Manual of Operation and Instruction
Model 3411-B
Advanced
Control Unit
Troxler Electronic Laboratories, Inc.
3008 Cornwallis Rd. • P.O. Box 12057
Research Triangle Park, NC 27709
Phone: 1.877.TROXLER
Outside the USA: +1.919.549.8661
Fax: +1.919.549.0761
www.troxlerlabs.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3411-B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Troxler 3411-B

Summary of Contents for Troxler 3411-B

  • Page 1 Manual of Operation and Instruction Model 3411-B Advanced Control Unit Troxler Electronic Laboratories, Inc. 3008 Cornwallis Rd. • P.O. Box 12057 Research Triangle Park, NC 27709 Phone: 1.877.TROXLER Outside the USA: +1.919.549.8661 Fax: +1.919.549.0761 www.troxlerlabs.com...
  • Page 2 Troxler gauges are protected by U.S. and foreign patents. Copyright © 2005, 2006 Troxler Electronic Laboratories, Inc. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means, electronic or mechanical, including...
  • Page 3 Troxler European Subsidiary Southwestern Branch Office Troxler Electronics GmbH 2016 East Randol Mill Road Gilchinger Strasse 33 Suite 406 D.82239 Alling nr. Munich, Germany Arlington, TX 76011 Phone: ++49.8141.71063 Fax: 817.275.8562 Fax: ++49.8141.80731 E-mail: troxler@t-online.de Model 3411-B Advanced Control Unit...
  • Page 4 The Model 3411-B Advanced Control Unit Manual of Operation and Instruction contains information on installing the ACU, and on safely using the Model 3411-B gauge after the ACU has been installed. Also included in this manual are safety warnings, gauge...
  • Page 5 With lists of check marks, follow the instructions in the order of the check marks. Triangles indicate that more than one option is available. Carefully select the option that applies. The ACU is equipped with a two-line backlit display. Model 3411-B Advanced Control Unit...
  • Page 6 NOTES...

  • Page 7: Table Of Contents

    Offset .................... 4–2 Stat Test ..................4–2 Drift Test..................4–5 Special Calibration................ 4–7 Specific Gravity ................4–7 Voidless Density ................4–8 Set Units..................4–8 Calibration Constants..............4–9 Memory Reset................4–9 Test Reading ................. 4–9 15-Second Inhibit................ 4–10 Model 3411-B Advanced Control Unit...
  • Page 8 TABLE OF CONTENTS (Continued) APPENDIX A. 3411-B ELECTRICAL SPECIFICATIONS Electrical Specifications ...............A–2 APPENDIX B. PERIODIC MAINTENANCE AND SERVICE Troubleshooting................B–2 Battery Charging ................B–7 Replacement Parts ................ B–8 Returning the Gauge for Service ..........B–10 Troxler Service Centers.............. B–11 INDEX...
  • Page 9 Marking the Test Area ..........2–11 2–4 Voids Illustration............. 2–15 B–1 Model 3411-B ACU Assembly .........B–9 LIST OF TABLES Table Title Page 2–1 Model 3411-B ACU Keypad Functions....2–3 3–1 K Values for Thin Lift Overlays ......3–14 Model 3411-B Advanced Control Unit...
  • Page 10 NOTES...
  • Page 11 This unit contains functions that require an ACCESS CODE. This code must be entered before these functions may be used. The ACCESS CODE for the Model 3411-B Advanced Control Unit is: 4678 This page should be removed if the access code is not to be distributed to other parties or users of this gauge.
  • Page 12 NOTES...
  • Page 13 CHAPTER 1 INTRODUCTION AND INSTALLATION This chapter introduces the Model 3411-B Advanced Control Unit (ACU) and provides instructions for installing it into a Model 3411-B gauge. CONTENTS Introduction................... 1–2 Installing the ACU ................ 1–3 Entering the Calibration Constants ..........1–4 Model 3411-B Advanced Control Unit 1–1...

