NetPoint Pro n2S5S Quick Installation Guide
Components Included in the Package
Description
A
Wall/Pole
Bracket
B
Clamping Bracket
C
'L' Adapter Wall/Pole Mount
D
Hex Bolt M8x70
E
Hex Bolt M8x40
F
Hex Bolt M8x25
G
Flat Washer M8
H
Spring Washer M8
I
Nut M8
J
Safety
Cable
Qty
Description
1
K
Waterproof RJ45 connector
1
L
Power Injector
1
2
M
Ring Terminal
Ground Screw
1
Lock Washer
N
Gland Cap
1
4
4
1
1
Qty
2
1
1
1
2
2
Advertisement
Table of Contents
Related Manuals for Netronics NetPoint Pro n2S5S
Summary of Contents for Netronics NetPoint Pro n2S5S
- Page 1 NetPoint Pro n2S5S Quick Installation Guide Components Included in the Package Description Description Wall/Pole Waterproof RJ45 connector Bracket Clamping Bracket Power Injector ‘L’ Adapter Wall/Pole Mount Hex Bolt M8x70 Ring Terminal Ground Screw Hex Bolt M8x40 Lock Washer Gland Cap...
- Page 2 NetPoint Pro n2S5S Unit. 2. Install the Mounting Brackets When mounting the NetPoint Pro n2S5S, the pole or wall mounting on must support a minimum of 61.6 lbs (28 kg). In addition, the pole or wall mounting on must support the wind load from the NetPoint Pro n2S5S.
- Page 3 1. Wrap the safety cable around the pole and insert the mounting plate through the cable loop. 2. Attach the mounting plate to the NetPoint Pro n2S5S unit using the hexagonal bolts. Copyright © 2014 Netronics Technologies. All rights reserved.
- Page 4 NetPoint Pro n2S5S Quick Installation Guide 4. Ground the NetPoint Pro n2S5S Unit Connect the 10 AWG grounding cable before connecting any other cables. When removing the NetPoint Pro n2S5S, the grounding cable should be the last cable removed. 5. Connect the Ethernet PoE Outdoor Rated CAT5E shielded 24 AWG cable, the cable can be up to 60 meters.
