Technical Information

DP7XX Series Displays

Overview
DP7XX Series Displays
LCD options
LCD option Type
Value Transmissive
Standard Transmissive
High-performance Transmissive-Enhanced View
TFT
*
Viewing angle: Up, Down, Right, Left
© Danfoss | November 2016
PLUS+1 ® Mobile Machine Displays are designed to provide flexible, expandable, powerful and cost
effective total machine management system displays for a wide variety of vehicle applications.
DP7XX Series Displays are designed to perform in the most extreme mobile machine environments. The
latest technology with backlight provides outstanding brightness and contrast performance resulting in
an easy-to-read screen. Develop your own software and layout using the PLUS+1
Integrated Development Environment) and the GUIDE Vector Based Screen Editor (VBSE). A basic graphic
library is available.

Display options

The DP7XX offers three different display options to meet your application needs for both in-cab and open
usage. An optional projective capacitive touch screen that works through mud, water and with gloves is
available for the DP720 model. The DP730 model is equipped by default with the projective capacitive
touch screen.
Contrast
600:1
1000:1
800:1
PLUS+1 GUIDE
®
PLUS+1 ® GUIDE (Graphical User Integrated Development Environment) is a complete toolbox that
generates downloadable applications for all programmable PLUS+1
A screen editor allows easy development of applications by programmers without formal software
development training. The expertise from a software engineer is not needed to find your way around in
PLUS+1 ® GUIDE

Linux

operating system
®
DP7XX Series Displays contain embedded Linux
licensed under the GPL Version 2.0 or LGPL Version 2.1.
Linux ® operating system software is free software; you can redistribute it and/or modify it under the terms
of the GNU General Public License as published by the Free Software Foundation; Licenses full notice
available:
GPL Version 2.0 http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
LGPL Version 2.1 http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html
As an installer of Linux ® operating system you will have your own obligations under the licensing
agreements, which may include among other things the obligation to include a copy of these licenses or
to include an offer of a physical copy of the source code for such software with your distributions of the
equipment. You should carefully review the licenses to determine what your obligations and options may
be for your intended use.
Anyone in receipt of this program may obtain the complete corresponding source code from Danfoss for
a period of three years after the last shipment of this product and/or spare parts by going on line at
http://www.danfoss.com or include "source code for DP7XX" in your written request to:
PLUS+1 ® Helpdesk Danfoss (US) Company, 3500 Annapolis Lane North Plymouth, MN 55447 USA
Brightness Viewing angle
(cd/m2)
500 60°, 60°, 70°, 70°
400 80°, 80°, 80°, 80°
550 80°, 80°, 80°, 80°
® operating system software that is copyrighted software
® GUIDE (Graphical User
*
For application use
In-cab
In and out of cab
In and out of cab
® Compliant products.
L1315553 | BC00000223en-US0504 | 7
