Summary of Contents for RedBack Laser dld5x
-
Page 2: Operating Instructions
CONTENTS User Safety Introduction and DLD5X™ Accessories DLD5X™Diagram Operating Instructions Batteries Operation Magnetic Base Modes of Operation Calibration Self Check & Technical Specifications Care & Maintenance, Trouble Shooting Warranty User Safety • Laser output sign lies near the output aperture. - Page 3 Congratulations on purchasing the DLD5X™ multi line and dot laser level with plumb up/down, horizontal/vertical alignment and 90 degree square. The DLD5X™ is automatic levelling and features a secure pendulum lock to prevent accidental damage when not in use. The DLD5X™ features clear bright horizontal and vertical lines to produce...
- Page 4 DLD5X DIAGRAMS 1. Control Panel 2. Plumb Dot Up Laser Output 3. 3x Horizontal Dots at 90 4. Plumb Dot Down Laser Output 5. Screw to remove magnetic Base 6. Pendulum Lock & Power On/Off 7. Vertical Line Output 8. Horizontal Line Output...
- Page 5 DLD5X OPERATING INSTRUCTIONS Battery Instructions The DLD5X operates on 3 x standard “AA” batteries, first remove the magnetic base from laser to expose underside, locate battery compartment and pull latch to open battery compartment. Insert batteries as indicated and close battery compartment cover.
- Page 6 If the lasers flash together with a loud beeping sound then the DLD5X out of self levelling range and the laser housing needs to be set up more level on the ground or tripod until the beeping stops, the DLD5X is now in self levelling range.
- Page 7 , Vertical LIne, Both lines and lines off. Pressing the Dot Button will toggle between Horizontal dots, Plumb Up/Down dots, All dots and dots off. The DLD5X has a manual mode, in other words it can display the laser lines and dots without first levelling. This is achieved by NOT Unlocking the pendulum and pressing the Line or Dot buttons note the manual level LED will flash.
-
Page 8: Modes Of Operation
The DLD5X can be used with an optional electronic Line receiver such as the RedBack LLR705 or LR200. To use a receiver the DLD5X needs to be switched into Pulse Mode by pressing the pulse button, this makes lines visibly a little less bright but is required for the receiver to pick the lines up. -
Page 9: Technical Specifications
DLD5X TECHNICAL SPECIFICATIONS Technical Specifications Laser Wavelength 635nm <1mW Laser Class Range Lines 20m Radius Indoors (light depending) Range Dots 30m Radius Indoors (light depending) Accuracy ±2mm/10m Self Levelling Range ±3 Vertical Line Fan Angle Horizontal Line Fan Angle Temperature Range... - Page 10 • Trouble Shooting - FAQ I hear a continuous beeping when turned on! This is the out of level alarm indicating that the DLD5X outside of self levelling range, re level the laser housing and try again. The Laser does not power up! Check the pendulum lock has been unlocked, rotated into the “Unlock”...
- Page 11 Notes www.redbacklasers.com.au...
- Page 12 “Workmanship” refers to handling, assembly and manufacturing processes done by or for CMI Industries Pty Ltd in order to manufacture the products. “Warranty Period” For the DLD5X is Two Years. Warranty period is from original purchase date, no extension is made in the event of warranty replacement products supplied or time spent being repaired.