  • Page 14: Introduction

    Model 3430 gauge for less than the cost of a new gauge. The ACU is a direct replacement for the 3411-B’s original scaler and adds a number of improvements over the original: ♦...

  • Page 15: Installing The Acu

    Disconnect the ribbon cable from the scaler and set the scaler aside. Connect the ribbon cable to connector J8 on the Model 3411-B ACU. J8 is located on the circuit board labeled 110238 REV. X (TOP), where X is the current revision of the board. Ensure that the polarizing key on the ribbon cable connector is aligned with the slot in connector J8.

  • Page 16: Entering The Calibration Constants

    ENTERING THE CALIBRATION CONSTANTS The calibration constants are a set of mathematical constants used by the gauge when calculating a test result. These constants are developed when the gauge is calibrated, and are unique to a particular gauge. The constants for a gauge are listed on the most recent calibration sheet provided with the gauge.
  • Page 17 To change the value of the flashing digit for the E value, use the up and down arrows. To accept the flashing value and select the next digit, press 〈START/ENTER〉. Enter the remaining constants for each depth. Model 3411-B Advanced Control Unit 1–5...
  • Page 18 NOTES 1–6...
  • Page 19 CHAPTER 2 OPERATING THE GAUGE This chapter explains the basic operation of a Model 3411-B gauge after it has been retrofitted with a Model 3411-B Advanced Control Unit (ACU). Instructions for setting gauge parameters, taking the daily standard count, preparing the test site, positioning the gauge, and taking moisture and density measurements are included.

  • Page 20: The Keypad

    THE KEYPAD The keypad (see Figure 2–1) of the Model 3411-B Advanced Control Unit (ACU) consists of ten keys — an eight-function keypad and the 〈ON/YES〉 and 〈OFF/NO〉 keys – and a backlight switch. The gauge is equipped with a beeper to verify keystrokes. If a beep is not heard when a key is pressed, the keystroke was not recognized and should be repeated.

  • Page 21: Model 3411-B Acu Keypad

    Table 2–1 provides a more detailed description of the individual keys and the location in the manual where each function is described. Table 2–1. Model 3411-B ACU Keypad Functions KEYS DESCRIPTION PAGE Turns on the gauge and answers Yes 2–4 to prompts.

  • Page 22: Turning The Gauge On

    TURNING THE GAUGE ON The gauge uses rechargeable NiCad batteries (included) as a power source. When first turned on, the ACU displays test characters before proceeding to the self-test. NOTE If the gauge turns off immediately after it is turned on, the battery charge may be low or the gauge may be wet inside.

  • Page 23: Gauge Parameter Setup

    (↑ ↓ or ENTER) To select Set Units, press 〈START/ENTER〉. Units: (↑ ↓ or ENTER) Use the up and down arrows to scroll through the available units. When the desired units are displayed, press 〈START/ENTER〉. Model 3411-B Advanced Control Unit 2–5...
  • Page 24 SETTING THE COUNT TIME The count time defines how long the gauge reads. Longer count times produce better measurement precision. Troxler recommends a count time of one minute for most sample measurements. To change the count time, press 〈TIME〉 to display:...
  • Page 25 (0 – 9 and .). When the correct value for the current digit is displayed, press 〈START/ENTER〉. The gauge will proceed to the next digit to the right. When the value entry is complete, the gauge activates the value and returns to the Ready mode. Model 3411-B Advanced Control Unit 2–7...

  • Page 26: Taking The Standard Count

    TAKING THE STANDARD COUNT The gauge uses a cesium-137 and an americium-241:beryllium source for taking measurements. These radioactive sources undergo a natural decay process, resulting in a gradual loss in the intensity of their radiation. The time required for the source strength to diminish by 50% is referred to as the half-life.
  • Page 27 Standard Count: DS= xx MS= xx Troxler recommends that the operator keep a daily log of the moisture and density standard counts (see the Model 3400-B Manual of Operation and Instruction originally supplied with the Model 3411-B gauge). To verify gauge stability, compare the daily standard count to a reliable reference as follows: ♦...

