  • Page 1 IR Bullet Network Camera NCR373 User Manual 201510 373 A1...

  • Page 2: Table Of Contents

    Table of Contents Product Overview Physical Characteristics Installation Package Content Installation 2.2.1 Checking Appearance 2.2.2 Mounting & Wiring 2.2.3 Safety Wire Preparation 2.2.4 Adjusting the Camera Position 2.2.5 Adjusting the Protection Shield Hood Connection Network Topology System Requirements Connecting Process 3.3.1 Default IP address 3.3.2 Connecting from a computer &...
  • Page 3 WARNING ● This camera operates at DC 20V only. ● Installation and service should be performed only by qualified and experienced technicians and comply with all local codes and rules to maintain your warranty. ● To reduce the risk of fire or electric shock, do not expose the product to rain or moisture. ●...

  • Page 4: Fcc Compliance Statement

    FCC Compliance Statement Information to the user: This unit has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 5: Product Overview

    Product Overview Physical Characteristics Unit: mm Figure 1 - 1: Physical Dimension & Pictorial Index Table 1 - 1: Pictorial Index Definition Name Description Insert an Ethernet cable into the port for network connection and DC 20V power RJ-45 Ethernet / DC Power supply.
  • Page 6 Figure 1 - 2: Internal Interface Pictorial Index Interface Description LED Indicators Blue & Red It symbolizes network data has been under transmission. Micro SD card slot Insert a micro SD card into the slot for recording and file storage. Press the button for 6 seconds to restore to the factory default settings.

  • Page 7: Installation

    Installation Package Content Check if everything in the packing box matches to the order form and the packing slip. All items listed below should be included in the packing box. • Network IR Bullet Camera * 1 • Printed Quick Guide * 1 •...

  • Page 8: Mounting & Wiring

    2.2.2 Mounting & Wiring Step 1. Mounting Preparation • Use the guide pattern to mark out and prepare a mounting area. Place the supplied guide pattern on a mounting surface. Drill 6 mm (0.25”) outer holes x 3 at the mounting surface corresponding to the 3 indicated positions for plastic anchors.
  • Page 9 Step 3. Wiring the Camera While mounting the camera, pass the Ethernet RJ-45 Port cable, which penetrates from the mounting bracket, through the hole of mounting surface or place it by the side hole of the mounting bracket as shown in Figure 2-3 depending on your different applications.

  • Page 10: Safety Wire Preparation

    2.2.3 Safety Wire Preparation If you possess a safety wire (fall prevention wire, not supplied), connect the safety wire with one end to the mounting surface and the other end to the safety-cord screw of the camera. Safety wire Safety-cord screw of the camera Figure 2 - 5: Mounting the Camera Depending on the material of mounting surface, different screws and anchors than those supplied may be required.

  • Page 11: Adjusting The Camera Position

    2.2.4 Adjusting the Camera Position • Pan Adjustment (A) Rotate the A joint to adjust the camera horizontally for applying to a variety of applications. • Tilt Adjustment (B) Tilt the B joint to adjust the camera vertically for applying to varied applications. •...

  • Page 12: Adjusting The Protection Shield Hood

    2.2.5 Adjusting the Protection Shield Hood This camera is designed with capability to operate under rugged environments and thus will possibly be subject to influences from sunlight or rain. Protection shield hood is consequently coated on the camera to prevent from those outside effects. To adjust the protection shield hood, first loose the 2 cross screws above the hood followed by moving the protection shield hood forward or backward till a desired position based on your need of different applications.

  • Page 13: Connection

    Connection Network Topology The camera, which is equipped with Ethernet RJ-45 network interface, can deliver live view image in real time via both Internet and Intranet manners. Please refer to the skeleton drawings shown below for understanding. Figure 3 - 1: Network Topology System Requirements Below table lists the minimum requirement to implement and operate the camera.

