- Page 1 DEEP SEA ELECTRONICS PLC DSE335 Operator Manual (Applicable to module version 4.2 and upwards) Document Number: 057-233 Author: Fady Atallah 057-233 ISSUE: 1...
- Page 2 Deep Sea Electronics Plc at the address above. The DSE logo is a UK registered trademarks of Deep Sea Electronics PLC. Any reference to trademarked product names used within this publication is owned by their respective companies.
-
Page 3: Table Of Contents
DSE335 Operator Manual TABLE OF CONTENTS SECTION PAGE INTRODUCTION ....................6 BIBLIOGRAPHY ......................... 7 1.1.1 INSTALLATION INSTRUCTIONS ................. 7 1.1.2 TRAINING GUIDES ...................... 7 1.1.3 MANUALS ........................7 1.1.4 THIRD PARTY DOCUMENTS ..................7 SPECIFICATIONS ....................8 SHORT NAMES ........................8 REQUIREMENTS FOR UL CERTIFICATION .............. - Page 4 DSE335 Operator Manual 3.1.7 LOAD CURRENT TRANSFORMERS ................. 30 3.1.7.1 CONNECTION TO TERMINALS 45 & 46/47 ............31 3.1.7.2 CT CONNECTIONS .................... 31 3.1.8 CONFIGURABLE VOLT-FREE CHANGEOVER OUTPUTS C & D ......32 3.1.9 PC CONFIGURATION INTERFACE CONNECTOR ............ 32 3.1.10 RS485 CONNECTOR ....................
- Page 5 ALARMS ........................... 83 COMMUNICATIONS ......................84 INSTRUMENTS ........................ 84 MISCELLANEOUS ......................85 MAINTENANCE, SPARES, REPAIR AND SERVICING ........86 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE ........86 9.1.1 PACK OF PLUGS....................... 86 9.1.2 INDIVIDUAL PLUGS ....................86 PURCHASING ADDITIONAL FIXING CLIPS FROM DSE ..........86 PURCHASING ADDITIONAL SEALING GASKET FROM DSE .........
-
Page 6: Introduction
• Fully configurable inputs for use as alarms or a range of different functions. Using a PC and the DSE Configuration Suite software allows alteration of selected operational sequences, timers, alarms and operational sequences. Additionally, the module’s integral front panel configuration editor allows adjustment of this information. -
Page 7: Bibliography
Introduction 1.1 BIBLIOGRAPHY This document refers to and is referred to by the following DSE publications are obtained from the DSE website: www.deepseaplc.com 1.1.1 INSTALLATION INSTRUCTIONS Installation instructions are supplied with the product in the box and are intended as a ‘quick start’... -
Page 8: Specifications
Specifications 2 SPECIFICATIONS 2.1 SHORT NAMES Short Name Description DSE3xx All modules/controllers in the DSEATS range DSE335 DSE335 module/controller 2.2 REQUIREMENTS FOR UL CERTIFICATION Description Specification Screw Terminal • 4.5 lb-in (0.5 Nm) Tightening Torque • Terminals suitable for connection of conductor size 12 AWG to 26 AWG (0.5 mm²... -
Page 9: Terminal Specification
Specifications 2.3 TERMINAL SPECIFICATION NOTE: For purchasing additional connector plugs from DSE, see the section entitled Maintenance, Spares, Repair and Servicing elsewhere in this document. Description Specification Two part connector. • Male part fitted to module • Female part supplied in... -
Page 10: S1 & S2 Voltage / Frequency Sensing
Specifications 2.5 S1 & S2 VOLTAGE / FREQUENCY SENSING Description Specification Measurement type True RMS conversion Sample Rate 5KHz or better Harmonics Up to 10 or better 300K Ω ph-N Input Impedance Phase to Neutral 15V (minimum required for sensing frequency) to 333V AC (absolute maximum) Suitable for 110V to 277V nominal (±20% for under/overvoltage detection) -
Page 11: A Rating Of The Cts
Specifications 2.6.1 V A RATING OF THE CTS NOTE: Details for 4 mm² cables are shown for reference only. The connectors on the DSE modules are only suitable for cables up to 2.5 mm². The V A burden of the module on the CTs is 0.5 V A. However depending upon the type and length of cabling between the CTs and the module, CTs with a greater V A rating than the module are required. -
Page 12: Ct Polarity
