Page 1: Washing Machine
WA85M4 Washing Machine user manual This manual is made with 100% recycled paper. imagine the possibilities Thank you for purchasing this Samsung product. M-PJT_DC68-03032E-04_Philippines_EN.indd 1 2014/4/30 10:42:18... - Page 2 • Artificial intelligence It’s artificially intelligent, can inspect weight of clothes and select the water level automatically according to the load capacity. • Stainless diamond drum Its diamond-like rhombus design can relieve the impulsive force of water effectively and reduce the damage to clothes.
-
Page 3: Safety Information
It’s your responsibility to use common sense, caution, and care when installing, maintaining, and operating your washing machine. Samsung is not liable for damages resulting from improper use. IMportAnt SAFety SyMbolS And precAutIonS... - Page 4 - Failure to do so may result in lightning strike. Do not use an extension cord or double adapter. If the washer makes strange noise, smell or smoke, unplug it promptly and call Samsung Customer Service. Do not use the strong acid cleaning agent. 4_ safety information M-PJT_DC68-03032E-04_Philippines_EN.indd 4...
- Page 5 When using hot water in washing, please make sure that the water should not exceed 50°C. - Otherwise, plastic parts may deform or be damaged, and clothes may deform, shrink or discolor. When the washer is spinning and rotating, please don’t open the washer lid or touch the clothes.
-
Page 6: Table Of Contents
contents seTTING Up yOUR WAshING Unpacking your washing machine mAChINe Description of parts Accessories Selecting a location Adjusting the levelling feet Connecting the water supply hose Connecting the drain hose How to change the drain hose direction Assembling the Rat Protection Panel WAshING A lOAd Of Using the control panel lAUNdRy... -
Page 7: Accessories
Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping, or if you do not have all of the parts, contact your Samsung dealer. deScrIptIon oF pArtS Water supply hose... -
Page 8: Adjusting The Levelling Feet
setting up your washing machine AdjuStIng the levellIng Feet 1. Select a location for placing the washing machine. Maintain at least 10cm between the washer and the wall if it is High placed near wall. 高 低 2. Adjust the legs on feet for levelling. Diagonal 对角线... -
Page 9: Connecting The Drain Hose
connectIng the drAIn hoSe • Decide direction of the drain hose • Insert end of the drain hose into the drain-outlet. Cautions when inserting the drain hose: Don’t exceed more than Be careful to drain water The doorsill shoudn’t be 3m when the drain hose is out at the end of the drain more than 5cm. used by connecting whth hose. -
Page 10: Washing A Load Of Laundry
washing a load of laundry uSIng the control pAnel Display current program When the washer operating, the current program will flicker. dIsplAy pANel Display current water level/ Remaining time Display current water level or the remaining time to finish washing. 5 s. later After the washer starts operating, After 5 seconds , the display the display show current water... -
Page 11: Preparing For Clothes Before Washing
prepArIng For clotheS beFore WAShIng Follow these simple guidelines for the cleanest laundry and the most efficient wash. emptying pockets Before each wash, check and empty the pockets! Hairpins, coins and other hard substances may cause damages to clothes and the washer. Cashmilon and those garments having big volume and lightweight may rise and cause damages to the clothes and problems to the machine. Use the laundry net (to be purchased additionally) or wash them separately. -
Page 12: Wash Course
washing a load of laundry WASh courSe Step 1: put the laundry into the washer 1. Open the washer lid . 2. Load your laundry into the washing machine. • Put the laundry in evenly. • Do not overload the washing machine. • Cashmilon and those garments having big volume and lightweight may rise and cause damages to the clothes and problems to the machine. Use the laundry net or wash them separately. -
Page 13: Step 4: Select The Washing Program
WASh courSe Step 4: Select the washing program Press program button to select the washing program you need, and lamp of the selected program lights up Fuzzy Quick delicate heavy Soil For most For lightly soiled Use for wash Use for wash frequently used garments that you fine laundry Stained or heavy washing program. -
Page 14: Step 6: Start Washing Clothes
√ √ √ √: ON; X: OFF; -: Unavailable Max load heavy pROGRAm fuzzy Quick delicate Wash Rinse spin soil Max load WA85M4 6.5kg 4.0kg 4.0kg 6.5kg 6.5kg 6.5kg 6.5kg When the cycle is finished After the total cycle has fifinished, the display will flicker “0” for 30 seconds, and disappear automatically 30 seconds later. 1. Open the lid, and remove laundry. After washing has finished, take out the clothes in time; Otherwise, they will be crumpled. In order to keep the tub dry, keep the lid open for about 1 hour, and close the lid after the washer is dried. -
Page 15: Cleaning Supply Connector Filter
cleaning and maintaining your washing machine cleAnIng the exterIor 1. Wipe the washing machine surfaces, including the control panel, with a soft cloth using a nonabrasive household detergent. 2. Use a soft cloth to dry the surfaces. 3. Do not pour water onto the washing machine. cleAnIng the FIlter 1. -
Page 16: Following Phenomena Are Not Failures
troubleshooting troubleShootIng Washing machine won’t Water dose not drain - Is the drain hose down? work - Is the drain hose frozen? - Is the washer plugged in? - Is the drain hose clogged? - Is the power cut off? - If the water dose not drain - Is the fuse operating? in 15 minutes, the display - Is the water tap opened? -
Page 17: Specifications
SpecIFIcAtIonS MAx. MASS oF dry WA85M4 6.5kg cloth In kg StAndArd WAter level WASH 330W poWer conSuMptIon SPIN 280W dIMenSIonS(mm) W528xD545xH895 WAter uSAge 156L WeIght 26kg WAter preSSure 0.03~1MPa SpIn Speed 715rpm WAShIng type Stirring Type troubleshooting _17 M-PJT_DC68-03032E-04_Philippines_EN.indd 17 2014/4/30 10:42:24... - Page 18 memo M-PJT_DC68-03032E-04_Philippines_EN.indd 18 2014/4/30 10:42:24...
- Page 19 memo M-PJT_DC68-03032E-04_Philippines_EN.indd 19 2014/4/30 10:42:24...
- Page 20 QUESTIONS OR COMMENTS? Country CAll OR VIsIT Us ONlINe AT 1-800-10-7267864 [PLDT] PHILIPPINES 1-800-8-7267864 [Globe landline and Mobile] www.samsung.com/ph/support 02-4222111 [Other landline] Code No. DC68-03032E-04_EN M-PJT_DC68-03032E-04_Philippines_EN.indd 18 2014/4/30 10:42:24...
