Television
Operating Instructions
KDL-48W657D / 40W657D / 32W607D
Getting Started
Parts and Controls
Connecting TV to the Internet
Watching TV
Navigating through Home Menu
Viewing Pictures from Connected
Equipment
Additional Information
Sony Customer Support
http://esupport.sony.com/ES/LA/
Please Do Not Return
the Product to the Store

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-48W657D

Summary of Contents for Sony KDL-48W657D

  • Page 1 Parts and Controls Operating Instructions Connecting TV to the Internet Watching TV Navigating through Home Menu Viewing Pictures from Connected Equipment Additional Information Sony Customer Support http://esupport.sony.com/ES/LA/ Please Do Not Return the Product to the Store KDL-48W657D / 40W657D / 32W607D...

  • Page 2: Table Of Contents

    Table of Contents IMPORTANT NOTICE ....4 Watching TV Safety Information ....4 Select Your Content Source .
  • Page 3 Viewing Pictures from Connected Equipment Connection Diagram... . . 32 Connecting the TV ....33 Showing a Set Top Box with HDMI connection .

  • Page 4: Important Notice

    Thank you for choosing this Sony product. Before operating • Utilice el cable de alimentación de ca especificado por the TV, please read this manual thoroughly and retain it for Sony y que corresponda al voltaje de la zona donde vaya a future reference. utilizarlo.
  • Page 5 NOTE ON AC ADAPTER Warning To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. To prevent fire or shock hazard, do not place objects filled with liquids, such as vases, on the apparatus.
  • Page 6 Please take a moment to register your TV  Discover the wealth of entertainment now available on super-high resolution http://esupport.sony.com/LA/perl/ Blu-ray Disc™ player and other Sony HD registration.pl equipment. Four Steps to a Stunning HD Sound Experience Complete the high-definition experience Set, Source, Sound, and Setup.

  • Page 7: Getting Started

    Securing the TV Getting Started Sony strongly recommends taking Setting Up Your TV measures to prevent the TV from toppling over. Unsecured TVs may Some TV models are packaged with a topple and result in property damage, detached Table-Top Stand so you can serious bodily injury or even death.

  • Page 8: Recommended Measures To Secure

    The length of the M6 machine screw Recommended Measures to Secure differs depending on the rope or chain the TV diameter. Please refer to below illustration. Consider the following measures when 10 mm - 12 mm securing your TV to a Stand (not supplied). Secure the Stand for the TV.

  • Page 9: Precautions

    Precautions How to care for your BRAVIA TV Safety is very important. Please read and follow the safety documentation (Safety Booklet) separately provided. Unplug the TV and other connected equipment from the wall outlet before you begin cleaning your  Wipe the LCD screen gently with a soft cloth.

  • Page 10: Parts And Controls

     (Sensors/LED indicator) • Receives signals from the remote Parts and Controls control. Do not put anything over the sensor. Doing so may affect its function. • Lights up in amber when the [Sleep Timer] or [On Timer] is set (page 29), or the TV is in Photo Frame Mode (page 20).

  • Page 11: Remote Control

     Color buttons Remote Control Displays operation guide (when colored buttons are available). The remote control shape, location,  NETFLIX (Only on limited region/ availability and function of remote control country/TV model) button may vary depending on your region/ Accesses the “NETFLIX” online service. country/TV model.
  • Page 12   CH +/– (REPLAY)/ (ADVANCE) Replays the scene/briefly fast forwards Select the next (+) or previous (–) the scene (USB and IPTV Video playback channel. only).  CC/SUBTITLE  POWER Changes the subtitle setting (page 28). Turns the TV on or switches to standby Hint mode.

  • Page 13: Guidelines For Remote Control

    Guidelines for Remote Control  Point your remote control directly at the IR sensor located on your TV.  Make sure that no objects are blocking the path between the remote control and the IR sensor on your TV.  Fluorescent lamps can interfere with your remote control;...

  • Page 14: Connecting Tv To The Internet

    Type 1: Secured network with Wi-Fi Connecting TV to the Internet Protected Setup™ (WPS) The WPS standard makes security of a Setting up the Internet wireless home network as straightforward as pressing the WPS button on the wireless Connection LAN router. Before setting up a wireless LAN, check the location of the WPS button To use the network features of your TV it on the router and verify how to use it.

