MANOR 4x6S
ASSEMBLY INSTRUCTIONS | INSTRUCCIONES DE MONTAJE | MONTAGEANLEITUNG | CONSIGNES
DE MONTAGE | SAMLEVEJLEDNING | MONTAGE-VOORSCHRIFTEN | ISTRUZIONI D'ASSEMBLAGGIO
Thank you for your purchase of the Keter shed,
In order to activate your warranty, please enter
WARRANTY
www.keter.com, under storage buildings
ACTIVATION
category and fill in the sheds warranty
activation form.
IF THERE ARE MISSING OR BROKEN PARTS, PLEASE DO NOT RETURN THE PRODUCT TO THE STORE
Please log onto our website, or contact Customer Service at:
S'IL Y A DES PIÈCES MANQUANTES OU CASSÉES, NE RETOURNEZ PAS LE PRODUIT AU MAGASIN
Veuillez visiter notre site Internet, ou contacter notre Service Clientèle:
BITTE
BRINGEN SIE IHR PRODUKT NICHT GLEICH ZUM LADEN ZURÜCK, FALLS TEILE FEHLEN ODER DEFEKT SIND.
Bitte loggen Sie in unsere Website ein oder wenden Sie sich an unseren Kundenservice:
SI HUBIERA ALGUNA PARTE FALTANTE O DAÑADA, NO DEVUELVA EL PRODUCTO A LA TIENDA
Inicie sesión en nuestro sitio en Internet o contáctese con nuestro servicio de atención al cliente:
IN GEVAL
VAN ONTBREKENDE OF GEBROKEN ONDERDELEN NIET HET PRODUCT NAAR DE WINKEL RETOURNEREN.
Ga naar onze website of neem contact op met de Klantenservice:
IN CASO
DI PARTI MANCANTI O DANNEGGIATE, EVITARE DI RESTITUIRE IL PRODOTTO AL NEGOZIO.
Accedere al nostro sito o contattare il Servizio Clienti:
SE HOUVER
PEÇAS EM FALTA OU PARTIDAS, NÃO DEVOLVA O PRODUTO À LOJA.
Entre na nossa página de Internet ou contacte o Serviço de Clientes:
MANOR 4x6S
2 easy steps to use a QR-code:
1. Download a FREE QR-Code
reader from your smartphone
application site.
2. Scan the QR-Code.
SKU:
17197126 | 17194155
WWW.KETER.COM
US: # 1-888-374-4262
Canada: # 1-800-661-6721
UK: # 0121-5060008
Other European Countries:
# 31-1612-28301

Advertisement

Table of Contents
loading

Summary of Contents for Keter MANOR 4x6S

  • Page 1 SKU: MANOR 4x6S 17197126 | 17194155 2 easy steps to use a QR-code: Thank you for your purchase of the Keter shed, 1. Download a FREE QR-Code In order to activate your warranty, please enter WARRANTY reader from your smartphone www.keter.com, under storage buildings...
  • Page 3 LEVEL THE GROUND | NIVELLEMENT DU SOL | NIVELE EL SUELO | SORGEN SIE FÜR EINE EBENE GRUNDFLÄCHE MAAK DE GROND WATERPAS | METTERE IL TERRENO A LIVELLO | NIVELAR O SOLO Clear area of stones | Remove all plants, roots and other obstacles | Rake the ground | Make ground level using a long, flat object (e.g.
  • Page 4 GENERAL PARTS LIST Walls Parts Roof Parts Door Parts Floor Parts Window Parts FLOOR PARTS LIST (go to stage 1) fc1(x2) 172 cm t (x4) c1z(x2) s26b (x12) 106 cm 26 mm WINDOW PARTS LIST (stage 25) f-out f - out (x1) f-in (x1) f-in (x1)
  • Page 5 WALL PARTS LIST (stage 6) v (x2) bu1b bu1b (x1) 190x111 cm s1d (x1) 88x172 cm fu1b (x1) 190x111 cm w1d (x3) 88x172 cm cc (x4) s13b (x4) 168 cm 12mm s26b (x60) h1c (x2) 26 mm 165 cm DOOR PARTS LIST (stage 22) s13b (x21) dl (x1)
  • Page 6 FLOOR ASSEMBLY t (x1) fc1(x2) c1z(x2) t (x4) 172cm 106cm...
  • Page 7 Flip the floor upsidedown s26b(x12) 26mm s26b fully fit the panel inside the porfile...
  • Page 8 Flip the floor upsidedown WALL ASSEMBLY Choose where do you wan to locate the window...
  • Page 9 cc1(x1) w1d(x1) 168cm 88cm x172cm s26b(x8) bu1b(x1) 26mm fully fit the panel inside the porfile...
  • Page 10 cc1(x1) w1d(x1) s26b(x8) 168cm 88cm x172cm 26mm fully fit the panel inside the porfile h1c(x2) 165cm fully fit the panel inside the porfile...
  • Page 11 s13b (x4) w1d(x1) s1d(x1) 88cm x172 cm 88cm x172 cm 13mm s13b inside view fully fit the panel inside the porfile cc(x2) s26b(x8) 26 mm 168 cm fully fit the panel inside the porfile...
  • Page 12 s26b(x8) fu1b (x1) 190cm x 111cm 26mm s26b(x27) 26mm fully fit the panel inside the porfile...
  • Page 13 ROOF ASSEMBLY r1m(x1)folded rc1(x2)172cm e1d(x4) 56cm rc(x4) Note: The roof folding line and the ''this side down'' label, must be seen at this stage. s26b(x8) 26mm fully fit the panel inside the porfile...
  • Page 14 s26b(x24) 26mm s26b...
  • Page 15 s26b(x16) 26mm screwe on the mark line...
  • Page 16 DOOR ASSEMBLY s13b(x11) d(x1) dh(x2) 12mm dl(x1) Pre-drilled holes Pre-drilled holes...
  • Page 17 s13b (x10) 12mm dl (x1)
  • Page 18 ROOF CROWN ASSEMBLY s26b(x4) kc(x2) 26mm s26b VENT ASSEMBLY v (x2) Push vent into position. Your helper holds the wall from the inside.
  • Page 19 WINDOW ASSEMBLY pls (x1) f - out (x1) acw (x1) f-out...
  • Page 20 f-in (x1) sc15 (x7) 18mm f-in...
  • Page 21 In case a problem should occur, please address your claim to customer service either by phone or through our web site: www.keter.com. The warranty is valid as of the date of purchase and a dated proof of purchase should be presented on request.
  • Page 22 GARANZIA LIMITATA DI 2 ANNI L’ottima reputazione di cui gode Keter per i suoi prodotti è il risultato di una dedizione e di un impegno costante verso la qualità, il design e l’innovazione. L’intera gamma degli armadietti e dei box viene prodotta con materiali di prima qualità, sotto un controllo e una supervisione rigorosi. Se dovesse presentarsi un problema, presentare reclamo al servizio d’assistenza, per telefono o attraverso il nostro sito Web: www.keter.com.
  • Page 23 • Tragen Sie beim Gebrauch von Elektrowerkzeugen eine Schutzbrille und folgen Sie stets der Anleitung des Herstellers. • Bitte verwenden Sie zur Reinigung des Schuppens einen Gartenschlauch oder ein mildes Putzmittel. D ie Verwendung von harten Bürsten oder anderen ungeeigneten Putzgeräten kann das Material beschädigen. •...