  • Page 14: Connecting Process

    Connecting Process 3.3.1 Default IP address Since this is a network-based unit, an IP address must be assigned at the very first. The unit’s default IP address is 192.168.1.30 and sub mask is 255.255.255.0. However, if you have a DHCP server in your network, the unit would obtain an IP address automatically from the DHCP server so that you don’t need to change the camera’s IP address.
  • Page 15 Viewing Preparation Images of the unit can be viewed through Microsoft Internet Explorer 8 or above. Before viewing, follow these steps to enable the display. Enable Cookies as instructions below In Internet Explorer, click Internet Options on the Tools menu. ...
  • Page 16 Scroll down to the ActiveX controls and plug-ins radio buttons and set as follows:  【 Download signed ActiveX controls 】 Prompt (recommended) 【 Download unsigned ActiveX controls 】 Prompt 【 Initialize and script ActiveX not marked as safe for scripting 】 Prompt Figure 3 - 4: Security Settings 2/4 【...
  • Page 17 【 Run ActiveX controls and plug-ins 】 Enable 【 Script ActiveX controls marked safe for scripting* 】 Enable Figure 3 - 6: Security Settings 4/4 Press OK to save the settings.  Close all Microsoft Internet Explorer Windows and restart a new window. This will allow the new settings taking effect. ...

  • Page 18: Ip Finder

    Please note that IP Finder works only on Microsoft Windows XP, Microsoft Windows Vista, and Microsoft Windows 7. Steps to get the utility program running are listed below. Download IP Finder from MESSOA Website to the computer. Double click on IPFinder.exe in the IP Finder folder, and the IP Finder window should pop out.

  • Page 19: Administration And Configuration

    Administration and Configuration Live View Figure 4 - 1: First Login Page After accessing and login to the IP address of the camera, the screen will be shown as the screenshot above. There’re 2 main options on the upper left side: “Live View” and “Configuration” and a left dropdown menu for user interface language changing.
  • Page 20 The following icons within the table, which are in the left-side window and on the top of Live View screen, are for several functions activation and statuses indication. Please refer to the detailed definitions below for more understanding. Icon Definition The “Snapshot”...

  • Page 21: Configuration

    Configuration After clicking the “Configuration” option, the screen will be shown as below with several menu options for users to configure on the left side. We will thoroughly introduce them one by one in the following chapters. Figure 4 - 3: Configure 4.2.1 Encode Figure 4 - 4: Encode By default, there are up to 3 profiles to be selected from and each profile contains 3 streams individually for further...
  • Page 22 Table 4 - 2: Edit Profile Options Item Option Description QuadVGA(1280×960) is the highest resolution QuadVGA(1280×960) , HD(1280×720), (320x176) is the lowest resolution. Compression SVGA(800×600), VGA(640×480), VGA Note: Wide(640x360), QVGA(320x240), (320x176) Stream 1 must be always ON. H264 only supports SVBR and its maximum bit rate is 8M. MJPEG: Each video frame is individually compressed as single jpeg image with full-scale contents itself and can be retouched freely with ease.
  • Page 23 Table 4 - 3: Correlations of Resolution/Streams/FPS/Codecs – NTSC/PAL Stream 1 (H.264/ Stream 2 (H.264/MJPEG) Stream 3 (H.264/MJPEG) MJPEG) 1280x960@30/25fps 1280x960@30/25fps 1280x720@30/25fps 1280x720@30/25fps 800x600@30/25fps 800x600@30/25fps 640x480@30/25fps 640x480@30/25fps 1280x960@30/25fps 640x360@30/25fps 640x360@30/25fps 320x240@30/25fps 320x240@30/25fps 320x176@30/25fps 320x176@30/25fps 1280x720@30/25fps 1280x720@30/25fps 800x600@30/25fps 800x600@30/25fps 640x480@30/25fps 640x480@30/25fps 1280x720@30/25fps 640x360@30/25fps 640x360@30/25fps...

  • Page 24: Image

    4.2.2 Image Exposure This section mainly allows user to control the settings pertaining to exposure mode and day night modes. Figure 4 - 5: Exposure Basic Settings ● Exposure Mode There are 4 modes to select from as follows: • Auto: with certain pre-settings, the camera automatically determines the correct exposure for pictures without user input settings for further exposure before taking videos.
  • Page 25 ● BLC Set an area for Backlight Compensation. Backlight Compensation is a function that achieves the brightness of a selected area to optimal image level. This function is necessary when an auto iris lens tends to close quickly due to an intense light coming from back of object in the area wished to view, resulting in the area is too dark and difficult to see.

  • Page 26: White Balance

    ● Day Night Switch Control – Mode Set Day Night mode from 3 options, Auto, Color and B/W. When Color mode is selected, the camera is forced to stay in Color mode permanently. On the other hand, the camera keeps within black and white mode when B/W is selected. Auto simply let the camera to, based on different intensity of lights, switch between 2 modes automatically.
  • Page 27 Basic Setting Figure 4 - 9: Basic Settings ● Sharpness Increasing the sharpness value will sharpen the edges and small feature of viewing images. If the edges appear too smooth or blurred, increase the sharpness; otherwise, decrease the sharpness. Sharpness value can be set from 0 to 100. The 100 offers the sharpest image.

