- Page 1 VC45 VC45 VM45 VM45 Operating Instructions Operating Instructions...
-
Page 3: Safety Instructions
− When the device is not properly working although you followed all instructions of the user's manual. − When the camera fell to the floor or the housing has been damaged. − When the device shows apparent deviations of normal operation. ©PCO 1999 VMC45-03/99... -
Page 5: Table Of Contents
Contents Contents 1. Video Camera VC45 1.1 Features of the Camera ..........6 Video Standard ................6 Shutter Control ................6 Long Exposure ................6 1.2 CCD Sensor..............7 Overview of the used sensors ............. 7 Lens-on-chip ................7 Spectral Response..............8 1.3 Connections ..............8... -
Page 6: Video Camera Vc45
This manual contains important information and instructions for the use of the Video Camera VC45 and the Video Module VM45. If you work with a Video Camera VC45, you will find all neces- sary information in Chapter 1. Chapter 2 includes additional information when working with a Video Module VM45 (= VC45 without housing). -
Page 7: Ccd Sensor
1. Video Camera VC45 1.2 CCD Sensor Overview The following CCD sensors can be used in the camera: CCIR format resolution pixel size active sensor 1/2“ 741 x 576 pixel 8.6 x 8.3 µm 6.4 x 4.8 mm 2/3“ 741 x 576 pixel 11.6 x 11.2 µm 8.6 x 6.5 mm... -
Page 8: Spectral Response
= with infrared cutting filter 1.3 Connections Lens Mount The VC45 uses a C-Mount with a standard back focal length of 17.52mm (distance between the front edge of the C-Mount in- sert and the focal plane of the CCD sensor). The C-Mount has a fine adjustment to allow for small variations in the focal length of instruments. -
Page 9: Pin Assignment
1. Video Camera VC45 Pin Assignment The 12 pin socket at the camera rear panel has a standard pin assignment as follows. Please note that there are also special pin assignments possi- ble. In this case a separate pin assignment is enclosed. - Page 10 1. Video Camera VC45 Remark The Long Exposure Control can only be active when the module is in the parallel mode and the shutter is off! DIP switch S1/pin 7 = open DIP switch S1/pin2 = closed; ENB don’t care DIP switch S1/pin2 = open;...
- Page 11 1. Video Camera VC45 Shutter speed setting, parallel or serial input. Parallel Input Only the high-speed shutter is used when using parallel input. (During frame accumulation, low-speed shutter does not oper- ate normally). Shutter speed table shutter speed shutter off...
- Page 12 1. Video Camera VC45 symbol min: max: ED2 setup time against the rising edge of ED1 20ns ED2 hold time against the rising edge of ED1 20ns ED1 rising setup time against the rising edge of ED0 20ns ED0 pulse width 20ns 50µs...
- Page 13 1. Video Camera VC45 CSYNC Composite synchronisation output TTL level VSYNC Vertical synchronisation output TTL level MODE Switch between field-frame readout and integration TTL level mode readout field high frame GENLOCK External synchronisation Input to synchronise the camera to an external video device.
-
Page 14: Mode Settings
1. Video Camera VC45 1.4 Mode Settings Operating Mode The camera runs in two different operating modes: • FRAME interlaced • FIELD interlaced FRAME FIELD INTERLA- INTERLA- FIELD 1 FIELD 2 FIELD 1 FIELD 2 Integration Time: 2 x 40ms (CCIR) Integration Time: 2 x 20ms (CCIR) 2 x 33.4ms... -
Page 15: Long Exposure In Frame Mode
1. Video Camera VC45 Long Exposure in Frame Mode By using the EXP (= exposure) input (pin 3 of the 12-pin socket) the integration time can be controlled. In line 10 of the video signal a marker pulse is allocated. If in this moment the EXP signal is "high", the marker pulse is sup-... -
Page 16: Shutter Mode
1. Video Camera VC45 Shutter Mode In the shutter mode, exposure times between 1/50 ... 1/10000 s can be realized. These shutter times can be achieved by a par- allel and serial programming via external signals (ENB, ED0, ED1, ED2) or by a parallel setting via internal DIP switches. -
Page 17: Video Module Vm45
2. Video Module VM45 2. Video Module VM45 The main features of the Video Module VM45 are identical to these of the Video Camera VC45. In this Chapter you will find some additional information to the Video Module VM45. Please note that there are parallels between the 12-pin socket at the camera rear panel and the internal connector ST1. - Page 18 The XSG pulse is done in the following lines after the vertical sync has ended: CCIR 8 lines odd field 8.5 lines even field EIA RS170 1.5 lines odd field 1 line even field ©PCO 1999 VMC45-03/99...
