INSTRUCTION MANUAL
INSTALLATION / OPERATIONS / PARTS & SERVICE
MONTAGUE
REFRIGERATION AND FREEZER
BASES
MODEL(S):
RB36SC—RB108SC
RB36R—RB108R
RB36 FREEZER—RB108 FREEZER
These instructions should be read thoroughly before attempting installation.
Set up and installation should be performed by qualified installation personnel.
PLEASE RETAIN THIS MANUAL
FOR FUTURE REFERENCE.
THE MONTAGUE COMPANY
1830 Stearman Avenue
P.O. BOX 4954
Hayward, CA 94540-4954
TEL: (510) 785-8822 FAX: (510) 785-3342
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MONTAGUE RB36SC
Summary of Contents for MONTAGUE RB36SC
- Page 1 These instructions should be read thoroughly before attempting installation. Set up and installation should be performed by qualified installation personnel. PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE. THE MONTAGUE COMPANY 1830 Stearman Avenue P.O. BOX 4954 Hayward, CA 94540-4954 TEL: (510) 785-8822 FAX: (510) 785-3342...
- Page 2 IMPORTANT WARNING: FOR YOUR SAFETY: Improper installation, adjustment, alteration, service or maintenance Do not store or use gasoline or can cause property damage, injury other flammable vapors death. Read operating liquids in the vicinity of this or maintenance instructions any other appliance. thoroughly before installing or servicing this equipment.
- Page 3 The Refrigeration and Freezer bases are produced with the best possible material and workmanship. PROPER INSTALLATION IS ESSENTIAL FOR SAFE AND EFFICIENT TROUBLE-FREE OPERATION. THE INSTALLATION INSTRUCTIONS CONTAINED HEREIN ARE FOR THE USE OF QUALIFIED INSTALLATION AND SERVICE PERSONNEL ONLY. INSTALLATION OR SERVICE BY OTHER THAN QUALIFIED PERSONNEL MAY RESULT IN DAMAGE TO THE EQUIPMENT AND/OR INJURY TO THE OPERATOR.
- Page 4 MONTAGUE MODELS Montague RB-SC and RB-R models are refrigerated Equipment Stand units available in different lengths from 36 to 108 inches in width. These units are available as refrigerated or freezer storage compartments.
-
Page 5: Table Of Contents
TABLE OF CONTENTS THE SERIAL TAG …………………………………. PAGE 6 RECEIVING & INSPECTING …………………….. PAGE 7 A. UNPACKING AND CHECKING INSTALLATION ……………………………………. PAGE 7 & 8 A. UNPACK LOOSE COMPONENTS B. REFRIGERATION LINES C. ELECTRIC CONNECTION OPERATION ……………………………………….. PAGE 8 A. TEMPERATURE SETTING B. -
Page 6: The Serial Tag
Serial = The permanent ID# of your REFRIGERANT: LBS: Montague unit A TYPE II DISPLAY REFRIGERATOR OR FREEZER Model = The model # of your Montague unit INTENDED FOR OTHER THAN HOUSEHOLD USE. (DESTINE A UN USAGE AUTRE QUE Volts = Voltage ... -
Page 7: Receiving & Inspecting
INSTALLATION All Montague products are factory tested for A. Uncrate unit as near to final location as performance and are free from defects when possible for easier and lighter handling of the shipped. -
Page 8: Refrigeration Lines
INSTALLATION(CONTINUED) OPERATION connections. See wiring diagram shipped A. TEMPERATURE CONTROL SETTINGS: with the unit on the compressor compartment both Self-Contained Remote behind the louver panel for electrical rating. Refrigerated units, temperature Control should be set 35°F with a 5°F differential. This E. -
Page 9: Drawer Configuration
AVAILABLE DRAWER CONFIGURATION DRAWER CONFIGURATION (A) DRAWER CONFIGURATION (B) DRAWER CONFIGURATION (C) Can accommodate up to one Can accommodate up to two pans Can accommodate up to two pans 6” (152mm) deep, 12” x 20” (305 x 6” (152mm) deep, 12” x 20” (305 x 6”... - Page 10 AVAILABLE DRAWER CONFIGURATION Remote Model Guide Drawer: Width & Configuration Unit Width Model Total Inches 14-3/8” 22-3/8” 27-1/4” Number Pans (mm) (356mm) (566mm) (692mm) RB-36-R 36” (914) RB-48-R 48” (1219) RB-60-R 60” (1524) RB-72-R 72” (1829) C - (2) RB-84-R 84”...
