Summary of Contents for Messoa SLI080
- Page 1 User Manual High Power Intelligent IR Illuminator ZEIM-4000643G 080 A.4...
-
Page 2: Safety Information
Safety Information Before using the product, please carefully read through the safety information and operation instructions. Take note of the “Caution” labels: Please follow the “Caution” labels on the product and User Manual to ensure operation safety. Cleaning: Before cleaning the unit, please first unplug the power. Peripheral/accessories: Do not place the unit on an unstable cart, tripod, or on a tabletop as personal injury and damage to the unit may occur due to a fall. - Page 3 12. Safety inspection: After the unit maintenance has been completed, the mainte- nance staff must perform safety inspection to ensure proper operation. 13. The IR illuminator contains ultra-intense LED emitters. DO NOT STARE AT THE LED SOURCE. 14. Never open or remove the front cover while the IR illuminator is under operation. Qualified personnel must perform all maintenance.
- Page 4 CE Compliance The IR illuminator has been tested for compliance with CE (Conformité Européenne) standards and guidelines, and has been found to conform to applicable CE standards, specifically • EN61000-6-3 for generic emissions • EN50130-4 for immunity, • EN60598-1 for Luminaires •...
-
Page 5: Table Of Contents
Table of Contents 1. Introduction ..............6 1.1 Package Contents ..............6 1.2 Hardware Overview ..............6 1.2.1 Dimensions ................6 1.2.1 Part Names ................7 2. Installation ..............10 2.1 Making the Connection ............10 2.2 Traffic Camera Application ............13 3. Remote Control ..............15 4. -
Page 6: Introduction
1. Introduction 1. Introduction 1.1 Package Contents The package includes these items: High Power Intelligent IR Illuminator „ CD-ROM (Remote Control Utility and User Manual) „ User Manual „ Hexagonal Wrench „ 2-pin Screw Terminal Block „ Video Sync Link Cable (optional) „... -
Page 7: Part Names
1. Introduction 1.2.1 Part Names Photocell Sensor Pressure equalization valve D/N Status For D/N status AC24V/DC12V+ (Blue) Output AC24V/DC12V- (Black) RS485- (White) RS485+ (Orange) TELE/VIDEO LED Failure_COM (Red) For telemetry IR LED Failure_NO (Green) ON/OFF control LED Failure_NC (Blue) and Video input Controls Mounting Loosen the 4 screws... - Page 8 1. Introduction Controls Loosen the four screws securing the panel to ex- Diffuser Position Control pose the controls and make required adjustments. 4 (ON) 3 (3/4 ON) CAUTION ! 2 (2/4 ON) Important: After setup, make sure to lock all four 1 (1/4 ON) Please lock all four screws screws tightly in sequence as indicated in the cau-...
- Page 9 1. Introduction LED Power: Using a screwdriver, loosen the screw and turn it clockwise to increase the power or counter-clockwise to decrease the power. LED Power Sensitivity: The illuminator will automatically turn on when light- ing condition become dark and off when lighting conditions become light.
-
Page 10: Installation
2. Installation 2. Installation 2.1 Making the Connection It’s suggested to set up the illuminator at night for optimized illumination results. Attach the illuminator to desired location. Use appropriate mounting bracket as required. Using a wrench, loosen the side bolts and then tilt the illuminator to desired angle. Carefully tilt the illuminator until the satisfied angle is achieved. - Page 11 2. Installation Video Sync Cable Alarm IN Pin #5 Pin #6 VIDEO OUT POWER IRIS AC24V Pin #5 Pin #6 GND B/W SETUP DC12V Video Sync Cable • If using the camera as the master: Terminate the other end of the video sync cable (Pin #3&4) to the camera’s Alarm Out connectors.
- Page 12 2. Installation Optionally connect the RS-485 signals to a computer for remote control. RS-485 +/- If you are going to chain multiple illuminators, use the D/N status cable to make the connection. D/N Status Connector Pin Assignment Name VIDEO D/N Status Please refer to the diagram below for connection and make required DIP Switch settings.
-
Page 13: Traffic Camera Application
2. Installation 2.2 Traffic Camera Application Connection for D/N and Video Sync (Illuminator as master) If you are going to connect the illuminator to a traffic camera, use a video sync cable (op- tional) to make the connection as below: GND &... - Page 14 2. Installation Chaining up to 3 illuminators with traffic camera When connecting the illuminator to a traffic camera, it’s allowed to chain up to 3 illumi- nators to sync the 3 illuminators’ D/N status and shutter speed with the camera. Refer to the diagram below for connection and make required DIP Switch settings.
-
Page 15: Remote Control
3. Remote Control 3. Remote Control The CD comes with a utility to remotely configure the illuminators. The utility required no installation. Simply copy the executable file to your computer and double-click the file to launch the utility. From the menu bar, click COM PORT and select a com port number according to your connection. - Page 16 3. Remote Control For your convenience, you can enter a descriptive name for each illuminator. To do so, click the Modify ID List to pop-up the dialog box. Click Start Scan to search for the connected illuminators. Then select the ID of target illuminator to modify the location name.
-
Page 17: Specification
4. Specification 4. Specification Electric LED array High efficiency surface mount power LED with advanced current limited integral control circuitry Beam Patterns 10°~50° 20°~60° 40°~80° 60°~100° Max distance 300m (984 ft) 240m (787 ft) 170m (558 ft) 130m (427 ft) Wavelength 850nm Even illumination... - Page 18 4. Specification Environment Operating Temperature -50 ~ +60ºC (-58ºF ~ 140 ºF) Operating Humidity 90% MAX Storage Temperature -50 ~ +60ºC (-4ºF ~ 140 ºF) Storage Humidity 70% MAX Protection IP68 Mechanison Dimension(W*L*H) 233 x 310 x 220 mm (9.17”x 12.2” x 8.66”) Weight (tentative) 5.6Kg (12.3lb)
- Page 19 4. Specification...