- Page 19 • Internally by the potentiometer P2 upper board VIDEO SPC • Externally with a voltage range of 0 ... 5V The gain range is between 5 ... 32 dB. • Externally with a potentiometer: +5 V to GAINext 10kΩ ©PCO 1999 VMC45-03/99...
- Page 20 (VR). The synchronisation with Genlock can be enabled/disabled by controlling LSW. This can be done with DIP switch S1: DIP switch S1/pin 8 = open Genlock disabled DIP switch S1/pin 8 = closed Genlock enabled ©PCO 1999 VMC45-03/99...
-
Page 21: Dip Switches
DIP switches The 8 DIP switches have the following function: lower board VMAIN DIP switch S1 DIP switch S1 function factory set TRIG open closed open open open Mode open PS (parallel / serial) open Genlock open ©PCO 1999 VMC45-03/99... -
Page 22: Ccd Select And Standard
Pin 1 bottom side of lower board VMAIN 6 pin connector JP1: EIA RS170 or CCIR setting Pin 1 Pin 1 EIA RS170 CCIR JP2: 1/2“ sensor or 2/3“ sensor Pin 1 Pin 1 1/2“ sensor 2/3“ sensor ©PCO 1999 VMC45-03/99... -
Page 23: Gamma Setting
2. Video Module VM45 Gamma Setting The gamma setting can be done with the jumpers JP3, JP4 and JP5, jumpered on the board "Video SPC". Linear Gamma 1 Gamma 2 Other combinations are not allowed !! upper board VIDEO SPC ©PCO 1999 VMC45-03/99... -
Page 24: Servicing, Maintenance And Cleaning Instructions
Do not leave the camera’s optical input window open, without lens or protecting cap. Our warranty does not cover damaged optical surfaces caused by improper cleaning methods. ©PCO 1999 VMC45-03/99... -
Page 25: Appendix
S/N: ..the camera) Warranty PCO grants a 12 month warranty period for the camera. The warranty period starts on day of delivery ex-factory. In case of defect within the warranty period replacement or repair will be made (at PCO’s discretion) free of charge. The device shall be returned on customer’s expenses to PCO, preferably in the... -
Page 26: Ce-Certification
4. Appendix CE-Certification VC45 complies with the requirements of the „EMC Directions of the European Communities (089 / 336 / EWG)“ and therefore bears the CE-Marking. Dimensions and Weight C-Mount 39mm 8,3mm 75mm 12mm 110mm 130mm 1/4”-20 UNC 47mm 25mm... -
Page 27: Electrical Schematics Of The Board Vmain
4. Appendix Electrical Schematics of the board VMAIN ©PCO 1999 VMC45-03/99... -
Page 28: System Data
4. Appendix System Data Model VC45-C-12 VC45-C-23 VC45-N-12 VC45-N-23 Sensor format 1/2“ sensor 2/3“ sensor 1/2“ sensor 2/3“ sensor Video Standard CCIR EIA RS170 Pixel Resolution 741 x 576 741 x 576 756 x 486 756 x 486 Pixel Size 8.6 x 8.3µm... - Page 29 Dear Customer, We hope the VC45 / VM45 will be an always valuable tool for your scientific day in, day out work. Comments, suggestions or any new idea on our system are welcome. We are at your disposal at any time, also after your buying of this camera.
