NetPoint Pro 6X2.4
Outdoor Wi-Fi Base Station

Installation Guide

Rev. 7
August 2008
Note: To better reflect the value of Netronics products we are changing the name of our
product family from NetPoint to NetPoint Pro, consequently the name for the existing product
with 6 antennas will be NetPoint Pro 6X2.4.
The new product name emphasizes the difference in architecture (Multiple Radio system) and
the value to customer, superiority in performance (coverage, capacity, indoor penetration and
immunity to interference) of Netronics WiFi base station over any other standard outdoor WiFi
access point products available in the market.
Copyright Notice

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetPoint Pro 6X2.4 and is the answer not in the manual?

Questions and answers

Related Manuals for Netronics NetPoint Pro 6X2.4

Summary of Contents for Netronics NetPoint Pro 6X2.4

  • Page 1: Installation Guide

    Rev. 7 August 2008 Note: To better reflect the value of Netronics products we are changing the name of our product family from NetPoint to NetPoint Pro, consequently the name for the existing product with 6 antennas will be NetPoint Pro 6X2.4.
  • Page 2 ©2006, 2007, 2008 Netronics, Inc. All rights reserved. Netronics is a registered trademark of Netronics in the Canada and certain other jurisdictions. Specifications are subject to change without notice. FCC Notice to Users and Operators This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 Installation Guide...

  • Page 4: Table Of Contents

    Contacting Technical Support ................7 Introduction ................8 C h a p t e r 2 Installing the Netronics NPP 6X2.4 Metro Base Station ..10 C h a p t e r 3 Important Safety Instructions ................. 11 Preparing for Installation ................12 Installation Hardware and Tools ..............

  • Page 5: Installation Guide

    AC Wiring Power Cable 120VAC, 15A Plug ..........55 Wind Loading Considerations ..........57 C h a p t e r 8 Backhaul Unit Installation Instructions ........59 C h a p t e r 9 Acronyms ................61 C h a p t e r 1 0 Appendix A: NPP 6X2.4 Product list ........

  • Page 6: About This Guide

    Chapter 1 About This Guide Preface This guide details the Netronics NPP 6X2.4 installation procedures. The intended audience of this document is trained technical professionals. Conventions The exclamation point within a triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

  • Page 7: Contacting Technical Support

    Contacting Technical Support For technical support, contact Netronics using these methods: support@Netronics-networks.com Email: www.Netronics-networks.com Web: Installation Guide...

  • Page 8: Introduction

    The NPP 6X2.4 is a new category of Wi-Fi Base Station designed from the ground up for metro- Wi-Fi deployments. It is based on six antennas and radios and custom-built ASICs, utilizes Netronics's powerful multi-antenna signal processing technologies, and provides significant performance gains to off-the-shelf 802.11 standards-based Wi-Fi clients.
  • Page 9 Introduction Installation Guide...

  • Page 10: Installing The Netronics Npp 6X2.4 Metro Base Station

    Chapter 3 Installing the Netronics NPP 6X2.4 Metro Base Station This guide explains how to safely install the Netronics NPP 6X2.4 Metro Base Station. The following topics are covered in this chapter: • Important Safety Instructions on page • Preparing for Installation on page •...

  • Page 11: Important Safety Instructions

    Installing the Netronics NPP 6X2.4 Metro Base Station Important Safety Instructions ARNING It is illegal to modify the construction of this product. Modifying the operating frequency or enhancing the transmit output power through the use of external amplifiers or other equipment is specifically disallowed by the "Telecommunications Act."...

  • Page 12: Preparing For Installation

    Preparing for Installation The Netronics NPP 6X2.4 must be installed by a trained professional, or systems integrator who is familiar with RF planning issues and regulatory limits as defined by the governing body of the country in which the unit will be installed.

  • Page 13: Installation Hardware And Tools

    • Wood brace mounting only: four 5/8-inch diameter, 3-inch long lag bolts Choosing a Location The Netronics NPP 6X2.4 is a radio device and susceptible to interference that can reduce throughput and range. To ensure the best performance follow these guidelines: •...

  • Page 14: Power Source Options

    • DC power source (2-wire service); 48VDC. See Installation Accessories on page details. • The NPP 6X2.4 can be powered by a Netronics Injector connected to Ethernet port B (ETH B). See Installation Accessories on page for details.

  • Page 15: Using Hose Clamps

    Note : The NPP 6X2.4 should be mounted with at least 4 ft of clearance around the antennas to eliminate potential interference from the mounting structure. Figure demonstrates acceptable options for mounting on a streetlight. In both cases the NPP 6X2.4 is mounted to ensure clearance for the antennas above the height of the streetlight. Figure 3.1 Example Mounting Locations on a Streetlight Using Hose Clamps...