2.6.3 CT PHASING Take particular care that the CTs are connected to the correct phases. For instance, ensure that the CT on phase 1 is connected to the terminal on the DSE module intended for connection to the CT for phase 1. -
Page 13: Inputs
12V typical for negative activation. 0V typical for positive activation. 2.8 OUTPUTS NOTE: Refer to Breaker Control Training Document (DSE part 056-022) for further details on configuring and control different type of load switching devices. There are twelve outputs fitted to the controller 2.8.1 CONFIGURABLE OUTPUTS A &... -
Page 14: Communication Ports
Specifications 2.9 COMMUNICATION PORTS Description Specification USB Port USB2.0 Device for connection to PC running DSE configuration suite only Max distance 6m (yards) Serial RS232 and RS485 are both fitted but provide independent operation Communication RS232 Serial Non – Isolated port... -
Page 15: Communication Port Usage
The USB port is provided to give a simple means of connection between a PC and the controller. Using the DSE Configuration Suite Software, the operator is then able to control the module, starting or stopping the generator, selecting operating modes, etc. -
Page 16: Rs232
GSM modem for more remote communications. Many PCs are not fitted with an internal RS232 serial port. DSE DOES NOT recommend the use of USB to RS232 convertors but can recommend PC add-ons to provide the computer with an RS232 port. -
Page 17: Recommended External Modems
• For a data connection to a PC running the DSE Configuration Suite software, a ‘special’ CSD (Circuit Switched Data) SIM card is required in order for the modem to answer an incoming data call. -
Page 18: Rs485
The RS485 port on the series controller supports the Modbus RTU protocol. The DSE Gencomm register table for the controller is available upon request from the DSE Technical Support Department. RS485 is used for point-to-point cable connection of more than one device (maximum 32 devices) and allows for connection to PCs, PLCs and Building Management Systems (to name just a few devices). -
Page 19: Dsenet® For Expansion Modules
2.10 ADDING AN EXTERNAL SOUNDER TO THE APPLICATION When an external alarm or indicator is required, this can be achieved by using the DSE Configuration Suite PC software to configure an auxiliary output for “Audible Alarm”, and by configuring an auxiliary input for “Alarm Mute”... -
Page 20: Dimensions And Mounting
Specifications 2.11 DIMENSIONS AND MOUNTING 2.11.1 DIMENSIONS 240.0 mm x 181.1 mm x 41.7 mm (9.4 ” x 7.1 ” x 1.6 ”) 2.11.2 PANEL CUTOUT 220 mm x 160 mm (8.7 ” x 6.3 ”) 2.11.3 WEIGHT 0.7 kg (1.4 lb) 057-233 ISSUE: 1 Page 20 of 90... -
Page 21: Fixing Clips
Specifications 2.11.4 FIXING CLIPS NOTE: In conditions of excessive vibration, mount the module on suitable anti-vibration mountings. The module is held into the panel fascia using the supplied fixing clips. • Withdraw the fixing clip screw (turn anticlockwise) until only the pointed end is protruding from the clip. -
Page 22: Cable Tie Fixing Points
Specifications 2.11.5 CABLE TIE FIXING POINTS Integral cable tie fixing points are included on the rear of the module’s case to aid wiring. This additionally provides strain relief to the cable loom by removing the weight of the loom from the screw connectors, thus reducing the chance of future connection failures. -
Page 23: Applicable Standards
Specifications 2.11.8 APPLICABLE STANDARDS Standard Description BS 4884-1 This document conforms to BS4884-1 1992 Specification for presentation of essential information. BS 4884-2 This document conforms to BS4884-2 1993 Guide to content BS 4884-3 This document conforms to BS4884-3 1993 Guide to presentation BS EN 60068-2-1 -30 °C (-22 °F) (Minimum temperature) - Page 24 Specifications Standard Description IEEE C37.2 Continued… (Standard Electrical Power System Device 49 – Machine Or Transformer Thermal Relay (USING EXPANSION Function Numbers and MODULE) Contact Designations) 50 – Instantaneous Overcurrent Relay 52 – AC Circuit Breaker 55 – Power Factor Relay (USING INTERNAL PLC EDITOR) 59AC –...
