- Page 1 Enviro-tex Commercial EVI Series - Air Source Heat Pumps Installation and Users Guide IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS RETAIN THIS GUIDE FOR FUTURE REFERENCE P a g e...
- Page 2 Enviro-Tex Commercial EVI Series Installation and User Guide Customer Service If you have any questions about ordering Air Source Heat Pump replacement parts and products, please get in touch. Customer Service and Technical Support (Open from 9am-4pm Monday- Friday) Phone: 01472 828086 Email: info@enviro-tex.co.uk...
-
Page 3: Table Of Contents
Table of Contents IMPORTANT SAFETY PRECAUTIONS....................5 Health and Safety (Materials)....................5 Important End User Safety Information................... 7 Section 1........................... 8 Introduction........................... 8 Product Overview........................8 General Features........................8 Section 2........................... 9 Installation............................. 9 Materials needed for installation....................9 Installation of Outdoor Unit....................10 Suggested Installation Methods..................... - Page 4 Section 3......................... 18 Operating Heat Pump........................18 LCD User-Friendly Interface Controller................... 18 General Instruction......................... 18 Controller Panel........................18 Controller Set-up........................19 1. Temperature Setting......................19 2. System Status Display Value..................... 20 3. Clock Setting........................21 4. Timer Setting........................22 5. Manual/Forced Defrosting....................23 General Operating Guide........................
-
Page 5: Health And Safety (Materials)
Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is required to provide information on substances hazardous to health (COSHH Regulations 1998). Enviro-Tex takes every reasonable care to ensure that these products are designed and constructed to meet these general safety requirements, provided they are properly installed and used. - Page 6 IMPORTANT SAFETY INFORMATION FOR THE END-USER • Installation of the appliance must only be carried out by persons with suitable engineering qualifications. • Do not attempt to modify, repair or service the appliance yourself. • Do not insert body parts or any other items into the air inlet or outlet. •...
-
Page 7: Section 1
Compared with traditional oil/LPG boilers, Enviro-Tex high-temperature heat pump produces up to 50% less CO² whilst saves up to 80% on running costs. Enviro-Tex heat pumps are not only highly efficient, but also easy and safe to operate. -
Page 8: Section 2
6. A filter on the water inlet is needed. 7. The plumbing should be insulated to reduce heat losses. Note: We recommend installing shut-off valves on the inlet and outlet water connections for ease of serviceability. Enviro-tex EVI Series Air Source Heat Pump Specification Model EVI35000 EVI65000 EVI80000 Water Outlet Temp at 35/45°C... -
Page 9: Installation Of Outdoor Unit
Correct installation is required to ensure safe operation. The requirements for Enviro-Tex heat pumps include the following: 1. Appropriate site location and clearances. 2. Wiring to conform to 17 edition wiring regulations. 3. Adequate water flow. This manual provides the information needed to meet these requirements. Review all application and installation procedures completely before continuing the installation. - Page 10 The foundation of the heat pump can be a cement or steel structure. Anti-vibration rubber feet and a flat foundation are generally required. The foundation structure can be flexibly designed according to the working weight of the heat pump. (Please see the technical data in this manual.) Water drainage should be available near the installation location for draining water in an effective way.
-
Page 11: Suggested Installation Methods
Suggested Installation Methods 1. For hot water only / buffer tank, low loss header or thermal store installations, with or without a coil. (See Figure 3) The system is controlled by the programmer supplied and the thermostat probe only. Please ensure this is properly located within the buffer or header. (Figure 3) 11 | P a g e... -
Page 12: Water Connections
2. For direct heating only installation (See Figure 4) The system is controlled by the programmer supplied and the thermostat probe only. Please ensure this is properly located within the buffer or header. The water flow rate through the unit must meet the minimum amount set. (Figure 4) Water Connections Water connections at the heat pump... -
Page 13: Plumbing Installation Requirements
The water inlet and outlet connections to the heat pump, accept standard BSP threaded fittings. CAUTION – Make sure that water flow rates can be maintained with the installation of additional heat pumps and plumbing restrictions. Plumbing Installation Requirements 1. Water pressure should not exceed 3 Bar. 2. -
Page 14: Electrical Connections
Electrical Connections WARNING – Risk of electrical shock or electrocution. Ensure that all high voltage circuits are disconnected before commencing heat pump installation. Contact with these circuits could result in death or serious injury to users, installers or others. CAUTION – Label all wires prior to disconnection when servicing the heat pump. Wiring errors can cause improper and dangerous operation. - Page 15 Wiring Diagram Three Phase: EVI35000 15 | P a g e...