  • Page 16: Mounting On A Pole, Or Streetlight

    Using Hose Clamps Mounting on a Pole, or Streetlight The following explains how to mount the Netronics NPP 6X2.4 on a pole, tower, or streetlight. It is recommended to mount the NPP 6X2.4 on aluminum or galvanized steel structures. Note The Netronics NPP 6X2.4 must be mounted with the top of the unit parallel with...
  • Page 17 Figure 3.3 Mounting on a Metal Pole Figure 3.4 Mounting on a Wooden Pole Installation Guide...
  • Page 18 To mount the Netronics NPP 6X2.4 on a metal or wood pole: 1. Choose a mounting location. You can attach the NPP 6X2.4 to any pole or pipe with diameter of 3-10 inches. Wooden poles of larger diameter require different types of clamps.
  • Page 19 Figure 3.6 Attaching the Back Plate to the Pole Bracket 6. Attach the tray to the back plate as shown in Figure 3.7. Note The tray must be parallel to the ground. The tray can be rotated to obtain the correct position. 7.

  • Page 20: Wood Brace Mounting

    Figure 3.8 Attaching the NPP 6X2.4 to the Tray To continue installing the NPP 6X2.4, see Grounding the Netronics NPP 6X2.4 on page Wood Brace Mounting You can mount the tray directly onto a wood brace without using pole hose clamps.
  • Page 21 NPP 6X2.4 weight plus wind loading. Please see Chapter 9 for wind loading considerations. To mount the Netronics NPP 6X2.4 on a wood brace: 1. Select a mounting location. 2. Attach the tray directly to the wood brace using four 5/8 inch diameter, 3 inch long lag bolts as shown in 0.

  • Page 22: Streetlight Mounting

    Streetlight Mounting You can mount the Netronics NPP 6X2.4 on the horizontal or angled arm of a streetlight. To mount the Netronics NPP 6X2.4 on a streetlight: 1. Choose a mounting location. You can attach the NPP 6X2.4 to any streetlight arm with diameter of 3 to 10 inches.
  • Page 23 Figure 3.12 Attaching the Back Plate to the Pole Bracket 6. Attach the tray to the back plate as shown in Figure 3.13. Note The tray must be parallel to the ground. The tray can be rotated to obtain the correct position. 7.
  • Page 24 NPP 6X2.4 and tighten the bolts. Tighten the bolts using a 5mm Allen wrench. Insert bolts Figure 3.14 Attaching the NPP 6X2.4 to the Tray Grounding the Netronics NPP 6X2.4 To continue installing the NPP 6X2.4, see on page Netronics Networks...

  • Page 25: Grounding The Netronics Npp 6X2.4

    Make sure you have completed grounding before you connect power to the NPP 6X2.4. The method for grounding the Netronics NPP 6X2.4 is shown in the figure below. Figure 3.15 Grounding Method To ground the Netronics NPP 6X2.4:...
  • Page 26 4. Attach the second star washer and tighten the nut. 5. Attach the other end of the grounding wire to a grounding strap that is attached to a grounded surface or other earth ground (for example, a grounding rod). Netronics Networks...

  • Page 27: Grounding The Data Protection Device

    Grounding the Data Protection Device The grounding method for an indoor data protection device is shown in Figure 3.17 To ground an indoor data protection device: 1. Position the protection device as close to the entrance of the building entrance as possible.

  • Page 28: Connecting Power

    Connecting Power The following describes how to connect the NPP 6X2.4 to power. There are three options for connecting the Netronics NPP 6X2.4 to a power source: • AC power source (3-wire service) -- 3W(P+N+PE) or 3W(2P+PE); 110-220 VAC, 50/60 Hz.

  • Page 29: Connecting To Ac Power (Category C)

    • DC power source (2-wire service); 48VDC See Installation Accessories on page details. • Netronics injector connected to Ethernet port B (ETH B). See Installation Accessories page for details. ARNING Turn the power off before working on an electrical circuit. Turn off the breaker to the circuit you plan to work on.
  • Page 30 5. Connect the conduit to a junction box. The conduit and junction box must be IEEE/ANSI compliant and suitable for outdoor use. Note: Data and power must not be enclosed in the same conduit. 6. Connect the AC cable to the NPP 6X2.4 and tighten the nut. Netronics Networks...
  • Page 31 Connect the AC cable 7. Connect the Netronics NPP 6X2.4 to one of the following power sources: • AC power source (3-wire service) -- 3W(P+N+PE) or 3W(2P+PE); 110-220 VAC, 50/60 Hz. See Installation Accessories on page for details. • NEMA plug, for streetlight photoelectric control power tap (2-wire service) --2W(2P) or 2W(P+N);...