  • Page 28: Site Preparation/Gauge Positioning

    SITE PREPARATION/GAUGE POSITIONING Preparation of the test site surface is critical to gauge performance. This section provides site preparation procedures for both soils and base courses and asphalt surfaces. To ensure the most accurate gauge readings, the appropriate preparation procedure should be followed.

  • Page 29: Drill Rod Positioning

    EDGE MARK FOR SCRAPER MARKS PLATE CENTER SCRAPER SCRAPER PLATE PLATE MARK FOR DRILL ROD CENTER METHOD 2 METHOD 1 Figure 2–3. Marking the Test Area Model 3411-B Advanced Control Unit 2–11...
  • Page 30 ASPHALT SURFACE PREPARATION It is possible, but usually not necessary, to take direct transmission readings on asphalt. Drilling a hole in asphalt can be difficult, and may require the use of a drill (rather than the drill rod) if the asphalt has cooled and hardened.

  • Page 31: Taking A Measurement - Soil Mode

    After the count time has elapsed, the gauge displays the measurement results in a series of six screens, as follows. Use the up and down arrows to scroll through the various screens. Model 3411-B Advanced Control Unit 2–13...
  • Page 32 M Count: D Count: xxx.x PCF (Use ↑ & ↓ keys) xxx.x PCF % PR: xx.x Moist: xxx.x PCF % Moist: x.x Air Void: xx.x % Void Ratio x.xxx MOIST CR: x.xxx DENS. CR: x.xxx where: M Count = Moisture counts as read by the gauge D Count = Density counts as read by the gauge WD = Wet density in kg/m or pcf...

  • Page 33: Voids Illustration

    SG = Specific Gravity of Soil Particles DD = Dry Density M = Moisture VOID RATIO = Volume of Voids / Volume of Soil = ( SG(Dw) – DD ) / DD Figure 2–4. Voids Illustration Model 3411-B Advanced Control Unit 2–15...

  • Page 34: Taking A Measurement - Asphalt Mode

    TAKING A MEASUREMENT – ASPHALT MODE The Asphalt mode is automatically selected when a Marshall value is enabled (see page 2–6). NOTE When not taking measurements, always keep the source rod in the SAFE position. For added operator safety, the source rod on the gauge automatically retracts to the SAFE position when the gauge is picked up by the handle.
  • Page 35 DENS. CR = Density count ratio M Count = Moisture counts as read by the gauge D Count = Density counts as read by the gauge Press 〈ON/YES〉 to return to the Ready mode. Model 3411-B Advanced Control Unit 2–17...
  • Page 36 NOTES 2–18...
  • Page 37 CHAPTER 3 ADVANCED GAUGE OPERATION This chapter provides instructions for using the Model 3411-B Advanced Control Unit (ACU) in special circumstances where the gauge may require an offset or special calibration. This chapter also explains the procedure for using the gauge to measure thin layers of asphalt.