  • Page 28: Video

    4.2.3 Video Privacy Zone Privacy Zone enables user to black out a specific portion of the screen for privacy concern. There are up to 8 sets of privacy zones for users to define. After setting up a privacy zone, the live view image will appear a frame, whose color, size and position can be customized by user’s preference.

  • Page 29: Network

    4.2.4 Network General This section is for users to set detailed settings related to wired network condition for the camera. Figure 4 - 12: Network ● Basic Settings • Device Name: Input your preferred name for the camera.. • HTTP Port: This protocol allows for TCP protocol quality without having to open specific ports for streaming. Users inside a firewall can utilize this protocol to allow streaming data through.

  • Page 30: Ftp Server

    • Primary DNS: Same as the above. • Secondary DNS: Same as the above. • IPv6 Enable: Check the box to enable IPv6 protocol. • Accept IPv6 router advertisements: Check the box to activate RA (Router Advertisement) corresponding to RS (Router Solicitation) for IPv6 address designation.
  • Page 31 RTSP RTSP is a standard protocol for connecting a client to establish and control streaming data over the web. If you want to allow third-party devices or software to access video/audio streams from the IP camera over the network, you must configure the RTSP ports.
  • Page 32 ● Multicast URL Differing from URL, Multicast URL can transmit data from one host to a single host or to all hosts, thus consuming less network bandwidth with more flexibility. However, it is required to make sure if the peripherals connected with the camera are all compatible with Multicast in advance.
  • Page 33 ● SNMP V3 SNMP V3 provides more security features than SNMP v1/SNMP v2. Tick “ON” to enable the function. Input User Name for SNMP v3 first. Then select desired modes for “Authentication” with “Privacy” and enter passwords paired with both protocols individually.
  • Page 34 Firewall Under this menu, users can manually define several IP addresses to be allowed or denied to access camera. Figure 4 - 17: Firewall Settings ● Allow: Select this option to make inputted IP addresses allowed to access IP camera. ●...
  • Page 35 LDAP For accessing and maintaining distributed directory information services over an Internet Protocol network, the Lightweight Directory Access Protocol (LDAP), an open, vendor-neutral, industry standard application protocol, have a major role in both intranet and internet applications to facilitate information sharing between devices. Figure 4 - 19: LDAP Settings ●...
  • Page 36 Secure Sockets Layer (SSL), the standard security technology for establishing encryption, allows sensitive information such as login credentials to be transmitted securely. Figure 4 - 20: SSL Settings ● Self Signed Self-signed certificate is a private own key that has no connection with person or organization that perform authorized certificate signing procedure.

  • Page 37: System

    4.2.5 System Date & Time Figure 4 - 23: Date & Time Settings ● Current Server Time The current date/time is displayed here. ● Synchronization Mode There’re 3 modes for users to set date/time. • Sync With Manual: Manually set date and time individually. •...
  • Page 38 Firmware The information about the camera are explicitly written under this page. Also, users can manually update System Firmware if available. All motions of camera will be stopped during the firmware update. Please close any other screens before firmware update. Never disconnect power or LAN cable during the updating process. It takes approximately 3 minutes for the unit to reboot after firmware update process.
  • Page 39 This section allows user to enable OSD (On Screen Display) settings. In addition, it extends the OSD function to accord with the occurrence of events. Figure 4 - 26: OSD Settings ● Basic Settings There are up to 2 sets of OSD settings can be enabled concurrently as the following details: •...
  • Page 40 Event Search This section helps user to quickly learn more about the event the camera detected. Select the Event type and Time, click Search and all the related event will show in the Event List. Also, the Analysis area will show a quantitative analysis of the searched events with exact number and a pie chart.

  • Page 41: Account

    4.2.6 Account Account Settings Figure 4 - 28: Account Settings ● User Levels • Admin: The highest privileged control for the camera is “Admin” level, which can handle both live view and all the configuration settings. The default username and password for Admin are “admin” and “1234” respectively. •...
  • Page 42 ● Modify & Delete Users: Figure 4 - 30: Modify & Delete Admin/Operator/User • Delete: Choose one of the users from the list and then click “Delete” to remove it instantaneously. (The default Admin is not available to be deleted.) •...

