RDS SAM 400 User Manual

Speed-area-distance meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Electro-Magnetic Compatibility (EMC)
This product complies with Council Directive 2004/108/EC
when installed and used in accordance with the relevant
instructions.
Service and Technical Support
PLEASE CONTACT YOUR NEAREST DISTRIBUTOR
If unknown then fax: 44 (0) 1453 733322
© Copyright RDS Technology Ltd 2007
Document number
S/DC/500-10-533: Issue 4 : 6/7/07
\UK533-4.DOC
User Guide
"SAM 400"
Speed-Area-Distance Meter
Calibration and Operation
Software Reference WZ200-0 rev. 6
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SAM 400 and is the answer not in the manual?

Questions and answers

Related Manuals for RDS SAM 400

Summary of Contents for RDS SAM 400

  • Page 1 Service and Technical Support PLEASE CONTACT YOUR NEAREST DISTRIBUTOR If unknown then fax: 44 (0) 1453 733322 © Copyright RDS Technology Ltd 2007 Document number S/DC/500-10-533: Issue 4 : 6/7/07 \UK533-4.DOC User Guide “SAM 400”...

  • Page 2: Table Of Contents

    Select Engine / Ignition Hours ................14 RPM Sensor Factor ....................14 Changing the RPM Sensor Factor..............15 Wiring Connections – SAM 400 (without WCI/ACI) ________16 Wiring Connections – SAM 400 (With WCI / ACI)__________17 Connections for Cable S/CB/327-1-063............18...

  • Page 3: Overview

    ?? A power supply kit. ?? Shaft Speed Sensor (optional) If the SAM 400 is to be used on a number of vehicles, each vehicle can be equipped with a 'transfer kit' to enable the head unit only to be transferred simply between vehicles.

  • Page 4: Operation

    SAM 400 SPEED-AREA-DISTANCE METER Operation Figure 1 Channel Indicator Fwd Speed Part/Total Area Engine Hours Part/Total Distance Work Rate Decrease Cal Increase Cal Factor Factor Override Area/Distance accumulation ENTER PROGRAM SELECT CHANNEL MODE Reset Part/Total Area/Distance The instrument will normally be powered through the vehicle ignition system and will be on whenever the vehicle ignition is on.

  • Page 5: Forward Speed Display - Channel 1

    SAM 400 SPEED-AREA-DISTANCE METER Forward Speed Display - Channel 1 Channel 1 displays the current forward speed. Forward speed is measured via a sensor suitably mounted to a wheel hub or a convenient location to the vehicle drivetrain. Speed is displayed either in miles/hr or km/hr according to the units selected in the CAL Mode.

  • Page 6: Reset Area / Distance Totals

    SAM 400 SPEED-AREA-DISTANCE METER For both area and distance there are two memory registers - a 'Part' total ("tot.1") and a 'Full' Total ("tot.2"), which can be independently reset. For example the part total register may be utilised for individual jobs, fields etc, whereas the 'full' total register may be the daily total.

  • Page 7: (Ii) Optional Width Correction Interface

    (iii) Area Compensation Interface An Area Compensation Interface (ACI) connects between the SAM 400 and the sprayer switchbox. It detects which boom sections are on/off in order for the instrument to calculate the actual working width and apply the correct rate.

  • Page 8: Work Rate - Channel 4

    SAM 400 SPEED-AREA-DISTANCE METER Work Rate - Channel 4 This is the instantaneous work rate displayed in either hectares per hour or acres per hour, depending on the units set in the Cal mode. If a WCI switch or an ACI is installed, the work rate is automatically recalculated based on the implement part width in operation.

  • Page 9: Calibration

    SAM 400 SPEED-AREA-DISTANCE METER Calibration The instrument has two calibration modes. In calibration mode 1 you can view and change the Forward Speed Sensor Factor, Implement Width/Nozzle spacing, No. of nozzles per section (if ACI installed), Units, and RPM Sensor Factor.

  • Page 10: Set Implement Width/Nozzle Spacing

    SAM 400 SPEED-AREA-DISTANCE METER Set Implement Width/Nozzle spacing The factor to be programmed is the full, effective working width of the implement. NOTE: If an ACI is connected on a sprayer, the implement width is equal to the nozzle spacing, e.g. 0.5 metres, You must then programme the ACI input (number of nozzles per section).

  • Page 11: Metric/Imperial Selection

    SAM 400 SPEED-AREA-DISTANCE METER Metric/Imperial Selection Press and hold the CAL button while switching the instrument on. Select the channel. 4 indicator bars will appear showing the units currently selected (fig. 5). Use the small left and right buttons to select the units.

  • Page 12: Manually Calculating The Factor

    Carry out this test whenever soil conditions or wheel sizes change. (iv) If an RDS Radar sensor is installed, the Speed Sensor Factor is 0.008 m (or 0.312 inches). If the calibration factor works out at over 2.000 m (78.78 inches), consider fitting additional magnets.

  • Page 13: Number Of Sensor Magnets

    SAM 400 SPEED-AREA-DISTANCE METER Number of Sensor magnets The table gives the number of magnets required to enable a speed update of approximately once per second or faster on the display. Typical speed in normal operation: Tyre diameter up to 5mph...

  • Page 14: Set Forward Speed Alarm Thresholds

    SAM 400 SPEED-AREA-DISTANCE METER Set Forward Speed Alarm Thresholds Press and hold the button while switching the instrument on. channel (1) displays the Maximum speed alarm threshold (Output 2). The default is 50 (km/hr). Pressing the centre key selects the channel (2).

  • Page 15: Changing The Rpm Sensor Factor

    SAM 400 SPEED-AREA-DISTANCE METER Changing the RPM Sensor Factor Select the RPM channel ( Press and hold the CAL button while switching the instrument on until the instrument displays 'CAL.1'. Press the centre button to select channel 6. Use the '+' and '-' buttons to programme the new factor.

  • Page 16: Wiring Connections - Sam 400 (Without Wci/Aci)

    SAM 400 SPEED-AREA-DISTANCE METER Wiring Connections – SAM 400 (without WCI/ACI) A 12-way Qikmate to 8-way AMP interconnection cable Pt No. S/CB/327-1- 053 is supplied to connect to the sensors, power supply etc. S/CB/327-1-053 Please refer to the “Work measurement Installation”...

  • Page 17: Wiring Connections - Sam 400 (With Wci / Aci)

    SAM 400 SPEED-AREA-DISTANCE METER Wiring Connections – SAM 400 (With WCI / ACI) You will require the following cable in order to connect a WCI switch, ACI switch, or to utilise Outputs 1 and 2. Pt No. S/CB/327-1-063 (2 x 6-way AMP)

  • Page 18: Connections For Cable S/Cb/327-1-063

    SAM 400 SPEED-AREA-DISTANCE METER Connections for Cable S/CB/327-1-063 CONNECTOR – A TERMINAL COLOUR FUNCTION BLACK POWER SUPPLY 0V BLACK SENSOR 0V BLACK SENSOR 0V POWER SUPPLY +V O/P 1 TURQUOISE HIGH SPEED OUTPUT O/P 2 ORANGE MAX. SPEED OUTPUT CONNECTOR – B...
  • Page 19 SAM 400 SPEED-AREA-DISTANCE METER Issue 1 20/12/05 Original Issue Issue 2 27/3/06 p.6 - added note ref. Security Link Wire p.15 - correction ref. Labels Issue 3: 31/5/06 Changes to cover S/W WZ200-000 rev.6 p.15, 16 - Label A changed to show O/P 1 and 2 Issue 4 6/7/07 Correction p.5, p15...
