    of the oven. 7.5 Attention Grilling processes must never last more than 60 minutes. In enameled models, grill and grill + rotisserie cooking operations must be carried out with the door ajar on the first catch and the knob guard supplied fitted into the top of the oven cavity. Accessible parts may be very hot during and after use of the grill;...
  • Page 14 tear, such as gaskets, light bulbs, etc. The specific instructions for each procedure of this kind are provided below. Before carrying out any operation involving access to live parts, disconnect the appliance from the electricity supply. 9.1 Replacing the Oven Lamp ·...

  • Page 15: Technical Specifications

    9.3 Removing the gaskets To allow thorough cleaning of the oven, the door gasket can be removed. Before removing the gasket, remove the oven door as described above. Once the door has been removed, lift the tangs at the corners as shown in the figure. 10.
  • Page 16 Under no circumstances, whether based on limited warranty or otherwise shall the company be liable for incidental, special or consequential damages. Use of product indicates acceptance by you of the aforesaid terms and conditions. PRODUCT NAME : BUILT-IN OVEN GL 662 Gas MODEL NO.: SERIAL NO.: BILL NO.