-
Page 11: Maintenance Procedures
MAINTENANCE PROCEDURES track and pushing in the bottom so it fits inside A. CLEANING: STORAGE CABINET the opening, reconnect electrical supply. WARNING: DISCONNECT ELECTRICAL D. EVAPORATOR COILS: POWER SUPPLY BEFORE CLEANING ANY PARTS OF THE UNIT. WARNING: DISCONNECT ELECTRICAL POWER SUPPLY BEFORE CLEANING ANY B. -
Page 12: Condensing Unit
TROUBLSHOOTING PROBLEM POSSIBLE CAUSE Power failure Plug in loose receptacle or unplugged 1. Compressor fails to operate Blown fuse or tripped circuit breaker Main power switch is off Temperature control not set properly Door gaskets not sealing properly ... -
Page 13: Wiring Diagram (Rb-Self Contained)
WIRING DIAGRAM(RB-SC) SELF-CONTAINED EVAPORATOR COIL GROUND BLACK = HOT WHITE = NUETRAL FAN MOTOR BLACK WHITE GROUND ON SELF-CONTAINED WIRE CABINETS ONLY JUNCTION BOX PRESSURE 115V/60 HZ/ 1 PH SWITCH 1/3 HP COMPRESSOR EVAPORATOR COIL FAN MOTOR 10 AMP COMPRESSOR OUTLET GROUND WHITE... -
Page 14: Wiring Diagram (Rb-Remote)
WIRING DIAGRAM(RB-R) REMOTE EVAPORATOR COIL GROUND BLACK = HOT WHITE = NUETRAL FAN MOTOR BLACK WHITE GROUND WIRE JUNCTION BOX EVAPORATOR COIL FAN MOTOR GROUND WIRE WHITE SOLENOID VALVE BLACK BLACK T-STAT WHITE... -
Page 15: Wiring Diagram (Fb-Self Contained)
WIRING DIAGRAM(FB-SC) FREEZER EVAPORATOR COIL GROUND BLACK = HOT WHITE = NUETRAL FAN MOTOR BLACK WHITE GROUND WIRE DEFROST HEATER ON SELF-CONTAINED JUNCTION BOX CABINETS ONLY PRESSURE 115V/60 HZ/ 1 PH SWITCH 1/3 HP COMPRESSOR EVAPORATOR COIL FAN MOTOR 10 AMP BLACK COMPRESSOR OUTLET... -
Page 16: Wiring Diagram (Fb-Remote)
WIRING DIAGRAM(FB-R) FREEZER EVAPORATOR COIL GROUND BLACK = HOT WHITE = NUETRAL FAN MOTOR WHITE BLACK GROUND WIRE DEFROST HEATER JUNCTION BOX EVAPORATOR COIL FAN MOTOR SOLENOID GROUND VALVE WHITE WIRE DEFROST HEATER DEFROST HEATER (ONE DOOR) BLACK WHITE 1 2 3 4 5 6 7 8 9 AMBIENT (OUTSIDE COIL) DEFROST (INSTERTED... -
Page 17: Exploded Views & Parts Lists
EXPLODED VIEW #1... - Page 18 EXPLODED VIEW #1 PARTS LIST ITEM # PART # DESCRIPTION MODELS USED FOR 70030-4RA FAN HOUSING RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70031-2RA CONDENSING GUARD RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70032-0RA CONDENSER SHELF RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70044-4RA CC BOTTOM SHELF RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70045-2RA CC EXTERIOR TOP RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70046-0RA CC EXTERIOR BOTTOM RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70047-9RA CC BOTTOM &...
