7SR224 Recloser Controller
Overcurrent Relay
Document Release History
This document is issue
2010/05.
2008/03
First issue
2008/06
Second issue
2009/09
Third issue
2010/04
Fourth issue
2010/05
Fifth issue. Document reformatted due to rebrand.
Software Revision History
2008/03
2435H80011R2d-1a
2008/06
2435H80011R3d-2b
2008/10
2435H80011R4-3
2009/09
2435H80011R4c-3b
2010/04
2434H80011R4d-4
The copyright and other intellectual property rights in this document, and in any model or article produced from it
(and including any registered or unregistered design rights) are the property of Siemens Protection Devices
Limited. No part of this document shall be reproduced or modified or stored in another form, in any data retrieval
system, without the permission of Siemens Protection Devices Limited, nor shall any model or article be
reproduced from this document unless Siemens Protection Devices Limited consent.
While the information and guidance given in this document is believed to be correct, no liability shall be accepted
for any loss or damage caused by any error or omission, whether such error or omission is the result of
negligence or any other cause. Any and all such liability is disclaimed.
©2010 Siemens Protection Devices Limited
The list of revisions up to and including this issue is:
First Release
Second Release. Loss Of Voltage
Third Release. Single/Triple AutoReclose function
Fourth Release. Software maintenance release.
Fifth Release. Synchronising
7SR224 Argus Commissioning & Maintenance Guide
