Page 1: Quick Installation Guide
LevelOne WBR-6804 150Mbps Wireless Dual-WAN 3G Router Quick Installation Guide... - Page 2 Default Settings IP Address 192.168.1.1 Password admin Wireless Mode Enable Wireless SSID LevelOne Security None This Quick Installation Guide only describes the most basic situations and settings. All detailed information is described in the user manual.
- Page 3 Package Contents • WBR-6804 • Power Adapter • RJ-45 Cable • CD-ROM with Manual and QIG • Quick Installation Guide If any of the above items are missing, please contact your retailer or distributor. (Figure 1) Antenna Reset Button Mobile /Status LED...
- Page 4 Power JACK WAN PORT LAN PORT USB PORT Other LED indicator: Indicator Description Green and USB 3G connection is established Steady On USB 3G Green and Data packet transferred via USB 3G Blinking Green and Ethernet WAN connection is Steady On established Ethernet Green and...
- Page 5 Green and Data packet transferred via WiFi Blinking WiFi / Green and In WPS PBC mode Blinking WiFi radio is disabled Green and Ethernet LAN connection is Ethernet Steady On established Green and Data packet transferred via Ethernet Blinking (Figure 2)
- Page 6 (Figure 3) (Figure 4) (Figure 5)
- Page 7 Installation (Figure 1) Please connect the WBR-6804 to the RJ-45 Ethernet Port of your PC. Then Power-On the WBR-6804. Installation is now completed. You can now begin to configure the device. Check Your Network Settings to login web UI (Figure 2) 1.
- Page 8 (Figure 3) 2. When prompted, use the following password. Password: admin (Figure 4) 3. The first time you connect to the WBR-6804, you should run the Setup Wizard to configure the Internet Connection. Select Wizard and click Next. (Figure 5) This wizard will guide you through the setup in 6 easy steps.
