- Page 1 Washing Machine User manual WA85R6350B* WA6000R_DC68-04120D-00_EN.indd 1 2020-03-17 AM 10:33:40...
-
Page 2: Table Of Contents
Contents Safety information What you need to know about the safety instructions Important safety symbols Important safety precautions Installation What’s included Installation requirements Step-by-step installation Before you start Detergent guidelines Smart Check Laundry guidelines Operations Control panel Simple steps to start Auto cycles Special features Maintenance... -
Page 3: Safety Information
Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features. -
Page 4: Important Safety Precautions
Safety information These warning signs are here to prevent injury to yourself and others. Please follow them explicitly. After reading this manual, store it in a safe place for future reference. Read all instructions before using the appliance. As with any equipment that uses electricity and moving parts, potential hazards exist. To safely operate this appliance, familiarize yourself with its operation and exercise care when using it. - Page 5 5. The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be reused. 6. For washing machines having ventilation openings in the base, the installation instructions shall state that the openings must not be obstructed by a carpet.
- Page 6 Safety information Critical installation warnings WARNING The installation of this appliance must be performed by a qualified technician or service company. • Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. Plug the power cord into a wall socket that meets local electrical specifications.
- Page 7 Failure to do so may result in electric shock. If the appliance generates a strange noise, a burning smell, or smoke, unplug the power plug immediately and contact your nearest Samsung Customer Service. • Failure to do so may result in electric shock or fire.
- Page 8 • In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from doing it. Unplug the power plug when the appliance is not being used for long periods of time or during a thunder or lightning storm.
- Page 9 Using the product for business purposes qualifies as a product misuse. In this case, the product will not be covered by the standard warranty provided by Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse.
-
Page 10: Installation
What’s included Make sure all the parts are included in the product package. If you have a problem with the washing machine or the parts, contact a local Samsung customer center or the retailer. 01 Door 02 Detergent drawer... - Page 11 NOTE • Availability of parts with an asterisk (*) depends on your model. • Door: Make sure to keep the door closed while the washing machine is operating. • Lint filter: This collects lint that builds up from the laundry being washed. •...
-
Page 12: Installation Requirements
Installation Installation requirements Electrical supply and grounding Drain • Make sure the drain hose is not clogged. WARNING • We recommend a standpipe in height • AC 220-240 V / 50 Hz fuse or circuit of 90-100 cm. The drain hose must be breaker is required. -
Page 13: Step-By-Step Installation
Step-by-step installation STEP 1 Select a location Location requirements: Solid, level surface without carpeting or flooring that may obstruct ventilation • Away from direct sunlight • • Adequate room for ventilation and wiring • The ambient temperature is always higher than the freezing point (0 ˚C) •... - Page 14 Installation STEP 2 Adjust the levelling feet Unpack the product package. 1. Gently slide the washing machine into position. Excessive force may damage the levelling feet (A). 2. Level the washing machine by manually adjusting the levelling feet. 3. When levelling is complete, tighten the nuts (B) if provided (some models may not have the nuts).
- Page 15 STEP 3 Connect the water hose Connect the water hose to the water tap. 1. Remove the adaptor (A) from the water hose (B). 2. Use a Phillips screwdriver to loosen four screws on the adaptor. 3. Hold the adaptor and turn part (C) in the arrow direction to loosen it by 5 mm (*).
- Page 16 Installation 6. While holding down part (D), connect the water hose to the adaptor. Then, release part (D). The hose fits into the adaptor with a clicking sound. 7. Connect the other end of the water hose to the inlet valve on the back of the washing machine.
- Page 17 WARNING Stop using the washing machine if there is a water leak, and contact a local Samsung service center. Otherwise, this may cause electric shock. CAUTION Do not stretch the water hose by force. If the hose is too short, replace the hose with a longer, high-pressure hose.
- Page 18 Installation STEP 4 Position the drain hose General type 1. Press and hold down the joint ring, and insert it into the drain hose. 2. Insert the drain hose into the drain outlet. Make sure to connect them firmly using the joint ring. The drain hose is extensible.
