- Page 1 INSTRUCTION MANUAL STEAM IRON Steam Pro SI 3417...
- Page 2 Dear Customer, Congratulations! You are now the proud owner of USHA Household Electronic Steam Iron. Innovatively designed, using only the highest quality material and components, your USHA Household Electronic Steam Iron is designed for years of trouble free performance. Please read this Instruction Manual carefully before using and keep it Cautiously after reading for future reference.
-
Page 3: Important Precautions
Do not operate iron with a damaged cord or if the iron has been dropped or damaged. To avoid the risk of electric shock, do not disassemble the iron. Contact USHA Care. • Close supervision is necessary for any appliance being used near children. - Page 4 The plug of the supply cord must be removed from the socket-outlet before the water reservoir is filled with water Keep electrical appliances out of reach from Children or infirm persons. Do not let them use the appliances without supervision. When placing the iron on its stand, ensure that the surface on which the stand is placed is stable.
-
Page 5: Part List
PART LIST: A: Steam Regulating Knob G: Temperature regulating knob B: Water Spray Button H: Water Tank C: Steam Burst Button I: Soleplate D: Cover of water inlet J: Indicator Light E: Water Spray Mouth K: 360 degree rotating cord F: Self Clean Button L: Handle TECHNICAL SPECIFICATIONS... -
Page 6: Special Instructions
Water tank capacity of 300 ml- Irons upto 10 clothes in a single use Steam Output of upto 20gm/min at maximum temperature setting for removing tough wrinkles effortlessly Steam burst function for removing tough wrinkles easily 360 degree swivel cord for easy manueverability 35 steam vent holes for even distribution of steam on the clothes ensuring the perfect crisp look 10. - Page 7 HOW TO USE IRON Setting the Temperature Always check first whether ironing instructions are attached to the article to be ironed. (They can be found on a label showing a drawing of an iron. The number of dots indicate the correct temperature. Refer to the indications on the temperature dial.) Follow these ironing instructions in all cases.
-
Page 8: Temperature Table
READ THE GARMENT LABELS AND FOLLOW THE MANUFACTURER’S IRONING INSTRUCTIONS THAT ARE OFTEN SHOWN BY SYMBOLS SIMILAR TO THE FOLLOWING: TEMPERATURE TABLE: (For Reference Only) Temperature control setting • Acetale • Polyester • Elastano • Silk • Cotton • Polyamide • Triacetate • Linen • Polypropylene • Viscose • Wool First Time Ironing Remove any protective films or stickers from the sole plate and the cabinet. -
Page 9: Dry Ironing
FIRST TIME IRONING Remove any protective films or sticker from the soleplate and the cabinet, if any. Unwind and straighten the power cord. Fill the water tank. as described in “How to fill water”. Connect the appliance to a suitable mains supply outlet. Turn the Temperature Dial on the iron unit in clockwise direction to maximum position, pilot light glows. -
Page 10: Steam Ironing
STEAM IRONING Unwind and straighten the power cord. Fill the water tank as described in “How to Fill Water” Connect the appliance to a suitable mains supply outlet. Turn the Temperature Dial in clockwise direction to ‘ ’ (3 dots) setting. (For optimum steam quality, do not use 1 dot or 2 dots l l l setting for steam ironing);... -
Page 11: Burst Of Steam In Vertical Position
10. When the appliance gets cool completely, store it in a safe place. Note: It may be necessary to press the burst of steam button a few times to start this function. For optimum steam quality, do not operate the Burst of Steam more than three times after the Digital number blinking stops. -
Page 12: Self-Cleaning
SELF-CLEANING This function removes the scales and minerals built up in the Steam Chamber. The iron will remain in the best condition if this function is performed at least once a month or more regularly depending on the hardness of the water used. Fill the iron as described in How To Fill Water;... -
Page 13: Cleaning The Iron
CLEANING THE IRON Disconnect the iron from the mains supply outlet Use a damped cloth or non-scratching cleaner to remove any deposits on the sole plate or the cabinets. Note: Never use sharp or rough objects to remove the deposits on the sole plate. Never use any abrasive, vinegar or other chemical agents to clean the iron. - Page 14 Spray mist not There may not be enough water Fill the water tank, see coming out in the water tank. “HOW TO FILL THE WATER” First time usage. Press the Spray Button few times until the spray mist come out. Soleplate’s heat is Incorrect Temperature setting.
-
Page 15: Warranty Card
WARRANTY CARD This appliance is warranted for 2 year against all manufacturing defects from the date of sale. In the event of any complaint, please contact USHA Care at Toll Free No. 1800 1033 111. The warranty is valid only when: The appliance has been installed, used and maintained in accordance with the instruction manual.
