  • Page 1 CONFIDENTIAL This document contains Nokia confidential material. This material cannot be shared except with persons that have a valid business reason to read this content. You are personally responsible to ensure recipients of this document are aware of information handling guidelines.
  • Page 2 PERFORMING ANY MECHANICAL REPAIR ON SERVICE LEVEL 1&2! More More Assembly hints Solder components Service devices More More More Product controls and interfaces Service concept Phone reset More More More ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 3 Service Manual Level 1 and 2 Version history Nokia XL Dual SIM RM-1030, RM-1042 Version 1.0 Version Date Description 29.04.2014 First published version ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 4 SCREW TORX+ SIZE 4 M1.4 X 3.55 I0022 SCREW TORX+ SIZE 4 M1.6 x 4.55 B-COVER I0021 I0023 Only available Not reuseable Repair/swap as assembly after removal only in level 3 ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 5 RM-1030, RM-1042 Version 1.0 1) For disassembling you need the Nokia Standard toolkit version 2. You will also need an AV jack. 2) Protect the A-COVER with protective film. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 6 3) Release the B-COVER by pushing down the bottom corners as shown. 4) Remove the B-COVER. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 7 5) Unscrew the four Torx+ size 4 screws in the order shown. Do not use them again. Discard them. 6) Unscrew the eight Torx+ size 4 screws in the order shown. Do not use them again. Discard them. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 8 7) Start releasing the D-COVER by first releasing the two shown clips on the left side of the device with the SRT-6. Start from the top. 8) Then slide the SRT-6 along the bottom end and release the two shown clips. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 9 9) Then open the two shown clips on the right side. 10) Then slide the SRT-6 along the top end and release the three shown clips. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 10 11) Fold open the D-COVER as shown. Be careful not to damage the flexes. 12) Open the SIDE KEY FLEX connector with the SS-93. Be careful not to damage the connector or any components nearby. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 11 13) Open the DISPLAY and TOUCH PANEL connectors. Be careful not to damage the connectors or any components nearby. 14) Remove the D-COVER. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 12 Do not use the IHF FLEX again. Discard it. 16) Release the EARPIECE with the dental tool and remove it with tweezers. Do not use it again. Discard it. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 13 17) Release one part of the SIDE KEY FLEX with the dental tool and remove it with tweezers. 18) Open the CAMERA connector with the SS-93. Be careful not to damage the connector or any components nearby. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 14 19) Grab the CAMERA RUBBER with tweezers and pull out the CAMERA including the CAMERA RUBBER. 20) Remove the CAMERA RUBBER from the CAMERA with tweezers. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 15 21) Start releasing the TOP FLEX by first opening the TOP FLEX connector with the SS-93. Be careful not to damage the connector or any components nearby. 22) Then release the AV connector with an AV jack. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 16 23) Then release the rest of the flex gently with tweezers. 24) Then release the vibra with the SS-93. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 17 25) Finally release the sensor with the dental tool. Remove the TOP FLEX with tweezers. 26) Remove and discard the FLASH LENS ADHESIVE with the dental tool. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 18 27) Remove and discard the VIBRA ADHESIVE with tweezers. 28) Remove and discard the SENSOR SUPPORT GASKET with the dental tool. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 19 29) Open the FRONT CAMERA connector with the SS-93. Be careful not to damage the connector or any components nearby. 30) Release the FRONT CAMERA with the SS-93 and remove it with tweezers. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 20 31) Remove and discard the FRONT CAMERA GASKET with the dental tool. 32) Release the three shown clips holding the ENGINE BOARD with the SS-93. Start from the top. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 21 33) Remove the ENGINE BOARD. 34) Release the PMU SHIELDING LID with the dental tool. Be careful not to damage any componets nearby. Remove and discard the PMU SHIELDING LID with tweezers. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 22 35) Release the IHF SPEAKER with the sharp end of the SS-93 and remove it with tweezers. 36) Remove and discard the SPEAKER GASKET with the dental tool. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 23 37) The Nokia XL Dual SIM disassembly procedure is complete. -END OF DISASSEMBLY- ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 24 1) Fasten the eight Torx+ size 4 screws in the order shown to the torque of 15 Ncm. 2) Fasten the four Torx+ size 4 screws in the order shown to the torque of 12 Ncm. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 25 GSM Antenna spring gnd spring ANT102 ANT101 BT/WLAN Antenna spring ANT104 ANT103 U102 FIL1301 U1101 CN101 GPS Antenna BT/WLAN Display GSM Antenna spring Antenna filter Filter BL driver coax connector ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 26 D1211 D1212 D1206 D1507 D1506 D1504 D1205 Diode Diode Diode Diode Diode Diode Diode Diode Diode BOTTOM diode diode D1503 D1505 D1501 D1103 B1101 Barrier Ferrite Diode diode coil ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 27 For more information, refer to the Service Bulletin (SB-011) on Nokia Online. Supplier or manufacturer contacts for tool re-order can be found in “Recommended service equipment” document on Nokia Online. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 28 7 — Microphone 8 — Micro-USB connector 9 — Camera flash 10 — Camera 11 — Volume keys 12 — Power/Lock key 13 — Loudspeaker 14 — Antenna area ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 29 Service Manual Level 1 and 2 Service concept Nokia XL Dual SIM RM-1030, RM-1042 Version 1.0 Flashing concept Service CA-101 software Product specific battery Transceiver ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
  • Page 30 The hardware reset does not remove any consumer data. To perform a hardware reset, remove the battery and wait for one minute before reinserting it. Boot up the phone normally. ©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
