PoolRite Surechlor S3500 Quick Start Manual

Standard
C H L O R I N E G E N E R A T O R
installation installation
Heaters and other
equipment in the return
to pool line must be
installed before the cell
(i.e. Between the cell
and filter)
Remember:
The filter pump must be
plugged into the Power Pack.
When secure, plug the lead
into a suitable 240 volt power
point, but DO NOT SWITCH THE
UNIT ON
Connecting a pump load
greater than 1.5kW, or the use
of double adapters/stackable
plugs will void the warranty.
FOR FURTHER INFORMATION PLEASE REFER TO:
installation installation
S3500 Cell
cell must be installed horizontally (level) within 5 degrees, in the return to pool line. The
The S3500
two plumbing inlets must point down.
S3500 Power Pack
The Power Pack must be mounted on a vertical wall or fence within 1.5 metres of the cell and at least 1 metre
above the ground. The Power Pack must also be in a position to allow its supply lead to be plugged into a 10 amp
240 volt power point.
Select a suitable place to attach the mounting bracket, at least 1 metre above the ground and clear from hazards.
Ensure that the location selected is well ventilated (allowing plenty of airflow behind the unit) and is not in direct
sunlight (If mounted in direct sunlight the LED indicators will be less visible). The suitable location must not be
attached to or on top of a source producing large amounts of heat (e.g. metal fence or shed wall).
Mount the bracket horizontally ensuring that the vent louvers above the screws are facing upwards. Carefully
hook the Power Pack onto the mounting bracket.
Connecting the Pool Pump
Raise the tinted Control Panel Cover on the front of the Power Pack and loosen the two retaining screws in the
bottom right hand corner and remove the cable entry cover by pulling downwards. Plug the pool pump into
the pump socket on the front of the unit. Refit the cable entry cover making sure all cables pass through the
tunnel behind it to ensure they do not interfere with the proper closing of the Control Panel Cover.
Tighten retaining screws.
Off-Peak Installations
This unit is suitable for off-peak tariff supply (but will require installation by a suitably qualified tradesman).
What Salt Concentration to Use
We recommend that your S3500 salt concentration be maintained at a level of between 5000 and 7000 ppm.
operation operation