- Page 19 Pump type (Applicable models only) 1. Open the hose cap (A), and insert the drain hose. Tighten the drain hose using the joint ring. NOTE • The position (side or rear) of the drain outlet depends on the model. • Availability of the hose cap depends on the model.
- Page 20 Installation CAUTION • Do not exceed 3 m (*) for the total length of extended hoses. • Do not let the drain hose run over doorsills that protrude 5 cm (**) or more from the floor. • Do not run the drain hose under the bottom of the machine.
-
Page 21: Before You Start
Before you start Detergent guidelines To add a laundry-specific detergent, follow these steps: 1. Open the door then the Built-in sink to reveal the tub. 2. Locate the detergent drawer, and slide it open. 3. Apply powder detergent as recommended by the manufacturer. Do not exceed the max line that is marked on the wing distributor. -
Page 22: Smart Check
Before you start Smart Check To enable this function, you must first download the Samsung Washer app at the Play Store or the Apple Store, and install it on a mobile device featuring a camera function. The Smart Check function has been NOTE optimized for Galaxy &... -
Page 23: Laundry Guidelines
Laundry guidelines Checkpoints • Check for stains or dirt. Apply a little detergent to a white towel. Rub the white towel and the dirty clothes together to transfer the dirt or color to the white towel. Before washing, pre-treat the sleeves, collars, dress hems, and pockets by brushing with •... - Page 24 Before you start STEP 1 Sort Sort the laundry according to these criteria: • Care Label: Sort the laundry into cottons, mixed fibres, synthetics, silks, wools, and rayon. • Color: Separate whites from colors. • Size: Mixing different-sized items together in the tub improves the washing performance. •...
- Page 25 CAUTION Make sure to soak inflatable items (such as blankets, and cotton-filled or microfibre quilets) in water before you run a cycle. • Inflatable items may cause damage to the laundry or the machine during the wash or drying process. •...
- Page 26 Before you start STEP 4 Prewash (if necessary) • To remove stains and dirt on collars, sleeves, hems, and pockets, apply detergent lightly and brush off. • Use powder or liquid detergents. Do not use soap, as this may remain on the tub after washing.
- Page 27 STEP 6 Apply a proper detergent type The type of detergent depends on the type of fabric (cotton, synthetic, delicate items, wool), color, wash temperature, and degree of soiling. Always use “low suds” laundry detergent, which is designed for automatic washing machines. CAUTION •...
-
Page 28: Operations
Operations Control panel Press the button repeatedly to select a desired cycle listed above each button. For more information, see the Cycle overview section on page 01 Cycle Panel • Cycle 1: COTTON, SUPER CLEAN, WATER SAVING, COLORS / DARKS •... -
Page 29: Simple Steps To Start
Press and hold to start an operation, or press to stop an operation 12 START/PAUSE temporarily. Simple steps to start 1. Press POWER to turn on the washing machine. 2. Select a cycle in the cycle panel. 3. Change the cycle settings (water level, wash time, rinse count, and/or spinning time) as necessary. -
Page 30: Auto Cycles
Operations Auto cycles Cycle Description • For most fabrics including cottons, linens, and COTTON normally soiled items. • Select this if you want to produce powerful cleaning SUPER CLEAN performance. • Select this to wash effectively with a minimum amount of water. •... - Page 31 Cycle Description • For lightly soiled items that you want to finish QUICK WASH washing quickly. • For loads that need rinsing only or to add rinse-aided RINSE + SPIN fabric softener to. • Featuring an additional spin process to effectively SPIN remove moisture from laundry.
-
Page 32: Special Features
Operations Special features Child Lock Child Lock is designed to prevent accidents by children or infants, such as drowning. 1. Press POWER. 2. To activate the Child Lock, hold down Wash Time and Rinse Times simultaneously for 3 seconds. The indicator blinks. 3. - Page 33 Delay End You can set the washing machine to finish a cycle later. The hour displayed indicates the time the wash will finish. 1. Select a cycle. Then, change the cycle settings if necessary. 2. Press Delay End repeatedly until a desired end time is set. 3.
