- Page 1 Installation and Operation Manual PTG-10 Pilot Tone Generator Designed and Manufactured by: JPS Interoperability Solutions 5800 Departure Drive Raleigh, NC 27616 919-790-1011 Email: sales@jpsinterop.com support@jpsinterop.com JPS P/N 5970-900200 Revision 4.0 May 19, 2016...
- Page 2 PROPRIETARY STATEMENT The information contained in this manual is the property of JPS Interoperability Solutions and is intended for the purchaser’s use only. It may not be reproduced without the expressed written consent of JPS Interoperability Solutions.
-
Page 3: Table Of Contents
PTG-10 Operations Manual Table of Contents GENERAL INFORMATION ..........................1-1 ..............................1-1 COPE ............................1-1 ESCRIPTION 1.2.1 General ............................1-1 1.2.2 Circuitry and Block Diagrams ......................1-2 1.2.3 Mechanical Assembly ........................1-2 1.2.4 Function and Operation ........................1-2 1.2.5 Power Supply ..........................1-2 1.2.6... -
Page 4: List Of Figures
PTG-10 Operations Manual List of Figures 2-1 – O ........................2-5 IGURE UTLINE IMENSIONS 2-2 – L ................2-6 IGURE OCATIONS OF NDICATORS AND DJUSTMENTS 5-1 – C 1........................... 5-2 IGURE IRCUIT IAGRAM 5-2 – C 2........................... 5-3 IGURE IRCUIT IAGRAM 5-3 –... -
Page 5: General Information
(a DC logic signal) exits the receiver on another wire making it impossible to carry both the audio and the COR on the same audio pair. The PTG-10 converts the COR signal to a tone which is mixed with the audio from the receiver, removing the need for a COR line. The PTG-10 works by injecting a pilot tone on the audio line whenever the associated receiver is squelched, and removes the tone whenever the receiver is unsquelched. -
Page 6: Circuitry And Block Diagrams
Please refer to Figure 5-4. The PTG-10 enables two conductors to carry both an audio signal and a COR signal. The PTG-10 can also function as a line proving tone to insure the integrity of the audio link. The tone produced by the PTG-10 will be notched out in the voter. Two LEDs allow status monitoring. - Page 7 PTG-10 Operations Manual rejection that a balanced link provides is not needed on the input signal. In contrast, the unit’s audio output is balanced, as the output is likely to be sent over a long distance. Table 1-1 SPECIFICATIONS Electrical...
- Page 8 PTG-10 Operations Manual Blank Page Interoperability Now!
-
Page 9: Installation
If it is necessary to return the equipment to the manufacturer, a Returned Material Authorization (RMA) number must first be obtained from JPS. This number must be noted on the outside of the packing carton and on all accompanying documents. When packing the unit for reshipment, it is best to use the original packaging for the unit;... -
Page 10: Installation Overview
Screws are provided in the accessory kit for securing the unit to the rack via the front panel. 2.6 Power Requirements The PTG-10 is designed to operate from +11 to +15 VDC. Power consumption is 0.5 VA typical. Interoperability Now! -
Page 11: Configuring The Ptg-10
(0) will produce a 2175 Hz tone; position (1) will produce a 1950 Hz tone. 2.7.2 Potentiometer Adjustments The PTG-10 has two factory set potentiometers. See Figure 2-1. “Overall Adjust” (R8) is set so that a -10 dBm input will produce a 0 dBm output. “Pilot Adjust” (R4) is also set for 0 dBm output. -
Page 12: Interconnect Information
The unit is factory set for the audio input level from the receiver to be -10 dBm and the audio output level of the PTG-10 to be 0 dBm. The PTG-10 is also factory set for the pilot tone level to be 0 dBm. - Page 13 PTG-10 Operations Manual 6.84 5.24 2.50 1.25 0.63 1.19 NOTES: A. 19" RACK MOUNT SLOTS (.45 X .25 DIA.) B. OPTIONAL MOUNTING HOLES .166 DIA. Figure 2-1 – Outline Dimensions Interoperability Now!
- Page 14 PTG-10 Operations Manual Figure 2-2 – Locations of Indicators and Adjustments Interoperability Now!
-
Page 15: Operation
PTG-10 Operations Manual 3 Operation 3.1 General This section contains information and instructions required for proper operation of the PTG-10. 3.2 Operational Indicators 3.2.1 Power Indicator This green LED, which can be viewed through a slot in the top cover, is illuminated whenever the unit’s main power is on and the power supply circuitry is functioning correctly. - Page 16 PTG-10 Operations Manual Blank Page Interoperability Now!
-
Page 17: Theory Of Operation
4.2 Tone Circuit Refer to Figure 5-1. Terminal block JP1interfaces all inputs and outputs between the PTG-10 and the outside world. Receiver Audio enters the unit at terminals 4 (RX In) and 1 or 7 (ground). - Page 18 PTG-10 Operations Manual Blank Page Interoperability Now!
-
Page 19: Maintenance And Repair
PTG-10 Operations Manual 5 Maintenance and Repair 5.1 General This section gives enough detail about the theory of operation in regard to the audio and power supply sections to allow them to be trouble shot in the field. 5.2 Preventive Maintenance There are no preventive or periodic maintenance requirements for this equipment. - Page 20 PTG-10 Operations Manual Balanced Output B Balanced Output A Unbalanced Input Header 8 Overall Level Mixer Adjust- Tone Level -4 to +20dB Gain Adjust- AMBER -25 to +9dB Gain TONE PRESENT SW 1 TONE SWITCH /COR RS-232 Mega 8L DB-9...
- Page 21 PTG-10 Operations Manual PTG-10 DC Input Unbal Audio Out B RX Audio RF Test Tone /COR Receiver Generator To Voter Ground Unbal Audio Out A 1 or 7 AC Volt Meter Figure 5-2 – Circuit Diagram 2 Interoperability Now!
- Page 22 PTG-10 Operations Manual PTG-10 +12VDC Input Balanced Output B Balanced Output A Unbalanced Input /COR Input COR Input Header 8 Balanced Outputs - Wired to Voter Input Unbalanced Input - Wired to Radio Receiver Audio Output /COR Input - Wired to Receiver’s COR or COS Line (low signal creates tone) COR Input - Wired to Receiver’s COR or COS Line (high signal creates tone)
- Page 23 PTG-10 Operations Manual MICROWAVE LINK SIGNAL PTG-10 Distant Receiver SITE 1 Voter Distant SITE 2 SIGNAL PTG-10 Receiver Leased Line or Two Conductor Audio Line Figure 5-4 – Block Diagram 1 Interoperability Now!
- Page 24 PTG-10 Operations Manual Blank Page Interoperability Now!
-
Page 25: Index
Mechanical Assembly .......... 1-6 Address ............... 2-9 Operation ............3-15 Operational Indicators ........3-15 Circuitry and Block Diagrams ......1-6 Configuring the PTG-10 ........2-10 COR Indicator ............ 3-15 Potentiometer Adjustments ........ 2-11 Power Indicator ..........3-15 Power Requirements .......... 2-10 Power Supply .......... - Page 26 PTG-10 Operations Manual Blank Page Interoperability Now!
