  • Page 1 EWW1685HDW2 Washer Dryer User Manual...

  • Page 2: Table Of Contents

    17. TECHNICAL DATA..................31 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent...
  • Page 4 Connect the mains plug to the mains socket only at • the end of the installation. Make sure that there is access to the mains plug after the installation. The ventilation openings in the base (if applicable) • must not be obstructed by a carpet.

  • Page 5: Safety Instructions

    ENGLISH Fabric softeners, or similar products, should be used • as specified by the fabric softener instructions. Remove all objects from pockets such as lighters and • matches. Never stop the wash dryer before the end of the drying • cycle unless all items are quickly removed and spread out so that the heat is dissipated.

  • Page 6: Water Connection

    • Do not use multi-plug adapters and • Do not touch the glass of the door extension cables. while a programme operates. The • Do not pull the mains cable to glass can be hot. disconnect the appliance. Always pull •...

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 Appliance overview Worktop Detergent dispenser Control panel Door handle Rating plate Drain pump filter Feet for the appliance level 3.2 Fixing plate kit Read carefully the instructions supplied with the accessory. (4055171146) Available from your authorized dealer. If you install the appliance on a plinth, secure the appliance in the fixing plates.

  • Page 8: Programmes

    Display Drying level touchpad (Kurutma seviyesi) Drying time touchpad (Kurutma süresi) Start/Pause touchpad (Başlat/ Durdur) Delay start touchpad (Gecikmeli başlatma) Time Manager touchpads (Time Manager) Extra rinse touchpad (Ekstra durulama) 4.2 Display A) The Temperature area: : Temperature indicator : Cold water indicator : Time Manager indicator.
  • Page 9 ENGLISH Programme Maximum load Programme description Temperature range Maximum spin (Type of load and soil level) speed 8 kg White cotton and coloured cot‐ 1600 rpm ton. Normal soil and light soil. Pamuklular 90°C - Cold 8 kg White cotton and colour-fast 1600 rpm cotton.
  • Page 10 Programme Maximum load Programme description Temperature range Maximum spin (Type of load and soil level) speed 2 kg Drying programme for synthetic items. Sentetik Kurutma 4 kg Drying programme for cotton items. Pamuklu Kurutma Steam programmes Steam can be used for dried, washed or worn once laundry. These programmes can reduce creases and odours and make your laundry more soft.

  • Page 11: Automatic Drying

    ENGLISH Programme ■ ■ ■ ■ ■ Sentetikler ■ ■ ■ ■ ■ Hassas giysiler ■ ■ ■ İpekliler ■ ■ ■ ■ Yünlüler/Elde yikama ■ ■ Yorgan ■ ■ ■ Sıkma/Boşaltma ■ ■ ■ ■ ■ Durulama 1) Set the spin speed. Make sure it agrees with the laundry. If you set No Spin option the only drain phase is available.

  • Page 12: Timed Drying

    5.3 Timed drying Dryness Level Type of fabric Load Spin Suggested (kg) speed duration (rpm) (mins) Extra Dry Cottons and Linen 1600 165 - 180 For towelling materi‐ (bathrobes, bath towels, 1600 90 - 100 etc) 1600 60 - 70...

  • Page 13: Consumption Values

    ENGLISH 6. CONSUMPTION VALUES The data of this table are approximate. Different causes can change the data: the quantity and type of laundry, the water and ambient tempera‐ ture. At programme start the display shows the duration programme for the maximum load capacity.
  • Page 14 Rinse Hold • Extra dry level for cotton items • Set this option to prevent the laundry • Cupboard dry level for cotton, creases. synthetic, silk and wool items • The washing programme stops with • Iron dry level for cotton items the water in the drum.

