Summary of Contents for ESICAM HN03
-
Page 2: Product Safety
Introduction Please read these instructions carefully in their entirety before using the product, and keep them handy for future reference. Thank you for your interest in our product and for ordering the IPCam. It can be controlled using any PC/laptop via the Intranet or Internet via a common web browser (recommended: Internet Explorer or Safari), via smartphone (iPhone, iPad, Android phone and pad) or via the client software installed on the PC. -
Page 3: Main Features
Main features Easy installation Motion sensor function The camera comes with an integrated wireless capability The camera can detect changes to the image being (IEEE802.11b/g/n) and web server function. Therefore, dri- viewed. As soon as a change occurs, it sends an e-mail to ver installation is not necessary. - Page 4 Interface: 10/100 Mbps Ethernet connection or Colour monitor: We recommend at least 800 x 600 wireless network connection (WLAN) and the latest driver for the display adapter Technical data #HN03 Technical data #HN11 Image sensor: 1/4" Progressive CMOS sensor Image sensor: 1/4“ Progressive CMOS sensor Display resolution: 1280x720 Pixels ...
-
Page 5: Connecting The Camera To The Network
Camera setup and confi guration 1. Connecting the camera to the network When using for the first time, please connect the camera and the computer to a router using network cables. Ensure that the router is switched on and that, when the RJ-45 cable is connected to the camera, the yellow and green light illuminates (network control lights). - Page 6 2.3 Add a camera with the software from the App store Click „+“ at the top right to add a new camera, and select „IP Camera“. There are four options for choosing a camera: Quick Setup: Pressing the WPS button on the camera and router links the camera automatically (does not work with every router) LAN search: Click „Search“...
- Page 7 2.5 WLAN setup Click the „House“ icon at the top left and the main menu appears. Clicking „Device Management“ gives you a list of all the cameras that have been installed on the network via LAN cable. Click the „>“ symbol on the right next to the camera to activate the settings.
- Page 8 2.7 Video options Horizontal cruise The application supports settings for the alarm, saving, password changes, firmware updates, image quality Vertical cruise (brightness, contrast, mirroring, infra-red options). Preset position The commands are self-explanatory thanks to the icons Full screen and are easy to understand. Sound off Sound on No communication...
- Page 9 3. Camera setup via PC software Proceed in the same way as with downloading for smart- phones and go to the www.eyecloud.so website. Click „Download“ under the Windows icon. Run the „app-Smart.exe“ file and allow the program to install. The following icon appears on your desktop following successful installation: After double-clicking the icon, the following window appears:...
- Page 10 Select WiFi: Clicking this button allows you to list the WiFi networks available with a click on „Search signal“. Select the appropriate network, click „Set“ and enter, if requested, the WPA or WPA2 key. This is often found on the underside of the router. After successfully setting up the WLAN network, the following message appears Confirm with „OK“.
- Page 11 3.2 Control elements Clicking with the left-hand mouse button on the window of the camera in question displays a control element with various control options: The control options framed in red only apply to HD Pan & Tilt IP Cam (#HN11). These functions relate to the movement of the camera via remote control.
- Page 12 Ocean Electric Co. Ltd. 200 Centreport Dr.Suite 365,Greensboro, NC 27409, USA Tel.: 001-626-560-3456 E-Mail: Salse1@oceanelec.cn...