-
Page 25: Enclosure Classifications
Specifications 2.11.9 ENCLOSURE CLASSIFICATIONS 2.11.9.1 IP CLASSIFICATIONS The modules specification under BS EN 60529 Degrees of protection provided by enclosures IP65 (Front of module when module is installed into the control panel with the optional sealing gasket). IP42 (front of module when module is installed into the control panel WITHOUT being sealed to the panel) First Digit Second Digit... -
Page 26: Nema Classifications
Specifications 2.11.9.2 NEMA CLASSIFICATIONS The modules NEMA Rating (Approximate) 12 (Front of module when module is installed into the control panel with the optional sealing gasket). 2 (front of module when module is installed into the control panel WITHOUT being sealed to the panel) NOTE: There is no direct equivalence between IP / NEMA ratings. -
Page 27: Installation
Installation 3 INSTALLATION The module is designed to be mounted on the panel fascia. For dimension and mounting details, see the section entitled Specification, Dimension and mounting elsewhere in this document. 3.1 TERMINAL DESCRIPTION To aid user connection, icons are used on the rear of the module to help identify terminal functions. An example of this is shown below. -
Page 28: Dc Supply, Outputs G-L
Installation 3.1.1 DC SUPPLY, OUTPUTS G-L NOTE: For further details of module configuration, refer to DSE Publication: 057-237 DSE335 Configuration Software Manual. Cable Description Notes Size DC Plant Supply Input 2.5 mm² (Negative) AWG 13 DC Plant Supply Input 2.5 mm²... -
Page 29: Configurable Digital Inputs J-L, Dsenet
Installation 3.1.3 CONFIGURABLE DIGITAL INPUTS J-L, DSENET NOTE: Terminal 24 is not used, do not connect. Cable Description Notes Size 0.5 mm² Configurable digital input J Switch to negative or positive depending on configuration AWG 20 0.5 mm² Configurable digital input K Switch to negative or positive depending on configuration AWG 20 0.5 mm²... -
Page 30: S1 Voltage Sensing
Installation 3.1.6 S1 VOLTAGE SENSING NOTE: The above table describes connections to a three phase, four wire alternator. For alternative wiring topologies, please see the ALTERNATIVE AC TOPOLOGIES section of this manual. Cable Description Notes Size 1.0 mm² Connect to S1 L1 (R) incoming supply (AC) S1 L1 (R) voltage monitoring AWG 18 (Recommend 2A fuse) -
Page 31: Connection To Terminals 45 & 46/47
L is the primary of the CT that ‘points’ towards the LOAD s1 is the secondary of the CT that connects to the DSE Module’s input for the CT measuring s2 is the secondary of the CT that must be commoned with the s2 connections of all the other CTs and connected to the CT common terminal of the module. -
Page 32: Configurable Volt-Free Changeover Outputs C & D
Installation 3.1.8 CONFIGURABLE VOLT-FREE CHANGEOVER OUTPUTS C & D NOTE: For further details of module configuration, refer to DSE Publication: 057-237 DSE335 Configuration Software Manual. Cable Description Notes Size 1.0 mm² Output C Normally Open AWG 18 1.0 mm² Volts free relay change-over relay user configured (8A resistive... -
Page 33: Rs485 Connector
Installation 3.1.10 RS485 CONNECTOR Pin No. Notes Two core screened twisted pair cable. A (-) 120Ω impedance suitable for RS485 use. B (+) Recommended cable type - Belden 9841 Max distance 1200 m (1.2 km) when using Belden 9841 or direct equivalent. Location of RS485 connector Location of RS232 connector... -
Page 34: Typical Wiring Diagram
Genset manufacturers and panel builders may use these diagrams as a starting point; however, refer to the completed system diagram provided by the system manufacturer for complete wiring detail. Further wiring suggestions are available in the following DSE publications, available at www.deepseaplc.com. -