  • Page 15: Settings

    ENGLISH 8. SETTINGS • To activate/deactivate this option 8.1 Child Lock press at the same time With this option you can prevent that the until the indicator comes on/goes children play with the control panel. off. • To activate/deactivate this option, 8.3 Acoustic signals press at the same time...
  • Page 16 10.2 Using detergent and additives 1. Measure out the detergent and the fabric conditioner. 2. Put the detergent and the fabric conditioner into the compartments. 3. Carefully close the detergent drawer 10.3 Detergent compartments CAUTION! Use only specified detergents for washing machine.
  • Page 17 ENGLISH • Position A for powder detergent (factory setting). • Position B for liquid detergent. When you use the liquid detergent: • Do not use gelatinous or thick liquid detergents. • Do not put more liquid then the maximum level. •...
  • Page 18 10.8 Starting a programme with Before starting the new the delay start programme the appliance could drain the water. In this 1. Press again and again until the case, make sure that the display shows the delay you want to detergent is still in the set.

  • Page 19: Daily Use - Drying Only

    ENGLISH 10.13 AUTO Stand-by option The washing programme is completed, but there is water in the The AUTO Stand-by function drum: automatically deactivates the appliance • The drum turns regularly to prevent to decrease the energy consumption the creases in the laundry. when: •...

  • Page 20: Daily Use - Washing & Drying

    • The display shows regularly a • : CUPBOARD DRY level new time value. indicator for cotton, synthetic, silk and wool items • The drying indicator starts to flash. • : EXTRA DRY level indicator • The display shows the door...

  • Page 21: End Of The Programme

    ENGLISH 12.3 Washing & Timed Drying To have a good drying performance do not exceed To have a good drying the appliance the maximum drying loads does not let you set a too low spin speed recommended in the user for the items to be washed and dried.

  • Page 22: Hints And Tips

    • To do not wash dark fabrics after you 1. Empty the drum. washed and dried light coloured 2. Clean the drum, the gasket and the fabrics (new sponge, wool, door with a wet cloth. sweatshirt ) and the contrary.

  • Page 23: Ecological Hints

    ENGLISH • Use the correct products for the type • Synthetic curtains. and colour of the fabric, the • Pieces of clothing with metal inserts. programme temperature and the level • Nylon stockings. of soil. • Quilts. • If your appliance has not the •...

  • Page 24: Care And Cleaning

    2. Use special fabric conditioner for done before. tumble dryers. To avoid the static charge at the end of When the drying programme is the drying cycle: completed remove the laundry in a short time.
  • Page 25 ENGLISH 14.6 Cleaning the drain filter Do not clean the drain filter if the water in the appliance is hot.
  • Page 26 www.electrolux.com...

  • Page 27: Frost Precautions

    ENGLISH 14.7 Cleaning the inlet hose and the valve filter 45° 20° 14.8 Emergency drain 0° C, remove the remaining water from the inlet hose and the drain pump. Because of a malfunction, the appliance 1. Disconnect the mains plug from the cannot drain the water.

  • Page 28: Troubleshooting

    15. TROUBLESHOOTING • - The appliance does not drain WARNING! the water. Refer to Safety chapters. • - The appliance door is open or 15.1 Introduction not closed correctly. Please check the door! The start of the appliance does not occur or it stops during operation.
  • Page 29 ENGLISH Problem Possible solution The appliance does not Make sure that the sink spigot is not clogged. drain the water. Make sure that the drain hose has no kinks or bends. Make sure that the drain filter is not clogged. Clean the fil‐ ter, if necessary.

  • Page 30: Emergency Door Opening

    Problem Possible solution The cycle is shorter The appliance calculates a new time according to the laun‐ than the time displayed. dry load. See the ‘Consumption Values’ chapter. The cycle is longer than An unbalanced laundry load increases the duration time.

  • Page 31: Technical Data

    ENGLISH 3. Open the filter flap. CAUTION! 4. Keep the emergency unlock trigger Make sure that the drum is pulled downward and, at the same not rotating. Wait till the time, open the appliance door. drum stops rotating, if necessary. Make sure that the water level inside the drum is not too high.
