Summary of Contents for Storm RC X3UCAV
- Page 2 Description of switch location and function Transmitter battery Transmitter and receiver bingding Lower voltage warning & return to land function GPS signal Unlock process Stabilize mode Direction lock Althold Gps loiter (RTL) Why failsafe function...
- Page 4 LED indicator for APM controller system working status LED indicator for (Blue color) APM controller system working status (Blue color) Motor Alarm light for battery power status (Red color) Alarm light for Low power (Red color) Gimbal...
- Page 5 Channel-7 Channel-8 Stabilize mode.0 0.Stabilize mode Altitude hold.1 1.GPS loiter Direction lock. 2 2.GPS RTL Bind Mode 1 Mode 2 Channel-7 Channel-8 Stabilize mode.0 0.Stabilize mode Altitude hold.1 1.GPS loiter Direction lock. 2 2.GPS RTL Throttle & Rudder Stick Elevator & Aileron Stick Bind Mode 1 Mode 2...
-
Page 6: Transmitter Battery
7、Description of switch location and function： Sw1 location Sw2 location Function Stabilize mode Altitude hold Direction lock GPS loiter GPS RTL Rolling Tilting 8、Transmitter battery:... - Page 7 4\Press the BIND switch, turn on the power switch, keep waiting for 10 seconds, and then release the BIND switch. It indicates Binding success if the RED light on receiver is steady on .
-
Page 8: Gps Signal
10、Lower voltage warning & Auto landing function： Lower voltage warning & AUTO Landing function: X3 controller box can automatically inspect the battery voltage. The Battery po wer indicator is blinking red when battery voltage below 10.8V. X3 will automatically launch landing program when battery volta ge under 10.5V. - Page 10 SW1&SW2 set at "0" SW1&SW2 set at "0" Pull the rudder switch and hit the right corner of bottom until the LED flashing in Blue to release.(shows as above picture) Solid blue LED light indicate successful unlocking. Flashing blue LED light indicate locking. The propeller can not rotate when controller system is locking.
- Page 11 Sw1set at " 2" ,sw2 set at " 0" . Sw1set at " 1" ,sw2 set at " 0" .
- Page 12 Sw1set at "0" ,sw2 set at "1". Sw1set at "0" ,sw2 set at "2".
- Page 13 GPS signal...
- Page 14 2.Move the Throttle & Rudder switch to the bottom right corner, after 12 seconds, quadcopter get into flight stabilized control calibration mode when Blue LED change from solid blue to fast flashing. And then take off the quadcopter, keep hovering, the calibration is finished when Blue LED stop fast flashing.
- Page 15 2.Compass get into calibration condition when blue LED is fast flashing.
- Page 16 20123 brushless 920KV 20123 brushless 920KV R...