Page 35: Dse335 3 Phase, 4 Wire With Restricted Earth Fault Protection
Installation 3.2.1 DSE335 3 PHASE, 4 WIRE WITH RESTRICTED EARTH FAULT PROTECTION NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’... -
Page 36: Alternative Topologies
Installation 3.3 ALTERNATIVE TOPOLOGIES NOTE: For further details of module configuration, refer to DSE Publication: 057-237 DSE335 Configuration Software Manual. The controller is factory configured to connect to a 3 phase, 4 wire Star connected alternator. This section details connections for alternative AC topologies. Ensure to configure the controller to suit the required topology. -
Page 37: Single Phase With Restricted Earth Fault
Installation 3.3.2 SINGLE PHASE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’ the neutral CT allows the module to read earth faults ‘before’... -
Page 38: Phase (L1 & L2) 3 Wire With Restricted Earth Fault
Installation 3.3.4 2 PHASE (L1 & L2) 3 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’... -
Page 39: Phase (L1 & L3) 3 Wire With Restricted Earth Fault
Installation 3.3.6 2 PHASE (L1 & L3) 3 WIRE WITH RESTRICTED EARTH FAULT NOTE: Earthing the neutral conductor ‘before’ the neutral CT allows the module to read earth faults ‘after’ the CT only (Restricted to load / downstream of the CT) Earthing the neutral conductor ‘after’... -
Page 40: Phase (L1 & L3) 3 Wire Without Earth Fault Measuring
Installation 3.3.7 2 PHASE (L1 & L3) 3 WIRE WITHOUT EARTH FAULT MEASURING 057-233 ISSUE: 1 Page 40 of 90... -
Page 41: Phase 4 Wire With Unrestricted Earth Fault Measuring
Installation 3.3.8 3 PHASE 4 WIRE WITH UNRESTRICTED EARTH FAULT MEASURING NOTE: Unrestricted Earth Fault Protection detects earth faults in the load and in the sources. Be sure to measure the natural earth fault of the site before deciding upon an earth fault alarm trip level. -
Page 42: Earth Systems
The typical wiring diagrams located within this document show connections for a negative earth system (the battery negative connects to Earth) 3.4.2 POSITIVE EARTH When using a DSE module with a Positive Earth System (the battery positive connects to Earth), the following points must be followed: •... -
Page 43: Description Of Controls
Description of Controls 4 DESCRIPTION OF CONTROLS NOTE: The following descriptions detail the sequences followed by a module containing the standard ‘factory configuration’. Always refer to the configuration source for the exact sequences and timers observed by any particular module in the field. CAUTION: The module may instruct an engine start event due to external influences. - Page 44 Description of Controls Main status and Four configurable instrumentation display Menu navigation LEDs buttons Open/Close S2 (manual mode only) Open/Close S1 (manual mode only) Latest Transfer Select Stop Information (Info) mode Select Select Alarm Mute / Select mode: Test On Manual mode Auto mode Lamp Test...
-
Page 45: Control Push-Buttons
Description of Controls 4.1 CONTROL PUSH-BUTTONS Icon Description Stop / Reset This button places the module into its Stop / Reset mode. This clears any alarm conditions for which the triggering criteria have been removed. If S2 is on load and the module is placed into Stop mode, the module automatically instructs the changeover device to unload the S2 source (Close S2 Output becomes inactive (if used)). - Page 46 Description of Controls Icon Description Mute / Lamp Test This button silences the audible alarm if it is sounding and illuminates all of the LEDs as a lamp test feature. Latest Transfer Information Whilst pressing this button, the module displays the reason, time, date and duration for the latest transfer that occurred, holding this button cycles between the last S1 transfer and the last S2 transfer.
