Summary of Contents for VivoLink VL120013
- Page 1 User Manual VL120013 4K HDBT Splitter 1x4 with PoC...
- Page 2 4K HDBT Splitter 1x4 with PoC SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ...
- Page 3 The item PoC is short for Power over Cable. The receiver works with VL120013 can only be VL120001R. The item “far-end” means the device (e.g. display device, 3rd party RS232 device etc) connected with VL120001R.
-
Page 4: Table Of Contents
4K HDBT Splitter 1x4 with PoC Contents 1. Introduction ......................... 5 1.1 Introduction to VL120013................... 5 1.2 Features ......................5 1.3 Package List ...................... 5 2. Panel Description ......................6 2.1 Front Panel ......................6 2.2 Rear Panel ......................7 3. -
Page 5: Introduction
40m and 1080p signal up to 60m. If required, use the HDMI local output to cascade the HDMI signal up to 4 times with additional S VL120013. VL120013 is also capable of bi-directional IR control, RS232 control, EDID management and PoC. -
Page 6: Panel Description
4K HDBT Splitter 1x4 with PoC 2. Panel Description 2.1 Front Panel Name Description Power ① Illuminate red once powered on indicator ② FIRMWARE USB port, used for firmware update. Iluminate green when there is input signal, remain off when ③... -
Page 7: Rear Panel
IR IN socket OUT: Connect with IR emitter to emit the IR signal received from the receiver side. Assign ID for VL120013 to identify every unit, the value may ④ ID PRESET vary from 0~F. -
Page 8: System Connection
Control panel VL120001R IR Emitter VL120001R IR Emitter HDTV HDTV VL120001R HDTV IR Emitter IR Emitter HDTV HDTV 3.3 Connection Procedure Step1. Connect a HDMI source device (e.g. Blue-ray DVD) to the HDMI INPUT socket of VL120013 with HDMI cable. -
Page 9: Cascade Connection
VL120013 and VL120001R(s). If you want to cascade IR signal among several VL120013, connect the IR LOOP socket of one of them and the IR IN socket of the next until all VL120013 have been connected. Step6. Connect a DC 24V power adapter to the power port of VL120013, VL120001R is able to be energized by VL120013 with PoC solution. -
Page 10: Twisted Pair Cable Connection
Cascade through IR Loop Connect the IR LOOP socket of the first VL120013 and the IR IN socket of the next until all VL120013 have been connected. Sending IR signals to the IR Receiver connected to the first VL120013 will control all cascaded VL120013. -
Page 11: Control Modes
4.1 IR Control VL120013 provides with an IR IN port, the port support bi-directional transmission. Connect an IR receiver to the IR IN port, users can control VL120013/ far-end device from local or control local devices from remote via corresponding IR remote. -
Page 12: Control Local Device From Remote
4.1.2 Control local device from remote Control VL120013 or local displayer from remote via corresponding IR remote. Figure 4- 2 Control local device from remote 4.2 RS232 Control Connect the RS232 ports of VL120013 and VL120001R, VL120013 is capable to... -
Page 13: Installation/Uninstallation Of Rs232 Control Software
Uninstallation Delete all the control software files in corresponding file path. 4.2.2 Basic Settings Firstly, connect VL120013 with an input device and an output device. Then, connect it with a computer which is installed with RS232 control software. Double-click the software icon to run this software. -
Page 14: Rs232 Communication Commands
Command Sending Area. Note: To control VL120013 via RS232 port, the communication protocol parameters should be configured in the right manner: Baud rate: 9600; Data bit: 8; Stop bit: 1; Parity bit: none. - Page 15 4K HDBT Splitter 1x4 with PoC Command Function Feedback Example outputs port synchronously [X]: unit ID, varies from 00~15; [Y]: serial number of third party’s baud rate, varies from 1~7; [Q]: serial number of the HDBT output port, varies from 1~4; [Z]: command to be sent.
-
Page 16: Edid Management
19200 38400 57600 115200 4.3 EDID Management VL120013 provides with a 4-pin EDID DIP switcher, “1” stands for “On”, “0” stands for “Off”. Dial the switches to change EDID data refering to the following explainations: Switcher Status EDID information 0001... -
Page 17: Specification
176.4 kHz and 192 kHz DC24V 2.71A Power Supply 60m (196feet) with HDMI video, RS232 & IR control, PoC HDBT supports VivoLink VL120001R RS232 & IR Full function pass though; Control RS232 port ID selectable for cascading; Dimensions 220 x 148 x 44mm (half rack wide) -
Page 18: Panel Drawing
4K HDBT Splitter 1x4 with PoC 3840 x 2160@30Hz 3840 x 2160@60Hz 1080P 3D@60Hz Note: VL120013 supports 4k& 3D HDMI signals, please adopt quality HDMI cables compliant with HDMI1.4 for better transmission when connecting 4K or 3D sources. 6. Panel Drawing... -
Page 19: Troubleshooting & Maintenance
No HDMI signal output in VL120013 while local HDMI input is in normal working state Wrong RS232 Cannot control VL120013 Make sure the RS232 communication parameters by control device (e.g. -
Page 20: After-Sales Service
4K HDBT Splitter 1x4 with PoC 8. After-sales Service If there appear some problems when running VL120013, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty.
