- Page 1 C-series Platforms C2000 and C4000 Hardware Quick Start Guide Juniper Networks, Inc. 1194 North Mathilda Avenue Sunnyvale, CA 94089 408-745-2000 www.juniper.net Part Number: 530-018157-01, Revision A00...
- Page 2 Product Reclamation and Recycling Program Juniper Networks is committed to environmentally responsible behavior. As part of this commitment, we work to comply with environmental standards such as the European Union’s Waste Electrical and Electronic Equipment (WEEE) Directive and Restriction of Hazardous Substances (RoHS) Directive.
-
Page 3: Quick Start Overview
A Phillips screwdriver A utility knife Eight 10-32 x 3/8 Phillips screws (provided) for each model to be installed For detailed installation guidelines and considerations, see C2000 and C4000 Hardware Guide, Chapter 9, Installation Guidelines and Requirements. Quick Start Overview... -
Page 4: Installing The System
C2000 and C4000 Quick Start Guide 2. Installing the System When installing the system on a table top or in any other freestanding mode, be sure to leave enough space around the system for adequate ventilation. Position the system with easy access to the connections that it needs for power, local communications, and remote communications. -
Page 5: Cabling The System
C2000 and C4000 Quick Start Guide Figure 3: C4000, Front Oblique View Figure 4: C4000, Rear Oblique View 3. Cabling the System Before powering up the system, you must set up a management console. The console enables you to communicate with your system during the power-up process and to manage your system using the command-line interface (CLI). -
Page 6: Connecting To A Network
2. Connect the other end of the cable to your terminal’s serial port (VT100/ANSI). Ethernet Interfaces Port ETH0 and ETH1 on the C2000 model and the C4000 model accept RJ-45 10/100/1000Base-T Ethernet (copper) interfaces. Port ETH2 and port ETH3 on the C2000 model and the C4000 model accept SFPs. -
Page 7: Setting Up Management Access And Logging In
Each C-series platform contains a Juniper Networks database. The database stores SRC data, sample data, configuration information, and user profiles. You must enable the Juniper Networks database the first time you power on the system. Typically, you run the database in standalone mode only in testing environments. In standalone mode, the database does not communicate with other Juniper Networks databases;... -
Page 8: Configuring Hostname And Domain Parameters
C2000 and C4000 Quick Start Guide To enable a Juniper Networks database to run in standalone mode: 1. From configuration mode, access the configuration statement that configures the Juniper Networks database. user@host# edit system ldap server 2. Enable standalone mode. -
Page 9: Configuring The System For Remote Access
C2000 and C4000 Quick Start Guide 8. Configuring the System for Remote Access To allow remote access to the system, you must configure the generic interfaces. You can specify an IP address with mask or a broadcast address with mask for an interface. -
Page 10: Configuring The System To Accept Ssh And Telnet Connections
C2000 and C4000 Quick Start Guide 9. Configuring the System to Accept SSH and Telnet Connections To configure the system to accept SSH connections: 1. From configuration mode, access the hierarchy [edit system services ssh] level. 2. (Optional) Specify whether or not to allow root login through SSH. -
Page 11: Troubleshooting
United States, Canada, or Mexico) or 1-408-745-9500 (from elsewhere). Configuring and Operating the C-series Platform You are now ready to configure your system. See the C2000 and C4000 Hardware Guide and the SRC–PE Getting Started User Guide for more information about using the C-series platform. -
Page 12: Obtaining Documentation
Part Number: 530-018157-01, Juniper Networks, the Juniper Networks logo, NetScreen, NetScreen Technologies, the NetScreen logo, NetScreen-Global Revision A00 Pro, ScreenOS, and GigaScreen are registered trademarks of Juniper Networks, Inc. in the United States and other countries. Juniper Networks, Inc. 1194 North Mathilda Avenue The following are trademarks of Juniper Networks, Inc.: ERX, ESP, E-series, Instant Virtual Extranet, Internet Processor,...