  • Page 43: Event Source

    4.2.7 Event Source Defocus This function is designed to establish related actions when the camera is subject to the event of defocus. Figure 4 - 31: Defocus Settings ● Basic Setting • Enable: Check the box to enable the function. ●...
  • Page 44 ● Arming Schedule Setting Under this section, user can freely set up an ideal combination to record defocus events. The following table includes 7 days a week from the upper Monday to the lower Sunday with the hour group from the left 00 to the right 24. Click the “Edit” button at the upper-left corner to enter the setting page.
  • Page 45 Motion This function is designed to establish related actions when the camera detects motion issues. A maximum of 4 sets of motion detection areas can be customized by users. Figure 4 - 34: Motion Detection Settings ● Motion Zone Area Setting •...
  • Page 46 ● Arming Schedule Setting Under this section, user can freely set up an ideal combination to record motion events. The following table includes 7 days a week from the upper Monday to the lower Sunday with the hour group from the left 00 to the right 24. Click the “Edit” button at the upper-left corner to enter the setting page.
  • Page 47 Network This function is designed to establish related actions when the camera is subject to network conflict or network lost events. Figure 4 - 37: Network Event Settings ● Wire Network Issues • Network Lost: Check the box to enable the detection of network lost. When the camera loses internet access, the network lost event will be detected and recorded.
  • Page 48 Schedule This function is designed to establish related actions for schedule recording. Figure 4 - 38: Schedule Recoding Settings ● Basic Setting • Enable: Check the box to enable schedule recording function. • Trigger Interval: This relates to the following handler actions. The available range is from 1 to 3600 seconds. For example, if enabling the “Snapshot –...
  • Page 49 ● Arming Schedule Setting Under this section, user can freely set up an ideal combination for schedule recording. The following table includes 7 days a week from the upper Monday to the lower Sunday with the hour group from the left 00 to the right 24. Click the “Edit” button at the upper-left corner to enter the setting page.
  • Page 50 Tamper This function is designed to establish related actions when the camera is subject to tamper events. Figure 4 - 41: Tamper Detection Settings ● Basic Setting • Enable: Check the box to enable the tamper detection. • Sensitivity: Set the sensitivity for tamper detection. High stands for that camera is prone to be triggered with slight tamper issue, while Low means that camera is triggered with only major tamper issue.
  • Page 51 After clicking “Edit”, the prompt setting page will be shown as follows. User is able to individually establish up to 3 sets of time range for each day, where start and end time can be separately defined. Check the box at the right side to concretely enable the defined time range followed by clicking “Apply”...

  • Page 52: Event Handler

    4.2.8 Event Handler Email This section is designed to set up detailed settings for email notification when events occur. Make sure you have enabled email sending function in each event section in advance. Figure 4 - 44: Email Record Setting ●...
  • Page 53 ● E-mail Address List: This function is designed to notify multiple users via email when events occur. Figure 4 - 45: Email Address List • Check “Enable” to send email to the selected address. • Email Address: Input an email address to which events will be sent. There’re maximum 10 email addresses can be defined here.
  • Page 54 Record Setting This section is designed to set up detailed settings for video recording. Make sure you have enabled recording function in each event section in advance. Figure 4 - 47: Record Setting ● Basic Setting • Record Type: Select the recording content. Video: camera will only record the video information . Audio and Video: camera will record both audio and video.
  • Page 55 Snapshot This section is designed to set up detailed settings for snapshot capture when events occur. Make sure you have enabled Snapshot function in each event section in advance. Figure 4 - 49: Snapshot Setting ● Basic Setting • Pre Event Capture Count: Set a number of snapshots to be captured prior to an event. •...

  • Page 56: Appendix: Specifications Of Ir Bullet Network Camera

    Appendix: Specifications of IR Bullet Network Camera Video Sensor Type 1/3" image sensor optimized for low-light performance Active Pixels 1305 x 977 (HxV) Compression H.264 / Motion JPEG Streaming Triple simultaneous streams Resolution 1.3MP(1280x960), HDTV 720P(1280x720), 800x600, 640x480, 640x360, 320x240, 320x176 Max.
  • Page 57 -40°C ~ 50°C (-40°F ~ 122°F) Operating Humidity 10~ 90% RH Storage Temperature -40°C ~ 60°C (-40°F ~ 140°F) Regulatory Approvals CE, FCC, RoHS Order Information Model No. NCR373-N1-MES Note: Product specifications and pictures are subject to change without prior notice.
