Spool holder

Attaching the spool holder
1. The spool holder is mounted with two T-nuts
and two M4 x 8 bolts.
2. Mount the holder on the vertical slide near
the filament driver by sliding the T-nuts in the
aluminum beam.
3. Position the holder and screw on the M4 x 8
nuts firmly. By turning the bolts, the T-nut will
rotate inside the aluminum beam and hook
behind the profile edges. Make sure the T-nuts
turn 90 degrees.
Detaching the spool holder
Untighten the M4 x 8 nuts. The T-nuts will align
with the profile edges and you will be able to
remove the spool holder.
