Installation Instructions
FI Dishwasher
CONTENTS
INTRODUCTION ......................................................................................................................... 2
WHAT YOU NEED ...................................................................................................................... 2
SAFETY INSTRUCTIONS ............................................................................................................ 3
BEFORE STARTING THE INSTALLATION .................................................................................. 3
XXL DISHWASHERS ................................................................................................................... 4
- UNIT DIMENSIONS ............................................................................................................... 4
- PREPARING THE LOCATION ................................................................................................ 4
ADA AND XL DISHWASHERS .................................................................................................... 5
- UNIT DIMENSIONS ............................................................................................................... 5
- PREPARING THE LOCATION ................................................................................................ 5
- ADAFI TRIM KIT INSTALLATION OPTIONS .......................................................................... 6
STEP 1. FITTING THE DISHWASHER IN PLACE........................................................................ 7
STEP 2. ATTACHING THE ACCESSORY DOOR OR CUSTOM PANEL .................................... 10
STEP 3. ADJUSTING THE DOOR SPRINGS ............................................................................ 11
STEP 4. CONNECTING ELECTRICITY, WATER, AND DRAIN .................................................. 12
STEP 5. CHECKING DISHWASHER FUNCTION AND FIT ....................................................... 15
STEP 6. SECURING THE DISHWASHER.................................................................................. 15
STEP 7. ATTACHING THE TOE KICK (IF APPLICABLE) .......................................................... 17
INSTALLATION CHECKLIST ..................................................................................................... 20
IMPORTANT!
READ ALL OF THESE INSTRUCTIONS BEFORE INSTALLING THE DISHWASHER.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Asko ADA Series
Summary of Contents for Asko ADA Series
-
Page 1: Table Of Contents
Installation Instructions FI Dishwasher CONTENTS INTRODUCTION ......................... 2 WHAT YOU NEED ........................2 SAFETY INSTRUCTIONS ......................3 BEFORE STARTING THE INSTALLATION .................. 3 XXL DISHWASHERS ........................4 – UNIT DIMENSIONS ....................... 4 – PREPARING THE LOCATION ....................4 ADA AND XL DISHWASHERS ....................5 –... -
Page 2: Introduction
NOTE: you install the machine. The installation should be Cosmetic damage must be reported to the ASKO dealer carried out by a qualified person who is familiar with all within five days from the date of purchase. As soon as... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS • It is important that you closely follow the instructions • The power outlet for the dishwasher should be provided here. installed in a location that is easily accessible once the dishwasher is installed. • An incorrect or defective installation can lead to higher consumption of energy, water and dishwashing • Always follow the applicable regulations for water, detergent, which can lead to higher costs and poor... -
Page 4: Xxl Dishwashers
XXL DISHWASHERS UNIT DIMENSIONS Technical Data U.S. Metric Electricity 120V, 60Hz, 15 amp Height (Adjustable) 33-7/8˝ to 35-7/8˝ 861 mm to 912 mm Water pressure 4.2 - 140 psi, Width 23-5/8˝ 596 mm 0.03-1.0 MPa, Depth (Includes high loop) 22-7/8˝ 581 mm 0.3-10 Bar Depth W/Door Open... -
Page 5: Ada And Xl Dishwashers
ADA AND XL DISHWASHERS UNIT DIMENSIONS Technical Data U.S. Metric Electricity 120V, 60Hz, 15 amp Height (Adjustable)* 32-3/8˝ to 34-1/4˝ 821 mm to 872 mm Water pressure 4.2 - 140 psi, Width 23-5/8˝ 596 mm 0.03-1.0 MPa, Depth (Includes high loop) 22-7/8˝... -
Page 6: Adafi Trim Kit Installation Options
ADAFI TRIM KIT INSTALLATION OPTIONS ASKO XLADAFI dishwashers can be installed either with or without accessory fill strips depending on the type of installation. If the dishwasher cutout has been cut to European widths of 23-5/8˝ (600 mm), the unit won’t require fill strips. -
Page 7: Step 1. Fitting The Dishwasher In Place
STEP 1. FITTING THE DISHWASHER IN PLACE Be sure to remove the transport protection for the door when unpacking the dishwasher. Attach the light shielding film (packed in the document bag) to the underside of the countertop above the touch buttons. (Only certain models). The light shielding film ensures optimal button functionality. - Page 8 STEP 1. FITTING THE DISHWASHER IN PLACE Adjust the front feet by turning them clockwise to raise or counterclockwise to lower the dishwasher. Leave enough space to adjust them later. 1˝ (24 mm) Screw in the back foot completely by turning the adjustment screw at the front counterclockwise.