  • Page 38: Offsets

    OFFSETS The Model 3411-B gauge is factory-calibrated for soils, asphalt, and concrete with an approximate density range of 1100 to 2700 kg/m (70 to 170 pcf). With an offset, the operator can adjust the gauge readings to correlate to traditional laboratory methods, such as core samples.
  • Page 39 To input a minus sign (for a negative offset), press the down arrow first. To scroll through the numerals, press up and down arrows. To select the next digit and/or exit, press 〈START/ENTER〉. The display will be: Dens. Offset ON Model 3411-B Advanced Control Unit 3–3...
  • Page 40 MOISTURE OFFSET Some soils contain hydrogen sources other than water and/or neutron absorbers. Since the gauge measures moisture by determining the hydrogen content of the material and relating this to the water content, both types of material could cause gauge readings that differ from the true moisture.
  • Page 41 To scroll through the possible values for each digit, press the arrow key. To select the next digit, press 〈START/ENTER〉. When all digits are entered, the gauge will enable the offset. The display will be: Moist Offset ON Model 3411-B Advanced Control Unit 3–5...
  • Page 42 TRENCH OFFSETS If the gauge is to be used for moisture or density measurements in a trench or within two feet (0.6 m) of a large vertical structure, a trench offset may be required. If used, the trench offset adjusts all moisture measurements but only the density measurements from backscatter through four inches (10 cm).
  • Page 43 The procedure for entering the values is the same as for moisture and density offsets, ignoring the ± sign on the display. When the values are complete, the gauge enables the offset and displays: Trench Offset ENABLED Model 3411-B Advanced Control Unit 3–7...

  • Page 44: Special Calibrations

    (µ/ρ) of the material. If the chemical composition of the soil is known, Troxler can provide a procedure for recalculating the B value for manual entry (see page 3–9) to accurately measure the soil density.
  • Page 45 Enter B Value? To enter a known B value obtained with the procedure available from Troxler, press 〈ON/YES〉. To have the gauge calculate the recalibration, press 〈OFF/NO〉. If entering a new known B value, see the following explanation. For gauge-calculated special calibration, see page 3–10.
  • Page 46 Upon entry completion, the gauge will indicate that the special calibration is enabled and return to the Ready mode. Note that when the gauge is turned off the Special Calibration is disabled. SPECIAL CALIB. ENABLED! GAUGE-CALCULATED CALIBRATION The true density of the sample must be determined, and a gauge reading must be performed on the material in order to calculate and enable a special calibration.
  • Page 47 The special calibration is only valid for the depth selected during the special calibration. SPECIAL CALIB. ENABLED! Model 3411-B Advanced Control Unit 3–11...

  • Page 48: Thin Layer Measurements

    THIN LAYER MEASUREMENTS Conventional backscatter gauges measure density to depths of approximately 4 inches. To perform readings on layers of asphalt with thickness of 3.33 inches or less, use the following method (formula): × WD – DB DT = 1 – K where: DT = Overlay density WD = Density read by gauge...
  • Page 49 3.3 inches (84 mm) of the overlay. In applications where the overlay thickness is greater than 3.3 inches (84 mm), use (0) for the k value or use the actual gauge readings (WD). Model 3411-B Advanced Control Unit 3–13...

  • Page 50: K Values For Thin Lift Overlays

    Table 3–1. K Values for Thin Lift Overlays Thickness Thickness Thickness Thickness (inches) (mm) (inches) (mm) 0.46159 0.13459 0.44787 0.12880 0.43414 0.12078 0.42042 0.11275 0.40138 0.10781 0.38235 0.10285 0.36475 0.09790 0.35889 0.09104 0.34716 0.08418 0.33631 0.07995 0.32547 0.07572 0.31462 0.07149 0.29958 0.06562 0.28454...
  • Page 51 CHAPTER 4 SPECIAL FUNCTIONS This chapter gives brief explanations of the Special functions available on the Model 3411-B Advanced Control Unit (ACU), or directs the reader to the appropriate section dealing with a particular function. CONTENTS Recall .................... 4–2 Offset .................... 4–2 Stat Test ..................

  • Page 52: Recall

    RECALL The Recall function allows the operator to view the data from the last reading. Even though the ACU does not store multiple readings, this function displays the latest data. To access the Special functions, press 〈SPECIAL〉. To access the Recall feature, press 〈START/ENTER〉. The gauge displays the data from the last measurement.
  • Page 53 Upon completion of the stat test, the gauge displays the pass/fail status. If the stat test fails, repeat the test twice more. If two out of three stat tests fail, contact Troxler Technical Support (see page B-11). If the stat test passes, the display is: D: PASS M: PASS ↑↓...
  • Page 54 Moist R = x.xxx ↑↓ to view data Moist Avg. x ↑↓ to view data • • • #20D xxx M xxx (Use ↑ & ↓ keys) 4–4...