  • Page 32: Connecting To Streetlight Power (Category C)

    NEMA plug, for streetlight photoelectric control power tap (2-wire service) --2W(2P) or 2W(P+N); 100-240 VAC 50/60 Hz. See Installation Accessories on page details. 2. Make sure that the power is turned off on the designated circuits. 3. Remove the photosensor from the streetlight. Netronics Networks...

  • Page 33: Connecting To Dc Power

    4. Connect the NEMA 3 prong plug from the Netronics NPP 6X2.4 to the photosensor connector on the streetlight. 5. Connect the photosensor to the top of the NEMA 3 prong plug. 6. Connect the AC plug to the NPP 6X2.4 and tighten by hand.
  • Page 34 7. Connect the DC cable to the NPP 6X2.4 and tighten the nut. 8. Reenergize the circuit and check that the power to the NPP 6X2.4 turns on. Note: The Netronics NPP 6X2.4 is equipped with fuse branch circuit protection. External DC current protection of 10Amp should be installed. Netronics Networks...

  • Page 35: Connecting A Data Port

    This is not a mid-span powered device. Do not attempt to daisy-chain Power Over Ethernet devices. The figures below show the options for routing cables to the Netronics NPP 6X2.4. Connect the Ethernet cable to the appropriate data port (ETH A, ETH B, or ETH C).
  • Page 36 1. Make sure that the power is turned off for the designated circuits. 2. Run shielded Category 5 Ethernet cable appropriate for outdoor use from a data protection unit to the Netronics NPP 6X2.4. 3. Connect one end of the Category 5 cable to the data protection unit.
  • Page 37 5. Open the strip next to the connector access cover by unscrewing the bolt. Strip Connector access cover Figure 3.25 Opening the Strip and Connector Access Cover 6. Select the slot that matches the diameter of the Ethernet cable and remove the rubber plug.
  • Page 38 11. Close the strip and tighten the bolt using the 4mm Allen wrench. 12. Close the connector access cover and tighten the bolts using the 4mm Allen wrench. This ensures a watertight seal. 13. Apply silicon in the gap between the strip and the connector access cover. Netronics Networks...

  • Page 39: Connecting Peripherals

    14. Create a drip loop of at least 10 inches by looping the cables back to the tray and using a tie wrap to secure. ARNING: If you are using a Netronics Injector, make sure you are not supplying power to the injector until you insert the RJ45 connector into its socket, or you may risk electric shock.

  • Page 40: Using A Backhaul Unit

    There are two types of backhaul units: • A backhaul unit that provides its own power • A backhaul unit that uses power supplied by the NPP 6X2.4 Netronics Networks...

  • Page 41: Safety Information For The Netronics Npp 6X2.4

    When using a backhaul unit that uses power supplied by the NPP 6X2.4, connect the Ethernet cable to either ETH A or ETH B. Note: When using a Netronics injector, the NPP 6X2.4 cannot supply power to the backhaul unit. Note: Make sure to use the correct part number for the backhaul unit to avoid causing damage to the unit.

  • Page 42: Service Instructions

    • The use of wireless devices in hospitals is restricted to the limits set forth by each hospital. • Do not operate a portable transmitter near unshielded blasting caps or in an explosive environment. • The Netronics NPP 6X2.4 must be used only with Netronics approved components and antennas. Service Instructions The Netronics NPP 6X2.4 contains no user serviceable parts inside.
  • Page 43 Installation Guide...

  • Page 44: Power Consumption

    NPP 6X2.4 (Max) Input NPP 6X2.4 Input Power when PoE Power when PoE Power when a 48VDC Voltage output is not used output is not used PoE output is used 110 VAC 50/60 Hz 40W 220 VAC 50/60 Hz 44W Netronics Networks...

  • Page 45: Product Specification

    Chapter 5 Product Specification The tables in this chapter contain specifications for the Netronics NPP 6X2.4. Wireless Specifications IEEE 802.11b/g compliant Frequency band 2.4 - 2.483 GHz • 802.11b: DSSS (DBPSK, DQPSK, CCK) Modulation • 802.11g: OFDM (64QAM, 16QAM, QPSK, BPSK) TX Power Maximum 802.11b and 802.11g...
  • Page 46 • Input/Output Power over Ethernet • Weather-tight power connector plug for 100-240 VAC power input Power Input • Power from a Netronics Injector (ETH B port only) • Two Ethernet port LED Link/Act indicators (only for ETH A and ETH B ports) Indicator Lights •...
  • Page 47 • 100 - 240 VAC weather-proof power cable, 50/60 Hz with standard AC connector or street light NEMA photo-electric control Power Input power tap • 55VDC, supplied over Ethernet from Netronics injector. • Power from Netronics Injector 35W @ 55VDC Input Power Consumption •...
  • Page 48 Netronics Networks...