-
Page 47: Viewing The Instrument
If no buttons are pressed upon entering an instrumentation page, the instruments are displayed automatically subject to the setting of the LCD Scroll Timer. The LCD Page and LCD Scroll timers are configurable using the DSE Configuration Suite Software or by using the Front Panel Editor. -
Page 48: Status
Description of Controls 4.2.1 STATUS This is the ‘home’ page, which is displayed when no other page has been selected, and the page that is automatically displayed after a period of inactivity (LCD Page Timer) of the module control buttons. Contains summary information of both supplies along with different module status display. -
Page 49: Module
Description of Controls 4.2.2 S1 Contains electrical values of S1 measured or derived from the module’s voltage and current inputs. • S1 Configuration • S1 State • S1 Summary • S1 Voltage (ph-N) • S1 Voltage (ph-ph) • S1 Frequency •... -
Page 50: Expansion
At the time of writing, the modules log is capable of storing the last 250 log entries. Under default factory settings, the event log only includes electrical trip alarms (The event log does not contain Warning alarms); however, this is configurable by the system designer using the DSE Configuration Suite software. -
Page 51: Serial Port
Description of Controls 4.2.8 SERIAL PORT 4.2.8.1 RS232 SERIAL PORT NOTE: Factory Default settings are for the RS232 port to be enabled with no modem connected, operating at 19200 baud, Modbus slave address 10. This section is included to give information about the RS232 serial port and external modem (if connected). - Page 52 GSM status..Currently connected GSM operator and signal strength. If the GSM modem is not purchased from DSE, ensure that it has been correctly set to operate at 9600 baud. 057-233 ISSUE: 1 Page 52 of 90...
- Page 53 Description of Controls Modem Initialisation Sequence 1) The modem attempts to communicate to the module 2) If the Modem and module communicate successfully: 3) In case of communication failure between the modem and module, the modem is automatically reset and initialisation is attempted once more: In the case of a module that is unable to communicate with the modem, the display continuously cycles between ‘Modem Reset’...
- Page 54 2 seconds The DSE MODBUS document containing register mappings inside the DSE module is available upon request from support@deepseaplc.com. Email the request along with the serial number of the DSE module to ensure the correct information is sent.
-
Page 55: Rs485 Serial Port
2 seconds. The DSE MODBUS document containing register mappings inside the DSE module is available upon request from support@deepseaplc.com. Email the request along with the serial number of the DSE module to ensure the correct information is sent. -
Page 56: Scheduler
T W T F S S T W T F S S 4.2.10 ABOUT Contains important information about the module and the firmware versions. This information may be asked for when contacting DSE Technical Support Department for advice. • Variant – 335 About •... -
Page 57: Viewing Latest Transfer Information Page
Description of Controls 4.3 VIEWING LATEST TRANSFER INFORMATION PAGE It is possible to view the reason, time, date and duration of the latest transfer by pressing and holding the Latest Transfer Information . Holding this button cycles between the last S1 transfer and the last S2 transfer. -
Page 58: User Configurable Indicators
Description of Controls 4.4 USER CONFIGURABLE INDICATORS These LEDs can be configured by the user to indicate any one of 100+ different functions based around the following: • Indications - Monitoring of a digital input and indicating associated functioning user’s equipment - Such as Battery Charger On or Louvres Open, etc. -
Page 59: Operation
Description of Controls 4.5 OPERATION NOTE: The following descriptions detail the sequences followed by a module containing the standard ‘factory configuration’. Always refer to the configuration source for the exact sequences and timers observed by any particular module in the field. 4.6 QUICKSTART GUIDE This section provides a quick start guide to the module’s operation. -
Page 60: Stopping S2
Description of Controls 4.6.2 STOPPING S2 NOTE: This only applies when S2 is configured as a generator supply. Select Stop/Reset mode. S2 breaker is opened and the start request is removed. 057-233 ISSUE: 1 Page 60 of 90... -
Page 61: Stop/Reset
