Page 1: Quick Installation Guide
LevelOne WBR-3800 MobilSpot™ Portable Wireless Hotspot Quick Installation Guide... -
Page 2: Default Settings
Default Settings IP Address 192.168.0.1 User/Password password Wireless Mode Enable SSID WBR-3800 Security None This guide covers only the most common situations. All detail information is described in the user manual. - Page 3 To start installation, connect the WBR-3800 MobilSpot™ to your LAN network. Note: DO NOT connect the MobilSpot™ to power before performing the installation steps below. Step 1: Attach the antenna by screwing it in a clockwise direction. Once secured, position the antenna in an upwards...
- Page 4 Insert your 3G PC Card (either 16bit or 32bit) or plug a 3G USB Modem to the MobilSpot™. Note: The WBR-3800 MobilSpot™ is designed to work with either UMTS or EVDO and even HSDPA 3G modems. Please refer to your service provider for detailed feature information.
- Page 5 Step 3: Insert the Ethernet cable into the LAN Port on the back panel, and an available Ethernet port on the computer you wish to use to configure the unit. Note: After configuration is complete, you may wish to connect the LAN port to a Switch to share the Internet connection over wired network.
- Page 6 Step 4: Connect the Power Adapter The Power LED will turn ON to indicate power has been applied. Other LEDs will flash ON and OFF as the MobilSpot™ performs initialization and connection process. When complete, the following LEDs will illuminate green: 3G, WAN, LAN and WLAN.
- Page 7 Step 5: Using the Easy Setup Utility 1. Install the Easy Setup Utility from CD. After installation is complete, you can execute it from the Start Menu. 2. Configure the settings by the following steps. Select the Language, the click “Next.”...
- Page 8 3. You can select Quick Mode to run the Step-by-Step Wizard, or use Advanced Mode to access the Web Based Configuration of the router. Note: Please see User Manual for usage instructions 4. Check the items are completed before proceeding.
- Page 9 5. Enter your Wireless settings 6. Auto Detect your WAN Service.
- Page 10 7. In this case, DHCP WAN Type is detected. 8. Easy Setup is complete. 9. Click “ Finish” to complete the installation.