  • Page 49: Installation Accessories

    Chapter 6 Installation Accessories This chapter describes the accessories available for the NPP 6X2.4 and ordering information. The following topics are covered in this chapter: Power Cable on page • Ethernet Cables on page • Lightning Protection on page • Power Over Ethernet on page •...

  • Page 50: Power Cable

    Netronics - Use Netronics Indoor-Outdoor CAT 5e cable with pin crossing (pin 5 of the See Installation NPP 6X2.4 PoE connector goes to pin 7 of Netronics RJ45 connector, pin 7 of the NPP Guide 6X2.4 PoE connector goes to pin 5 of the Netronics RJ45 connector) Motorola (Canopy) - Use outdoor CAT 5e cable with spare pin crossing (pin 4 5 of the NPP 6X2.4 PoE connector goes to pin 7 8 Motorola RJ45 connector respectively)
  • Page 51 (pin 7 8 of the NPP 6X2.4 PoE connector goes to pin 4 5Motorola RJ45 connector respectively) Installation Guide...
  • Page 52 Netronics Networks...

  • Page 53: Ac Wiring Diagrams

    Chapter 7 AC Wiring Diagrams This chapter contains the following wiring diagrams for AC power: AC Wiring Photoelectric Power Tap on page • AC Wiring Power Cable 120VAC, 15A Plug on page • AC Wiring Photoelectric Power Tap WPC-AC-6M-UNV NPP 6X2.4 Installation Guide...
  • Page 54 NPP 6X2.4 NPP 6X2.4 NPP 6X2.4 Figure 8.1 AC Wiring Photoelectric Power Tap Netronics Networks...

  • Page 55: Ac Wiring Power Cable 120Vac, 15A Plug

    AC Wiring Power Cable 120VAC, 15A Plug WPC-AC-6M-UNV NPP 6X2.4 Figure 8.2 AC Wiring Power Cable 120VAC, 15A Plug Installation Guide...
  • Page 56 Netronics Networks...

  • Page 57: Wind Loading Considerations

    The Netronics NPP 6X2.4 weighs approximately 16 lbs, including all mounting hardware. When the Netronics NPP 6X2.4 is mounted on a pole, the sail area of the NPP 6X2.4 is approximately 1 square foot. The Netronics NPP 6X2.4 can load a pole with a maximum load of 3400 Newton in wind conditions of 165mph.
  • Page 58 Netronics Networks...

  • Page 59: Backhaul Unit Installation Instructions

    This chapter describes how to install a backhaul unit with the NPP 6X2.4. Use the assembly equipment provided with the backhaul unit to install. Netronics does not provide brackets or mounting equipment for the backhaul unit. Make sure the NPP 6X2.4 is installed in a higher position then the backhaul unit so the antennas are unobstructed.
  • Page 60 Netronics Networks...

  • Page 61: Acronyms

    Chapter 10 Acronyms Acronym Description Two-Phase or Split Phase Two-Wire Three-Wire Alternating Current ANSI American National Standards Institute American Wire Gauge Celsius Category Complementary Code Keying Code of Federal Regulations Canadian Standard Association Decibels Decibels Relative to an Isotropic Radiator DBPSK Differential-Binary Phase-Shift Keying Direct Current...
  • Page 62 Orthogonal Frequency Division Multiplexing Phase Protective Earth Power over Ethernet RJ45 Registered Jack 45 Received Signal Strength Receive Receive Data Technical Inspection Association Transmit Transmit Data Underwriters Laboratories Voltage (Alternating Current) VCCI Voluntary Control Council for Interference Voltage (Direct Current) Watts Netronics Networks...
  • Page 63 Installation Guide...

  • Page 64: Appendix A: Npp 6X2.4 Product List

    Spatially adaptive, multi radio WiFi base station, PoE input, no PoE output. 12405102 NPP 6X2.4-POE-EU ETSI / CE compliant Netronics 2.4GHz Spatially adaptive, multi radio WiFi base station, with 2.4GHz self backhaul. 100-240VAC input and 12405201 NPP 6X2.4-AC-48-FCC 48VDC PoE output for external device.