Description of Controls 4.7 STOP/RESET NOTE: If a digital input configured to Panel Lock is active, changing module modes is not possible. Viewing the instruments and event logs is NOT affected by panel lock. Stop mode is activated by pressing the button. -
Page 62: Manual Mode
Activation of the inbuilt exercise scheduler if configured for ‘on load’ runs. As the load increases and decreases, the module may (depending upon configuration) remove non- essential loads. This is configured as part of the Load Shedding control settings in the DSE Configuration Suite Software. -
Page 63: Stopping Sequence
Description of Controls Once the load has been transferred to S2, it is not automatically transferred back to the S1 supply. To manually transfer the load back to the mains either: • Pressing the Close/Open S1 button • Pressing the Auto button to return to automatic mode. -
Page 64: Automatic Mode
Description of Controls 4.9 AUTOMATIC MODE NOTE: If a digital input configured to Panel Lock is active, changing module modes is not possible. Viewing the instruments and event logs is NOT affected by panel lock. Auto mode is activated by pressing the button. -
Page 65: S2 Available
As the load increases and decreases, the module may (depending upon configuration) remove non- essential loads. This is configured as part of the Load Shedding control settings in the DSE Configuration Suite Software. -
Page 66: Mode Selection
As the load increases and decreases, the module may (depending upon configuration) remove non- essential loads. This is configured as part of the Load Shedding control settings in the DSE Configuration Suite Software. -
Page 67: Test Off Load
As the load increases and decreases, the module may (depending upon configuration) remove non- essential loads. This is configured as part of the Load Shedding control settings in the DSE Configuration Suite Software. -
Page 68: Prohibit Return
Description of Controls 4.10.3 PROHIBIT RETURN Activate by pressing the Mode button repeatedly until Prohibit Return is shown on the display, then press the Tick button to confirm the change. An LED indicator beside the button confirms this action. The Prohibit Return mode prevents the load being transfer back to the S1 from the S2 supply until the module is instructed to do so. -
Page 69: S2 Available
As the load increases and decreases, the module may (depending upon configuration) remove non- essential loads. This is configured as part of the Load Shedding control settings in the DSE Configuration Suite Software. -
Page 70: Scheduler
Up to 16 scheduled start/stop sequences can be configured in banks of 8 to either repeat on a 7-day or 28-day cycle. Scheduled runs may be on load or off load depending upon module configuration. Example Screen capture from DSE Configuration Suite Software showing the configuration of the Exercise Scheduler. -
Page 71: Load Shedding Control
S2. 4.12.1 LOAD SHEDDING CONTROL NOTE: Refer to DSE335 Configuration Suite Manual (DSE part 057-237) for further details on configuring, monitoring and control. The Load Shedding Control feature (if enabled) allows for a maximum of five load shedding steps. -
Page 72: Protections
Protections 5 PROTECTIONS When an alarm is present, the Audible Alarm sounds and the Common alarm LED if configured illuminates. The audible alarm can be silenced by pressing the Alarm Mute The LCD display jumps from the ‘Information page’ to display the Alarm Page Number of present alarms. -
Page 73: Indications
Protections 5.1 INDICATIONS Indications are non-critical and often status conditions. They do not appear on the LCD of the module as a text message. However, an output or LED indicator can be configured to draw the operator’s attention to the event. Example •... -
Page 74: Warnings
Calibration Lost The module has lost its calibration settings and must be sent back to DSE to be re-calibrated. Expansion Inputs If an expansion input has been configured as a warning the appropriate LCD message is displayed and the COMMON ALARM LED illuminates. -
Page 75: Electrical Trips
Protections Display Reason PLC Functions If a PLC Function has been configured as a warning the appropriate LCD message is displayed and the COMMON ALARM LED illuminates. S1 Breaker Auxiliary Fail Indicates that the S1 Closed Auxiliary input has not activated along with the Close S1 Output or Open S1 Output, or the input has activated when the output was not energised. -