  • Page 15: Type 2: Secured Network Without Wi-Fi Protected Setup™ (Wps)

    Note Type 2: Secured network without • Security key (WEP or WPA key) will not be required because you do not need to select any Wi-Fi Protected Setup™ (WPS) security method in this procedure. • To use the network with IPv6, select [Settings]  To set up a wireless LAN, SSID (wireless [Preferences] ...

  • Page 16: Preparing A Wired Network

    When you use the following functions to connect to the Internet, certain information Viewing the Network Status will be sent to Sony Corporation’s global servers, which is considered to be personal You can confirm your network status. information, and requires your agreement in order for service providers to use it.

  • Page 17: Watching Tv

    The boxy 4:3 aspect ratio (common to most SD signals) must be adjusted to fill the Watching TV screen. Press  on the TV or POWER on the remote control to turn on the TV. Press ANT/DIGITAL/ANALOG to switch between digital and analog modes.

  • Page 18: Changing The Viewing Style

    Changing the Viewing Style Changing the Wide Mode Press WIDE repeatedly to select the wide mode. [Wide Zoom]* [Normal] [Full] [Zoom]* * Parts of the top and bottom of the picture may be cut off. For HDMI PC Input (PC timing) [Normal] [Full 1] [Full 2]...

  • Page 19: Navigating Through Home Menu

    Photo Sharing Plus Navigating through Home Menu Connect, view and save favorite photos on TV using your devices (e.g. smartphones or tablets). The HOME button allows you to access a variety of TV settings and features. HOME  [All Apps]  [Photo Sharing Plus] Note All Apps...

  • Page 20: Using The Tv As A Photo Frame

    Duration Using the TV as a Photo Frame Mode To save power, the TV continually plays back in [Photo Frame Mode] for up to 24 Photo Frame Mode displays the clock and hours before powering off automatically. calendar at the same time as displaying a After automatic power off, do not use photo and listening to music or FM radio.

  • Page 21: Digital Program List

    Press then to select [Digital Program List]. You can enjoy photo/music/video files stored in a Sony digital still camera or camcorder through a USB cable or USB storage device on your TV. Connect a supported USB device to the TV.
  • Page 22 The data on the USB device may be damaged. Audio Codec: MPEG1 Layer1/2, MP3, • Sony will not be held liable for any damage to, or loss of, data on the recording media due to a Dolby Digital (2ch), Dolby malfunction of any connected devices or the TV.

  • Page 23: Home Network

    Home Network Settings Connecting to a Home Network Preferences You can enjoy various content (e.g. photo/ Note • The options you can adjust vary depending on music/video files) stored on DLNA the situation. Unavailable options are greyed out Certified™ media servers. The home or not displayed.
  • Page 24 MPEG Noise Reduction Sound Adjustments Reduces the picture noise in MPEG- Sound Mode compressed video. Select according to content you want to enjoy. CineMotion Provides improved picture movement Reset when playing BD (Blu-ray Disc), DVD Reset [Equalizer], [Clear Voice], or VCR images taken on film. Select [Steady Sound], [Balance] and [Auto] to represent original film-based [Volume Offset] settings.
  • Page 25 Advanced Settings H Center Adjusts the horizontal position of the Dynamic Range: Compensates for picture. differences in the audio level between different channels. V Center Note Adjusts the vertical position of the • The effect may not function or may vary picture.
  • Page 26 Audio Filter Subtitle Setup: Select [Low] or [High] to improve Subtitle Setting the sound of individual channels When [For Hard Of Hearing] is when distortion occurs in mono selected, some visual aids may also broadcasts. be displayed with the subtitles (if TV channels broadcast such Program Sorting: Changes the information).
  • Page 27 Technical Setup: Internet Lock Service Replacement Locks internet contents from being Select [On] to automatically change watched. the channel when broadcaster To view a internet contents, select changes transmission of the [Unblocked]. viewing program to a different channel. Setup FM Radio Setup Presets up to 30 FM radio stations that Network can be received in your area.
  • Page 28 Home Network Setup: Music Playback Setting: Select from listening to all tracks or a Show/Hide Media Servers single music track. Displays the connected server list. You can select the server to display Duration: Select the time period in the Device Selection. after which the TV automatically Media Server Troubleshooting switches to standby mode.
  • Page 29 Clock/Timers Startup Logo Sets the timer and clock. Select [On] to display the logo when the TV is turned on. Select [Off] to Sleep Timer: Sets the time in disable it. minutes that you would like the TV to remain on before shutting LED Indicator off automatically.
  • Page 30 BD player, etc; via the remote set to [On], the following control. functions are available. Tuning and Menu Keys If the specific Sony equipment For basic operations and operation that is compatible with BRAVIA of channel-related buttons and Sync Control is connected, this HOME/OPTIONS button.