-
Page 16: Power Supply
Three Phase: EVI65000/ EVI80000 Power Supply 16 | P a g e... -
Page 17: Controller Pc Board Setting
1. If the supply voltage is too low or too high, it can cause damage and/or result in unstable operation of the heat pump unit, due to high in rush currents on start up. 2. The minimum starting voltage should be above 90% of rated voltage. The acceptable operating voltage range should be within ±10% of the rated voltage. -
Page 18: Operating Heat Pump
Section 3 Operating Your Heat Pump LCD User-Friendly Interface Controller General Instructions The operation panel features: 1. Capacitive touch keys for higher operating sensitivity and unlimited key operations. 2. Minimal electromagnetic susceptibility and interference. 3. Stylish appearance of easy viewing purposes. 4. -
Page 19: Controller Set-Up
Keys Explanation: Unlocking Keys: Press the “power” key for 3 seconds until you hear the audible tone, then release the key. The backlight of the LCD display will turn on and the key pad is locked with no “lock key display”... -
Page 20: System Status Display Value
2. System Status display values: Make sure key-pad is unlocked. Press the “setting” key and enter into the inquiry panel with “inquire” symbol on display. On the state of power on, press the “setting” key for more than 3 seconds, until an audible tone is heard and enter into the setting panel with “setting”... -
Page 21: Clock Setting
Defrosting time 5-20min 8min Evaporator coil temperature to quit 1℃─40℃ 25℃ defrosting Electronic expansion valve 20~180 s regulation period Degree of super heat -8~15°C Allowed discharge gas temperature 70~135°C Expansion valve opening degree in 6~55° defrosting Expansion valve minimum opening 6~30 degree Super heat compensation... -
Page 22: Timer Setting
4. Timer Setting The heat pump consists of two separate timing functions. Timer 01 and 02 are used to set the ON/OFF times of the heat pump within the 24 hour period. Timer 03 and 04 are used to set the ON/OFF times of an external water pump within 24 hour period (Timer 03 and 04 - not applicable with these models). -
Page 23: Manual/Forced Defrosting
After completing all timer settings, the controller will display the following: To cancel the timer feature, press the “timer” key for more than 3 seconds until an audible tone is heard, then release key, timer is now cancelled. 5. Manual/ Forced Defrosting: Although this heat pump features an automatic defrosting function, a manual defrosting function enables the user to manually defrost the heat pump when unusual frosting appears. -
Page 24: Users Guide
CAUTION – Keep all objects clear from above the heat pump. Blocking air flow could damage the unit and may void the warranty. Users Guide 1. Rights and Responsibility 1.1 To ensure you have the service guarantee period, only qualified heating engineers can install and repair the unit. - Page 25 This error normally relates to an inadequate water flow rate causing the heat pump to overheat, check the size of the pump and pipe work. Compressor Low Pressure Protection (error code: 06E): If a low pressure is detected on the compressor, the heating function will be suspended, the error code will be displayed and the alarm will sound.
-
Page 26: Section 4
Section 4 General maintenance Controller Error Codes The following Common Error Codes for the heat pump units displayed on the controller: CODE NAME CODE NAME Abnormal compressor discharge temperature Phase Failure and/or Faulty compressor discharge temperature sensor Ambient temperature too low and/or Faulty Phase Stagger ambient temperature sensor Water flow switch... -
Page 27: Inspection And Service
Inspection and Service Enviro-tex air source heat pumps are designed and built to provide long life and performance, when installed and operated properly under normal conditions. Periodic inspections are important to keep your heat pump running safely and efficiently. Owner Inspection Enviro-tex recommends that inspections on heat pumps are done frequently, especially after abnormal weather conditions. -
Page 28: Problems And Corrective Action
Problem and Corrective Action Problem Possible Cause Corrective Action Description 1. Ensure that incoming phase rotation is correct. Use a phase rotation meter to check incoming phase. 1. Absent phase or phase 2. Test for absent phase, make sure that the circuit breakers rotation or voltage imbalance are switched ON and check cable connection. - Page 29 b) Circulation pump is too Install correct circulation pump small. for specific application. Charge the correct volume of refrigerant specified 6. Excessive refrigerant charge volume. on the label. 7. Control cable of the high pressure Replace the damaged cable or reconnect. switch damaged or disconnected.
- Page 30 damaged. 2. Water tank water temperature sensor Reconnect or clean water tank water temperature connector (plug) disconnected and/or sensor. oxidized due to damp or water. 3. The controller and/or PC Board faulty or Replace the controller or PC Board. damaged. 1.
- Page 31 2. Outlet water temperature sensor Reconnect or clean outlet water temperature connector (plug) disconnected and/or sensor. oxidized due to damp or water. 3. The controller and/or PC Board faulty or Replace the controller or PC Board. damaged. 1. Compressor suction temperature Replace the Compressor suction temperature sensor faulty or damaged.
- Page 32 Connectors. 3. If power is not restored, replace cable. a) The temperature displayed is Check the water tank water more than 45°C. temperature sensor, replace if faulty. 2. Problem with b) PC Board is damaged due to Find out the cause, find faulty relay(s) controller or PC burnt relays.
- Page 33 Check and ensure that the mains b) The main power supply power supply voltage is lower than 175V. cable', length and thickness, is within the specifications. 2. PC board power cable is disconnected Reconnect PC Board cable or replace the fuse. or the fuse is burnt.
- Page 34 Check and ensure that b) The main power the mains power supply voltage is lower supply cable', length and thickness, is within than 175V. the specifications. c) No compressor relay Check and/or replace output from the PC compressor relay or PC Board.
-
Page 35: Section 5
Section 5 Components assembly EVI30000 Item Description Item Description Item Description solenoid pilot actuated Tube in Shell Heat Fan Protection Net valve Exchanger Top Panel Ejection expansion valve Base Plate Fan Blade Plate heat exchanger Evaporator Back Support Bar Liquid Receiver Fan Motor Guard Side Net Panel Level Glass... - Page 36 EVI65000/EVI80000 36 | P a g e...
- Page 37 Item Description Item Description Front Under-Part Board Compressor Front Middle-Part Board Gas and Liquid Separator Left Front Support Bar Evaporator Tray Front Protection Net Condenser Front Top Board Right Top Board Left Under-Part Board Right Upside Board Left Middle-Part Board Right Middle-Part Board Pressure Gauge Right Under-Part Board...
- Page 38 Enviro-Tex 169-177 Cleethorpe Road, Grimsby, DN31 3AX. Email: info@enviro-tex.co.uk www.enviro-tex.co.uk 38 | P a g e...