  • Page 55: Drift Test

    START for 20 m. Drift Test To begin the five counts, press 〈START/ENTER〉. - DRIFT TEST - Rdg.#:xx xxx sec As with the stat test, the gauge indicates the count progress during the drift test. Model 3411-B Advanced Control Unit 4–5...
  • Page 56 After the five counts have been completed, the display is: D: PASS M: PASS ↑↓ to view data To view the drift test data, use the up and down arrow keys. D % Drift xx.xx ↑↓ to view data Dens. Avg. xx ↑↓...

  • Page 57: Special Calibration

    To change the value of the flashing digit, use the up and down arrows. To accept the flashing value and select the next digit, press 〈START/ENTER〉. If a value is not entered, the default value is 2.70, the “typical” specific gravity for soil. Model 3411-B Advanced Control Unit 4–7...

  • Page 58: Voidless Density

    VOIDLESS DENSITY The Voidless Density function allows the input of the theoretical voidless density value of the material being measured. This value is used in the % Voids calculation. To access the Special functions, press 〈SPECIAL〉. To access the Voidless Density feature, press the down arrow six times and press 〈START/ENTER〉.

  • Page 59: Calibration Constants

    This function is for authorized service personnel only! CAUTION Memory Reset erases all data stored in the gauge and sets all constants, except calibration constants, to the default values. TEST READING NOTE This function is for authorized service personnel only! Model 3411-B Advanced Control Unit 4–9...

  • Page 60: 15-Second Inhibit

    15-SECOND INHIBIT The 15-Second Inhibit function enables the gauge owner or operator to disable the 15-second count option. When this function is enabled, the gauge can only conduct one- or four-minute counts. To disable the 15-second count option, first access the Special functions by pressing 〈SPECIAL〉.
  • Page 61 Model 3411-B Advanced Control Unit (ACU). Note that the measurement, radiological, mechanical, and calibration specifications of the Model 3411-B are not affected by the retrofit, and are therefore unchanged from those shown in the Model 3400-B Manual of Operation and Instruction originally supplied with the gauge.

  • Page 62: Electrical Specifications

    ELECTRICAL SPECIFICATIONS Stored Power 40 watt-hours Battery Recharge Time 14 to 16 hours Gauge Charging 12 V dc, 500 mA minimum Requirements Liquid Crystal Display 2 line x 16 character alphanumeric Keypad 10-key sealed membrane Power Consumption < 0.10 watts average Appendix A–2...
  • Page 63 This appendix contains information on troubleshooting a Model 3411-B gauge when retrofitted with the Model 3411-B Advanced Control Unit (ACU), as well as information on charging the gauge battery. If a serious problem with the gauge arises, contact Troxler Technical Support (see page B–11) for instructions. CONTENTS Troubleshooting................B–2...

  • Page 64: Troubleshooting

    Model 3400-B Manual of Operation and Instruction. If the sliding block still does not close completely, contact the nearest Troxler Technical Support (see page B–11). Compare the current standard counts to the calibration standard counts. If they are within 1% for DS and 2% for MS, accept the standard count, then perform and accept four more standard counts.
  • Page 65 3. Report lost or missing radioactive sources to your state or federal radiation control agency in accordance with applicable regulatory requirements. 4. Contact the Troxler Radiation Safety Department for further advice. GAUGE READINGS APPEAR ERRATIC Ensure that the source rod is properly locked in the desired backscatter or direct transmission position, and is not resting on the test material.
  • Page 66 B and F values from English to metric units.) If necessary, perform a statistical stability (stat) test (see page 4–2), record the results and contact Troxler Technical Support (see page B–11). GAUGE TURNS OFF AFTER IT IS TURNED ON The gauge automatically turns off after five hours if no keys are pressed.
  • Page 67 Check calibration constants. Check to see if an offset (density, moisture, trench or special) is enabled. Ensure that the standard counts are correct. Ensure that the index rod is seated in bottom of notch. Model 3411-B Advanced Control Unit Appendix B–5...
  • Page 68 Gauge Fails Stability or Drift Tests ERROR MESSAGES The following error messages are not user-serviceable. Contact Troxler Technical Support (see page B–11) for more information. KEY PAD TEST ERROR! GM TUBE TEST ERROR! HELIUM TUBE TEST ERROR! DISPLAY TEST ERROR!

