Tripodmaker User Manual page 22

4. Press the white home button ( ) before
using any navigation buttons. The print head
now moves up towards the end stops.
! Attention: Do not use the X/Y navigation
as the vertical carts might crash on the
end stops.
5. Screw down the build plate by rotating the
screws clock wise.
6. Use the Z controller to move the print head
down.
Z000.00 should be readable on the printer
controller to show that the printer head is at its
lowest position.
! Attention: When the printer wasn't
homed before, Z000.00 is also shown.
7. Navigate your print head around the build
plate with the X/Y controller and adjust the 3
leveling screws with a size 3 allen wrench.
! Attention: Leaving too much time
between movements disables the motors
and leads to loss of cart position. Re-use
the home button ( ) to have a good
position reference in case the carts were
able to move freely.
Advice on leveling is found in the Leveling
Procedure section.
22 |