-
Page 34: Maintenance
Maintenance Cleaning Keep the washing machine clean to prevent deteriorated performance and to preserve its life cycle. Exterior • Clean the control panel with a soft, damp cloth. Do not use abrasive powders or cleaning pads. Do not spray cleaners directly on the panels. Tub Clean Regularly run this cycle to clean the tub and to remove bacteria from it. - Page 35 Lint filter 1. Press down the upper area of the filter case to remove. 2. Unlock the cover, and clean the filter with running water and a brush. 3. When cleaning is complete, close the cover and reinsert the filter case to the original position.
- Page 36 Maintenance Pump filter (applicable models only) 1. Put a floor-cloth or towel under the Pump filter. Turn the filter knob anticlockwise to remove. 2. Clean the filter with running water and a soft brush. 3. Reinsert the filter, and turn clockwise until it locks into position.
- Page 37 Mesh filter 1. Use pliers to pull out the mesh filter from inside the water inlet as shown. 2. Use a soft brush to clean the mesh filter with running water. 3. Reinsert the filter. Make sure it is tightened against water leaks. English 37 WA6000R_DC68-04120D-00_EN.indd 37 2020-03-17 AM 10:33:47...
- Page 38 Maintenance Detergent drawer 1. Open the door and then the Built-in sink to reveal the detergent drawer. 2. Slightly lift up the front edge of the drawer, and then slide it open. 3. Remove the wing distributor (A) and rinse cap (B) from the drawer. 4.
-
Page 39: Troubleshooting
Troubleshooting Checkpoints If you encounter a problem with the washing machine, first check the table below and try the suggestions. Problem Action Make sure you use rated power for the product. • Does not turn on. • Make sure the power cord is completely plugged in. •... - Page 40 Troubleshooting Problem Action • Make sure the washing machine is set on a level floor. If the floor is not level, use the levelling feet to adjust the washing machine. • Make sure the washing machine is not contacting any other object.
- Page 41 Problem Action • Fully open both water taps. • Make sure the temperature selection is correct. • Make sure the hoses are connected to the correct water taps. Flush water lines. • Disconnect the hoses and clean the screens. The hose filter screens may be clogged.
- Page 42 Excessive suds collect in recesses and can cause foul odors. Has odors. • Run cleansing cycles to sanitize periodically. Dry the washing machine interior after a cycle has finished. • If a problem persists, contact a local Samsung service center. 42 English WA6000R_DC68-04120D-00_EN.indd 42 2020-03-17 AM 10:33:47...
-
Page 43: Information Codes
Information codes If the washing machine fails to operate, you may see an information code on the display. Check the table below and try the suggestions. Code Action The WaterLevel sensor is not working properly. • Check WaterLevel Sensor wire harness. •... - Page 44 Troubleshooting Code Action Water is not draining. • Make sure the drain hose is not frozen or clogged. • Make sure the drain hose is positioned correctly, depending on the connection type. • Clean the debris filter as it may be clogged. •...
- Page 45 Display for additional rinsing. • Show additional rinsing is sensing unbalance. • Method of releasing the display. • Any key input. If any information code keeps appearing on the screen, contact a local Samsung service center. English 45 WA6000R_DC68-04120D-00_EN.indd 45 2020-03-17 AM 10:33:47...
-
Page 46: Specifications
Specifications Specification sheet Top loading washing machine Type WA85R6350B* Max load (kg) Washing Power consumption (W) AC 220-240 V / 50 Hz 360 - 420 Dimensions (mm) W 637 x D 701 x H 1075 Net weight (kg) 46.5 Water pressure (MPa (kg·f/cm 0.05 - 0.78 (0.5 - 8.0) Spin speed (rpm) NOTE... - Page 47 Memo WA6000R_DC68-04120D-00_EN.indd 47 2020-03-17 AM 10:33:47...
- Page 48 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT AUSTRALIA 1300 362 603 (Other) www.samsung.com/au/support NEW ZEALAND 0800 726 786 (All Product) www.samsung.com/nz/support DC68-04120D-00 WA6000R_DC68-04120D-00_EN.indd 48 2020-03-17 AM 10:33:48...