  • Page 69: Battery Charging

    “memory” and repeated unnecessary recharging will shorten the battery life. If possible, run the batteries down before recharging. NOTE Batteries should not be recharged unless the Battery Low! indication is displayed! Model 3411-B Advanced Control Unit Appendix B–7...

  • Page 70: Replacement Parts

    REPLACEMENT PARTS Figure B–1 shows the replaceable parts of the Model 3411-B Advanced Control Unit. Match the reference number (Ref #) shown below with the correct part in Figure B–1. Ref # Part Number Description 000001.0400 #4 Internal Lock Washer 000204.1400...

  • Page 71: Model 3411-B Acu Assembly

    Figure B–1. Model 3411-B ACU Assembly Model 3411-B Advanced Control Unit Appendix B–9...

  • Page 72: Returning The Gauge For Service

    RGA (Returned Goods Authorization) number, and a description of the instrument and its problem. This information is used by Troxler shipping and service personnel to expedite the repair work. To obtain an RGA number, please call or fax the factory or branch office with your request.

  • Page 73: Troxler Service Centers

    Troxler European Subsidiary Southwestern Branch Office Troxler Electronics GmbH 2016 East Randol Mill Road Gilchinger Strasse 33 Suite 406 D.82239 Alling nr. Munich, Germany Arlington, TX 76011 Phone: ++49.8141.71063 Fax: 817.275.8562 Fax: ++49.8141.80731 E-mail: troxler@t-online.de Model 3411-B Advanced Control Unit Appendix B–11...
  • Page 74 NOTES Appendix B–12...
  • Page 75 Constants................1–4, 4–9 Special..................3–8 Code, access..................xi Count time ..................2–6 Density Offset ..................3–3 Voidless ..................4–8 Depth of measurement ..............2–6 Drift test ..................4–5 Error messages................B–6 Installation ..................1–3 Keypad..................2–2 Model 3411-B Advanced Control Unit Index–1...
  • Page 76 Measurement Asphalt mode................2–16 Depth ..................2–6 Mode..................2–6 Site preparation................2–10 Soil mode.................2–13 Thin layer ................3–12 Units ..................2–5 Memory reset.................4–9 Mode Asphalt ..................2–6 Ready..................2–4 Soil ....................2–6 Moisture offset ................3–4 Offset .....................3–2 Density ..................3–3 Moisture ..................3–4 Trench..................3–6 Parts, replacement ................ B–8 Percent air voids ................2–15 Ready mode...................2–4 Recall.....................4–2 Replacement parts ................
  • Page 77 Test Drift................... 4–5 Stat .................... 4–2 Test reading .................. 4–9 Thin layer measurements ............3–12 Time, count ................... 2–6 Trench offset................. 3–6 Troubleshooting................B–2 Units, measurement ..............2–5 Void ratio ..................2–15 Voidless density................4–8 Model 3411-B Advanced Control Unit Index–3...
  • Page 78 NOTES Index–4...
  • Page 79 NOTES Model 3411-B Advanced Control Unit Warranty–1...
  • Page 80 Normal use is defined for the purpose of this warranty as operation under normal load, usage, and conditions with proper care and maintenance and competent supervision. In no event shall TROXLER be held liable for damages, delays, or losses consequential, incidental, or otherwise attributable to the failure of this instrument.