Page 76: Front Panel Configuration
Front Panel Configuration 6 FRONT PANEL CONFIGURATION This configuration mode allows the operator limited customising of the way the module operates. Use the module’s navigation buttons to traverse the menu and make value changes to the parameters: Increase value / next item Previous page Decrease value / next item 057-233 ISSUE: 1... -
Page 77: Accessing The Main Front Panel Configuration Editor
Contrast 54 % NOTE: The PIN number is not set by DSE when the module leaves the factory. If the module has a PIN code set, this has been affected by the ATS supplier who must be contacted if the code is required. If the code has been ‘lost’ or ‘forgotten’, the module must be returned to the DSE factory to have the module’s code removed. -
Page 78: Editing A Parameter
NOTE: The PIN number is automatically reset when the editor is exited (manually or automatically) to ensure security. NOTE: Refer to DSE335 Configuration Suite Manual (DSE part 057-237) for further details on configuring, monitoring and control. Enter the editor as described above. -
Page 79: Adjustable Parameters
Front Panel Configuration 6.2 ADJUSTABLE PARAMETERS NOTE: Refer to DSE335 Configuration Suite Manual (DSE part 057-237) for further details on configuring, monitoring and control. Section Parameter As Shown On Display Values Display LCD Contrast Language English LCD Page Timer hh:mm:ss... - Page 80 Front Panel Configuration NOTE: Refer to DSE335 Configuration Suite Manual (DSE part 057-237) for further details on configuring, monitoring and control. Section Parameter As Shown On Display Values Scheduler Scheduler Enable Inactive, Active Bank 1 Do Not Transfer Transfer to S1...
- Page 81 Front Panel Configuration NOTE: Refer to DSE335 Configuration Suite Manual (DSE part 057-237) for further details on configuring, monitoring and control. Section Parameter As Shown On Display Values Do Not Transfer Transfer to S1 Scheduler Bank 2 Run Mode Transfer to S2...
-
Page 82: Commissioning
If, despite repeated checking of the connections between the controller and the customer’s system, satisfactory operation cannot be achieved, then the customer is requested to contact the DSE Technical Support Department for further advice. 057-233 ISSUE: 1 Page 82 of 90... -
Page 83: Fault Finding
Fault Finding 8 FAULT FINDING 8.1 STARTING Symptom Possible Remedy Unit is inoperative Check the battery and wiring to the unit. Check the DC supply. Check the DC fuse. Read/Write configuration does not operate Unit shuts down Check DC supply voltage is not above 35 Volts or below 9 Volts Check the operating temperature is not above 70 °... -
Page 84: Communications
Check : • modem inoperative RS232 maximum of 15 m is not exceeded • Modem Initialisation strings in the DSE configuration is correct for the connected modem type • Modem is configured to 9600 baud • SIM card is CSD (circuit switched data) compatible •... -
Page 85: Miscellaneous
Fault Finding 8.6 MISCELLANEOUS NOTE: The above fault finding is provided as a guide check-list only. As the module can be configured to provide a wide range of different features, always refer to the source of the module configuration if in doubt. Symptom Possible Remedy Module appears to ‘revert’... -
Page 86: Maintenance, Spares, Repair And Servicing
In the case of malfunction, contact the original equipment manufacturer (OEM). 9.1 PURCHASING ADDITIONAL CONNECTOR PLUGS FROM DSE If additional plugs are required from DSE, please contact our sales department using the part numbers below. 9.1.1 PACK OF PLUGS Module type... -
Page 87: Dsenet Expansion Modules
NOTE: DSENet® utilises an RS485 connection. Using Belden 9841 (or equivalent) cable allows for the expansion cable to be extended to a maximum of 1.2 km. DSE Stock and supply Belden 9841 cable. DSE Part Number 016-030. DSE Part Numbers Model Max No. -
Page 88: Warranty
Warranty and Disposal 10 WARRANTY DSE provides limited warranty to the equipment purchaser at the point of sale. For full details of any applicable warranty, refer to the original equipment supplier (OEM). 11 DISPOSAL 11.1 WEEE (WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT) If you use electrical and electronic equipment you must store, collect, treat, recycle and dispose of WEEE separately from your other waste. - Page 89 This Page is Intentionally Blank...
- Page 90 This Page is Intentionally Blank...