- Page 9 STEP 1. FITTING THE DISHWASHER IN PLACE 11. Adjust the back foot by turning the adjustment screw at the front clockwise. (Only models with front adjustable rear foot.) If the machine does not have a front adjustable rear foot, level the remaining rear legs just as you did the front legs.
-
Page 10: Step 2. Attaching The Accessory Door Or Custom Panel
STEP 2. ATTACHING THE ACCESSORY DOOR OR CUSTOM PANEL Follow the separate instructions supplied with the dishwasher to attach the chosen accessory door or custom panel to the front of the machine. NOTE: Once you have fitted the accessory door or custom panel to the dishwasher, the door springs may need adjusting. -
Page 11: Step 3. Adjusting The Door Springs
STEP 3. ADJUSTING THE DOOR SPRINGS Adjustable spring XL = 3-11 kg XXL = 1-9 kg Check that the door is balanced. It should not fall open or snap shut. Adjust as necessary. If you need to adjust the door spring tension, use a screwdriver to turn the hexagonal headed screw located at the front of the machine. -
Page 12: Step 4. Connecting Electricity, Water, And Drain
CONNECT DRAIN HOSE THREE WAYS TO INSTALL DRAIN CONNECTIONS ASKO provides a 7/8˝ (22 mm) diameter corrugated drain hose which is connected to the back of the unit to form a high loop. A) Typical connection to sink plumbing before trap... - Page 13 STEP 4. CONNECTING ELECTRICITY, WATER, AND DRAIN 2. CONNECT WATER SUPPLY HOSE WARNING! Plumbing connections must comply with applicable sanitary, safety and plumbing codes in your area. Shutoff valve The machine can be connected to either a hot (max. 160 °F, 70 °C) or cold water supply. We recommend a cold water supply.
- Page 14 STEP 4. CONNECTING ELECTRICITY, WATER, AND DRAIN Plug 3. CONNECT THE PLUG Ensure that the power outlet is within the range of the power cable. Do not use an extension cord! The dishwasher must be connected to a grounded outlet. Grounded outlet GROUNDING INSTRUCTIONS...
-
Page 15: Step 5. Checking Dishwasher Function And Fit
STEP 5. CHECKING DISHWASHER FUNCTION AND FIT Test the dishwasher with the Rinse & Hold program. Check that the dishwasher fills and drains properly. Also check that none of the connections leak. Also check that adjacent drawers and cabinet doors can be opened when the dishwasher door is open. - Page 16 STEP 6. SECURING THE DISHWASHER Check that the dishwasher’s steel feet are solidly placed on the floor. Make sure the dishwasher is not hanging in the air by the mounting tabs. If it is, turn the front feet to lower them until the machine is resting on the feet.
-
Page 17: Step 7. Attaching The Toe Kick (If Applicable)
STEP 7. ATTACHING THE TOE KICK (IF APPLICABLE) Insulation material 1" 25 mm) CUSTOMER CARE CENTER 1-800-898-1879 • WWW.ASKONA.COM... - Page 18 NOTES CUSTOMER CARE CENTER 1-800-898-1879 • WWW.ASKONA.COM...
- Page 19 NOTES CUSTOMER CARE CENTER 1-800-898-1879 • WWW.ASKONA.COM...
-
Page 20: Installation Checklist
INSTALLATION CHECKLIST ASKO - DISHWASHER Appliance Installation Checklist • Remove packaging and check for cosmetic damages. • Remove the information packets from inside the dishwasher. • Attach any accessories as required by the installation. Fill strips, light shielding film, supplied door sealing, accessory door, custom panel...
