Alware Landing Gear Assembly Manual

Type a for phantom 1 / 2
Hide thumbs

Advertisement

Quick Links

Download this manual
Alware Landing Gear
Type A for Phantom 1 / 2
Assembly Manual
WWW.ALWARERC.COM

Advertisement

loading
Need help?

Need help?

Do you have a question about the Landing Gear and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alware Landing Gear

Summary of Contents for Alware Landing Gear

  • Page 1 Alware Landing Gear Type A for Phantom 1 / 2 Assembly Manual WWW.ALWARERC.COM...

  • Page 2: Check List

    Check list All the package should be packed and contain all the items in as shown below. Please contact the vendor you purchased from if anything is missing at once. WWW.ALWARERC.COM...
  • Page 3 STEP1 Slide the u-rings into the thin tubings. Put on connection plate. WWW.ALWARERC.COM...
  • Page 4 STEP2 Put on screws 2pcs M2x6mm Put on Join part WWW.ALWARERC.COM...
  • Page 5 STEP3 Put on screw M2.5x6mm Put on carbon fiber tubing WWW.ALWARERC.COM...
  • Page 6 STEP4 Put on Top Join Put on Set Screw Flat M2.5x 3mm & cap screw M2.5x12mm WWW.ALWARERC.COM...
  • Page 7 Step5 Put on Horizontal Alu Tubing Put on Tube Blocks WWW.ALWARERC.COM...
  • Page 8 Step6 Lock the Tube Blocks in place with Cap Screw M2x8mm Lock the Tube Blocks in place with Cap Screw M2x6mm WWW.ALWARERC.COM...
  • Page 9 Step7 Install the Landing gear on Phantom with 8pcs Cap Hex Screw M3x6mm WWW.ALWARERC.COM...
  • Page 10 Connection with Phantom 1 / 2 End of Manual WWW.ALWARERC.COM...
