Installation Manual
adt-audio
Installation
SRC
Manual
5 1
Part II:
Connectors
Pinning Diagrams
Description of Connectors
for Consoles without Patchbay
Version 1.6/14 • English
analoge + digitale Tonstudiotechnik Karl Jüngling • Inh. Dipl.-Ing. Gerd Jüngling
4-6, Scholtwiese • Gladbeck • 45966 • NRW • Germany • Phone: 0049 2043 51061 • Fax: 0049 2043 56844
E-Mail: info@adt-audio.com • Internet: www.adt-audio.com www.broadcast-console.com
Advertisement
Table of Contents
Related Manuals for adt-audio SRC51
Summary of Contents for adt-audio SRC51
- Page 1 Version 1.6/14 • English analoge + digitale Tonstudiotechnik Karl Jüngling • Inh. Dipl.-Ing. Gerd Jüngling 4-6, Scholtwiese • Gladbeck • 45966 • NRW • Germany • Phone: 0049 2043 51061 • Fax: 0049 2043 56844 E-Mail: info@adt-audio.com • Internet: www.adt-audio.com www.broadcast-console.com...
-
Page 2: Table Of Contents
Summary Preface..............3 3. Connectors............4 3.1 Technical data of Inputs and Outputs....4 3.2 Connector Types............5 3.3 Connector Panels........... 7 Input Channel Connector Panels....7 Master Section Connector Panel...... 8 Connectors on the Master Panel in brief..8 Pinnings of the Master Connectors.... -
Page 3: Preface
This manual concerns the 5.1 surround sound versions of the SRC51 console system for consoles without patchbay Version V1.6/2014... -
Page 4: Connectors
> 3 kOhms with pad. CMRR in accordance to IRT standards is > 70dB at Level frequencies <=15 kHz. The nominal level of the SRC51 system is determined by the customer. It Line level inputs is only fixed by the adjustment of the system meters that can be set to All line level inputs, including insert inputs, are electronically balanced. -
Page 5: Connector Types
Four versions of the connector panel versions. If you’re in doubt if your console has some special features that The connections for each module type of the SRC51 consoles are affect the connector pinning, please ask. standardized. There are two types of connector panels. - Page 6 The best choice is always to take care about clean grounding, before any kind of compensation techniques are used. Please, aks for advice (0049 2043 51061 – support@adt-audio.com) if you have any questions or problems. Special Terms:...
-
Page 7: Connector Panels
All audio lines are fully balanced and at nominal level. Since all modules have swit- SURROUND: IN-L ched insert points, there is no need to connect the insert inputs and outputs ex- ternally. The insert point is only activated when the insert switch of the particular channel is pressed. SRC51... -
Page 8: Master Section Connector Panel
It holds 17 D-Sub connectors, the power connector and a ground 2TR/17-20 2TR/9-12 6TR/2TR-A TB-AUDIO CTR-INS-IN CTR-INS-OUT MIX-INS-IN MIX-INS-O POWER-IN Connector Bay of a SRC51 Console connector. Even though the pinning of all connectors is the same with all 2TR/21-24 2TR/13-16 6TR/2TR-B STUDIO TB-CTRL ST-SPK SRD-SPK MIX-OUT versions of the console. - Page 9 Stereo speaker outputs for the alternate and mini speakers of the CT5 control room module. SRD-SPK Outputs of the main surround speakers of the CT5 control room module. MIX-OUT Surround master outputs and stereo matrix outputs of the MS5 USER-SWIITCH surround master module. SRC51...
-
Page 10: Pinnings Of The Master Connectors
Pinnings of the Master Connectors setting of the MS5 module. With stereo mode, Mix-Insert In / Aux 1 & Aux 2 Out. the downmix outputs are identical to the MIX- Mix Outputs OUT-L and MIX-OUT-R signals. The mix insert inputs of the MS5 surround ma-... -
Page 11: Ctr-Insert Out / Aux 3 & Aux 4 Out
CTR-INSERT OUT / AUX 3 & 4 OUT CONTROL ROOM INSERT IN & CTR-SURROUND SPEAKER OUT 2-TRACK C REPRO THIS CONNECTOR IS INSTALLED IN CONSOLES WITH AND WITHOUT PATCH-BAY. WITH PATCH-BAY IT IS CONNECTED DIRECTLY TO THE INSERT OUTPUT OF THE CTR MODULE... -
Page 12: Ctr-Stereo Speaker Out
CTR-STEREO SPEAKER OUT 6-TRACK/2-TRACK A REPRO 6-TRACK/2-TRACK B REPRO if STU module is installed, the 2-TRACK A pins are connected to if TBO module is installed, the 2-TRACK B pins are connected to the output of the extension selector in the STU module. -
Page 13: 2-Track 9-12 Repro
2-TRACK 9 - 12 REPRO 2-TRACK 13 - 16 REPRO 2-TRACK 17 - 20 REPRO THIS CONNECTOR IS ALWAYS INSTALLED THIS CONNECTOR IS ALWAYS INSTALLED THIS CONNECTOR IS ALWAYS INSTALLED BUT REQUIRES THE TBO MODULE TO BE FUNCTIONAL! BUT REQUIRES THE STU MODULE TO BE FUNCTIONAL! -
Page 14: 2-Track 21-24 Repro
2-TRACK 21 - 24 REPRO TALKBACK AUDIO STUDIO PHONES & SPEAKERS THIS CONNECTOR IS ALWAYS INSTALLED THIS CONNECTOR IS ALWAYS INSTALLED BUT THIS CONNECTOR IS ALWAYS INSTALLED BUT BUT REQUIRES THE TBO MODULE TO BE FUNCTIONAL! REQUIRES THE TBO MODULE TO BE FUNCTIONAL... -
Page 15: Talkback Control
Adding to re- Talkback Control sistors in series make possible to adapt the gain TALKBACK CONTROL to a line level signal. For 0 dB gain, 2 47 k-ohm This connector is used for the control inputs and THIS CONNECTOR IS ALWAYS INSTALLED BUT resistors are required. -
Page 16: User Switch