  • Page 31: Customer Support

    Network. Note • Software update via the internet may vary depending on your region/country/TV model. • To update the software, please visit Sony support website. Automatic Software Download Select [On] to download the software automatically. Select [Off] to disable it.

  • Page 32: Viewing Pictures From Connected Equipment

    Viewing Pictures from Connected Equipment Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Depending on TV model, connecting a large USB device may interfere with other connected devices beside • When connecting a large USB device, connect only 1 USB jack. Home Audio System with ARC/HDMI Device...

  • Page 33: Connecting The Tv

    Showing a Set Top Box with HDMI Connecting the TV connection Note • Use an antenna cable connector no greater than 14 mm thick. • When connecting the cable to the Cable/ Antenna, input finger tighten only, over tightening the connection can damage the TV. •...

  • Page 34: System

    Cable System or VHF/UHF Antenna System Antenna Cable...

  • Page 35: Showing Hd Bravia® Sync™ Basic Connection

    Showing HD BRAVIA® Sync™ Basic Connection Rear panel *A/V Receiver *Blu-ray Disc player Side Panel *HD Cable Box or HD Satellite Receiver SAT (Dish) Cable/ Antenna Signifies a BRAVIA Sync capable device.

  • Page 36: Showing Hd Basic Connection With Home Theater System

    Showing HD Basic Connection with Home Theater System Rear panel Side Panel Home Theater System Blu-ray Disc player/ DVD Player...

  • Page 37: Showing Pc Connection With Sd

    Showing PC Connection with SD VCR/DVD *DVI Notebook PC Side Panel Rear panel Bottom of TV VCR/DVD Combo with Video Input Splitter Cable/Antenna * DVI does not support audio signals. Connect the audio output of the PC to the PC speakers or an A/V receiver to listen to sound from the PC.

  • Page 38: Using Audio And Video

    • When connecting with an HDMI cable, be sure to the TV. Once connected, the device use HighSpeed HDMI Cable with Cable Type Logo (Recommended SONY Cable). screen will be displayed on the TV. • When connecting mono equipment, connect the audio cable to the L (mono) jack.

  • Page 39: Additional Information

    • When removing the Table-Top Stand from the TV, For product protection and safety lay the display face down on a stable work reasons, Sony strongly recommends that surface that is larger than the TV. installation of your TV on the wall be •...

  • Page 40: Installing The Tv Against A Wall Or

    LED indicator flashes red (interval time is three seconds). Press  on the TV to turn it off, disconnect the AC power cord, and contact Sony Leave at least this much space around the set. Customer Support. Installed on the wall When the LED indicator is not flashing, check the items as follows.

  • Page 41: Sound

    Picture contours are distorted use the Screen mirroring function?   Change the current setting of [CineMotion] to Sony Screen mirroring compatible devices other settings (page 24). (Xperia) can be connected. No color on programs Video or sound sometimes cuts out ...

  • Page 42: General

     Sometimes video streaming quality is If the LAN cable is connected to an active server and the TV has acquired an IP address, poor when using the wireless LAN check your DLNA Certified™ media server’s  The wireless network connection quality connections and configurations.

  • Page 43: Specifications

    The , +, and – buttons cannot be located (Resolution, Horizontal frequency, Vertical on the TV. frequency) For KDL-48W657D / 40W657D  See below illustration for location of the 640 × 480, 31.5 kHz, 60 Hz buttons on the TV.
  • Page 44 Dimensions* Disc Association. • “PlayStation” is a registered trademark with stand KDL-48W657D: 1,092 × 683 × 235 mm and “PS3” is a trademark of Sony KDL-40W657D: 924 × 589 × 212 mm Computer Entertainment Inc. KDL-32W607D: 735 × 481 × 174 mm •...
  • Page 45 • Windows Media is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. • This product contains technology subject to certain intellectual property rights of Microsoft. Use or distribution of this technology outside of this product is prohibited without the appropriate license(s) from Microsoft.
  • Page 48 For Your Convenience Online Be sure to register your TV. Registration: http://esupport.sony.com/LA/perl/registration.pl Your TV is capable of receiving software updates. For the latest information about software updates for your TV, visit: Software Updates: http://esupport.sony.com/LA/ © 2016 Sony Corporation Printed in U.S.A. 4-584-792-E2(1)