- Page 19 EXPLODED VIEW #2...
- Page 20 EXPLODED VIEW #2 PARTS LIST ITEM # PART # DESCRIPTION MODEL/S USED WITH 70002-9RA LINER SIDE, LEFT & RIGHT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70023-1RA DRAWER TRACK, LEFT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70025-8RA DRAWER TRACK, RIGHT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70026-6RA TRACK MOUNT, LEFT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70027-4RA TRACK MOUNT, RIGHT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70028-2RA TRACK MOUNT, FRONT LEFT...
- Page 21 EXPLODED VIEW #2 PARTS LIST CONTINUED TURBO COIL SEE "ADDITIONAL INFORMATION" TABLE FOR DETAILS 59676-0 HEX JAM NUT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 59630-2 SKATE WHEEL RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 59675-2 SPACER RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 59683-3 DIGITAL THERMOSTAT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 19118-3 CASTER WITH LOCK RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 60516-6 DIGITAL THERMOSTAT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R...
- Page 22 EXPLODED VIEW #3...
- Page 23 EXPLODED VIEW #3 PARTS LIST ITEM # PART # DESCRIPTION MODELS USED FOR 70014-2RA DRAWER SLIDE RIGHT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70015-0RA DRAWER SLIDE LEFT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70018-5RA DRAWER STOP RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70022-3RA HANDLE ENDS RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70042-8RA PAN DIVIDER RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70020-7RA DRAWER FACE RB-48-R,RB-36-SC,RB-60-SC 70160-2RA DRAWER FACE...
- Page 24 EXPLODED VIEW PARTS LIST #3 CONTINUED 70016-9RA PAN BACK DIVIDER RB-48-R,RB-36-SC,RB-60-SC 70164-5RA PAN BACK DIVIDER RB-48-R,RB-60-R,RB-84-R,RB-108-R,RB-60-SC,RB-72-SC,RB-96-SC 70114-9RA PAN BACK DIVIDER RB-36-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-48-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70017-7RA PAN FRONT DIVIDER RB-48-R,RB-36-SC,RB-60-SC 70163-7RA PAN FRONT DIVIDER RB-48-R,RB-60-R,RB-84-R,RB-108-R,RB-60-SC,RB-72-SC,RB-96-SC 70115-7RA PAN FRONT DIVIDER RB-36-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-48-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 70200-5RA DRAWER SUPPORT RB-36-R,RB-48-R,RB-60-R,RB-72-R,RB-84-R,RB-96-R,RB-108-R RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 59630-2...
- Page 25 EXPLODED VIEW #4 EXPLODED VIEW #4 PARTS LIST ITEM # PART # DESCRIPTION MODELS USED FOR 60513-1 SIGHT GLASS RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 60535-2 LOW PRESSURE SWITCH RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC 60524-7 LIQUID LINE FILTER DRIER RB-36-SC,RB-48-SC,RB-60-SC,RB-72-SC,RB-84-SC,RB-96-SC,RB-108-SC...
- Page 26 When ordering part, to eliminate mistakes and facilitate delivery, always give the following information: Serial No. _____________________________________________ Model No. _____________________________________________ Change No. ____________________________________________ Name & No. of Part Model No. Change No. Serial No. The Montague Company 1830 Stearman Avenue P.O. Box 4954 Hayward, CA 94540-4954...
- Page 28 THE MONTAGUE COMPANY 1830 Stearman Avenue P.O. BOX 4954 Hayward, CA 94540-4954 TEL: (510) 785-8822 FAX: (510) 785-3342 (Rev. A) P/N 61052-6...
