SPECIFICATIONS

NOTE : Specifications and others are subject to change without notice for improvement.
Video input system:
¡
Multi 26 System
(Refer to Table 1)
Intermediate Frequency
¡
Vision IF : 38.0MHz
Color IF : 33.57MHz
34.42MHz(M)
Sound IF : 32.5MHz(B/G)
32.0MHz(I)
31.5MHz(D/K,K1)
33.5MHz(M)
Tuning range
¡
Band
For TV
Ch 2-4
VHF-Low
VHF-High
Ch 5-12
Hyper
Ch 21-69
UHF
OSD (On Screen Display):
¡
Menu Method
Antenna input impedance: VHF/UHF 75ohm, Unbalanced
¡
Voice coil impedance : 8 ohm
¡
External connections :
¡
S-VIDEO (Super Video)
A/V in
: 1 pair
S-VIDEO (Super Video)
Scart(Full)
A/V in
: 1 pair
A/V out : 1 pair
Video in/out
Audio in (2 way)
Audio out (2 way)
R. G. B in
¡ SECAM : 38.0-4.25MHz
(
38.0-4.40625MHz
PAL/SECAM-B/G
For CATV
S1'-S3', S1
S2-S10
S11-S20
S21-S41
Front
Rear
Specifications
1Vp-p¡ 3dB, 75ohm
0.5Vrms¡ 3dB, over 10Kohm
0.5Vrms¡ 3dB, below 1Kohm
0.7Vp-p¡ 3dB
Power requirements :
¡
100-270 Vac, 50/60HZ
Power consumption :
¡
210 Wmax.
Tuning system :
¡
VS (Voltage Synthesizer)
100 Program Memory
Sound output :
¡
25 W max. X 2 way: (4 speaker)
Dual / Stereo : A2, NICAM
Local button :
¡
Menu, OK, TV/AV, POWER
Volume up(+), down(-)
Program up(+), down(-)
Function :
¡
Auto Program
Manual Program
Auto Sleep
ON/OFF TIMER
CATV/Hyper band
Teletext (TOP/FLOF/LIST)
PIP (Picture In Picture)
Child Lock :
In the Lock On state the TV can only be operated by the
remote controller.
If any button on the front panel is pressed, "CHILD LOCK ON" is
displayed on the screen but the button's function is not
performed.
To cancel of this mode, select lock off with menu button on
remote controller only.
Features
¡
Picture quality improvement circuit
- YNR (Luminance Noise Reduction)
- Picture Outline Compensation
- 6 -
