- Page 1 SRD10SBS / SRD12SBS SHAKER SERIES BASS PACKAGES...
-
Page 2: Table Of Contents
-Damage during freight from poor packaging or handling. -Return shipping on non-defective items. REMOTE CONNECTION Warranty Turnaround Time It is VM Audio’s goal to turnaround the merchandise in a SPEAKER WIRING timely fashion of 1 week. Unexpected delays may occur due to repair parts or replacement shortage. -
Page 3: Introduction
CONSUMER LIMITED WARRANTY AGREEMENT INTRODUCTION Your product is covered by a limited warranty by VM Audio as established below: Thank you for your interest in VM Audio products. Our goal is to enhance your listening experience. Mobile Electronics Limited Warranty... -
Page 4: Functions
HEIGHT (inches): ......9.94” DEPTH (inches): ......2.40” 1. INPUT: Audio Cable Jack Connections ENCLOSURE 2. OUTPUT: Audio Cable Jack Connections SRD10SBS SRD12SBS DESIGN: Ported Ported 3. GAIN: Input Signal Adjustment Knob SUBWOOFERS: 10” x 2 12” x 2 4. BASS BOOST: Bass Adjustment Knob TERMINALS: 5. - Page 5 TROUBLESHOOTING Continued... AMPLIFIER FUSE KEEPS BLOWING? 1) Incorrect Rear Panel wiring or short circuit: Using your DMM, make sure that all voltage polarities are correct, review section (Installation) for proper wire connection. 2) Amplifi er being driven too hard: Turn down the volume. Gain or Bass Boost not properly set, Review section (Tuning) for setting the Gain and Bass Boost properly.
-
Page 6: Getting Started
GETTING STARTED TROUBLESHOOTING Mounting If the bass package system does not appear to be working properly, check the following troubleshooting • Mount the amplifi er on a fl at, secure surface. suggestions. • Investigate the layout of your automobile thoroughly before drilling. NO SOUND? 1) Source unit volume is turned down •... - Page 7 CALIBRATION Continued... Wiring Setting Bass Boost • Before you begin routing and connecting the power wires, disconnect the negative ground cable from the vehicle’s battery. • Install and connect the highest possible wire gauge the amplifi er’s terminal will accept (1/0 GAUGE) for both power cables (+12V and GND).
-
Page 8: Installation
INSTALLATION CALIBRATION Make sure to mount the amplifi er in a location Setting Gain where there is enough room to have access to the knobs and terminals. 1. Turn the gain and bass control all the way down (counterclockwise). Mark the mounting Drill the holes on the 2. -
Page 9: Power Connections
5. Route another power cable from the in-line fuse to the amplifi er’s power terminal (or a power capacitor such as VM Audio SRCAP2.0). 6. Connect the power cable to the in-line fuse and the other end to the amplifi er’s positive +12V power terminal (or capacitor’s positive... - Page 10 POWER CONNECTIONS SPEAKER WIRING Continued... The remote wire, when connected to the amplifi er, is designed to turn on the amplifi er automatically when your stereo is turned on. REMOTE 4Ω SPEAKER IMPEDANCE 1. Locate the remote wire on the stereo head unit. 2.
- Page 11 REMOTE CONNECTION For a good electrical connection and maximum power transfer, use the same gauge size ground cable as The remote control knob will allow you to control the the power cable. The length of the cable should be bass output from your dashboard. as short as possible and as close to the amplifi er as possible.
-
Page 12: Audio Input
AUDIO INPUT LINE OUTPUT The audio inputs on the side panel of the amplifi er The pre-amp line outputs allow linking additional amplifi ers without the need to split the audio signals receive low level signals from the RCA outputs from the stereo, using Y-RCA cable adaptors.
