Broadband 3G Wireless Router
User Manual

Advertisement

Table of Contents
loading

Summary of Contents for MOBIDATA MBD-R100H

  • Page 1 Broadband 3G Wireless Router User Manual...

  • Page 2: Table Of Contents

    Model: -MBD-R100H Contents Broadband 3G Wireless router ..............3 Introduction ..................3 Main Functions ................4 Default settings ................4 Package and requirements ............5 Framework of 3G router ................6 Description..................6 Leds indication ................6 Dimension and fixing way............7 Connection way................7 Introduction of web server ................7 Access web server.................7...

  • Page 3: Broadband 3G Wireless Router

    1. Broadband 3G Wireless router 1.1 Introduction HSUPA-EASY is a SOHO WIFI 150Mbps wireless router with HSUPA modem built-in, through which you can create a WIFI hotspot or Ethernet conveniently when ADSL or fiber line is unavailable. Integrating 3G, WIFI and router functions, HSUPA-EASY will convert 3G network to WIFI wireless network and LAN Ethernet, through which the terminals could access internet safe and conveniently.

  • Page 4: Main Functions

    Model: -MBD-R100H 1.2 Main Functions High speed Wireless WAN connection up to 7.2Mbps downlink and 5.76Mbps uplink rate Multi network operation compatible HSUPA,HSDPA,UMTS, EDGE,GPRS,GSM Integrated (U)SIM /(R)UIM Card slot, 6PIN Broadband Wireless WIFI up to 150Mbps Downward compatibility 802.11 b/g/n...

  • Page 5: Package And Requirements

    Model: -MBD-R100H PPPOE Support SSID Easy-net, support hidden operation WPS and WiFi Encryption Support DHCP status Enable Default DHCP Pool Range 192.168.0.100-192.168.0.200 User name/Password admin/admin IP Address 192.168.0.1 Virtual Server, DNS,DDNS Support Remote Web management Support Port forwarding Support Reconnection Support 3G log &...

  • Page 6: Framework Of 3G Router

    Model: -MBD-R100H 2. Framework of 3G router 2.1 Description 3G antenna WIFI antenna SIM tray button Power (U)SIM card slot LAN port x4 Reset 2.2 Leds indication Powered Unavailable Power No Power Connected Connected Twinkle Connecting network (built-in twinkle Transmitting data...

  • Page 7: Dimension And Fixing Way

    Model: -MBD-R100H 2.3 Dimension and fixing way Φ4mm 103mm Press SIM tray button and put SIM card in SIM tray. 155mm 2.4 Connection way Through Ethernet LAN port or WIFI wireless you can connect the terminals to router. 3. Introduction of web server 3.1 Access web server...

  • Page 8: Application Of Web Server

    Model: -MBD-R100H Remarks: Username and password could be changed in system setting of web server. 3.2 Application of web server 3.2.1 Check the router status In this page you can find the connection status, factory settings and the version of router.

  • Page 9: And Lan

    Model: -MBD-R100H 3.2.2 3G and LAN (1) 3G Connection Most of the network profiles have been built in this manager, so usually the manager will connect internet automatically. If fail to connect internet, please check the network profile firstly. If the APN is incorrect or unavailable, please modify or create a new profile.
  • Page 10 Model: -MBD-R100H Remarks: If you don’t know the network profile, please contact the local ISP. If the local ISP require MAC address bound, please enable “MAC clone”. if 3G led indicates successful connection but no volume stream, please check the balance of SIM card Before reset, the router will save all the setting you made.
  • Page 11 Model: -MBD-R100H automatically, if you want to get the IP address manually, please close DHCP. What’s more this router could also support LLTD, IGMP proxy,UPNP and advertisement. If you want to check all terminals connected to this router, please go to...

  • Page 12: Wifi And Wds

    Model: -MBD-R100H (3) Advanced routing This router could support both static routing and dynamic routing. Usually the router will use static routing. If you want to use dynamic routing, please enable this RIP setting. 3.2.3 WiFi and WDS (1) Basic and advanced settings of WIFI...
  • Page 13 Model: -MBD-R100H set the radio status at RADIO OFF. This router could support mixed wifi mode and single wifi mode. For example, if you just want 802.11 g mode, please select the only 802.11g mode. Please do not change the frequency channel unless it is required in special wireless environment.
  • Page 14 Model: -MBD-R100H SSID is used for identify the known users, which could be set in different name, visible or hidden type. However the maximum SSIDs you can set is 7, and the seventh will be retained for other usage Isolation function is used for improving the security. If this function enabled, the users cannot visit each other.
  • Page 15 Model: -MBD-R100H This router manager could support many different security way. Some of them can be set as group passwords, but you can not use the group passwords at the same time. Herein it is suggested that you might modify the passwords or security way in aperiodicity.
  • Page 16 Model: -MBD-R100H a. PIN Mode This mode used in creating connection by input generated PIN code of the router First step: choose PIN mode, set down PIN code of the router, also can click <Generate> and generate new PIN code. As shown follow: Second step: Open the network card software, choose PIN code to connect, and waiting for connecting after enter into the PIN code.
  • Page 17 Model: -MBD-R100H For example: Note: maintain the parameter such as Wi-Fi channel, SSID, password be the same, when you set up the main router and sub-router. a. Main router IP address: 192.168.0.1, enable DHCP, (shown as follows) select “repeat mode” on WDS mode, and fill sub-router MAC. (Shown as follows) b.

  • Page 18: System Security

    Model: -MBD-R100H set up the main router MAC only i. Bridge Mode: this mode can be adopted by sub-router only, and enter into main router MAC l. Repeater Mode: main router connects Internet, and enters sub-router MAC; sub-router enters into the main router MAC.
  • Page 19 Model: -MBD-R100H Remarks: Only choose one of the ways from IP address bar and MAC address bar, can not fill it at the same time. Source IP address: the computer IP address is controlled in LAN network, if none it means all computer of LAN.
  • Page 20 Model: -MBD-R100H The conditions of above demonstration: firewall choose “Enable”, filtering rule choose “Dropped”, and the way of setting on MAC address and IP address must be the same, the form is: “00:00:00:00:00:00” (2) Port Forwarding Enable the port service from one computer within the LAN, such as mail, FTP and so on;...
  • Page 21 Model: -MBD-R100H (3) DMZ After Set up DMZ in one computer on LAN, input router WAN IP address, the WAN can access this computer directly, and not affect other computers of LAN. If use this function, choose “Enable”, input the IP address from one computer, it come into effect when click “Apply”, shown as follows:...

  • Page 22: System Management

    Model: -MBD-R100H 3） Keyword Filtering. (5) Remote management 3.2.5 System Management (1) Language and time settings This web server can support English, simple Chinese and traditional...
  • Page 23 Model: -MBD-R100H Chinese. The default language is English. (2) User name and password of web server In order to prevent an unauthorized access to this router, it is suggested please change a new user name and password before you create a sharing network.
  • Page 24 Model: -MBD-R100H (3) DDNS This router can support DDNS (Dynamic Domain Name Server) function, through which it is convenient to access the router from public network by fixed domain bound with the router IP address. Remarks: Because the IP from the router is not fixed, so it is not convenient for public computers to visit the router by dynamic IP address.
  • Page 25 Model: -MBD-R100H Remarks: Please make sure the update is correct version and official release. Update will lose all the parameters you set before, so if no need update, which is not suggested. During updating, please make sure the router works on uninterrupted power supply, otherwise sudden power-off will collapse the router.

  • Page 26: Web Server Compatibility

    Model: -MBD-R100H 3.3 Web server compatibility The windows might be a little different when you access web server from different browser. So far the web server can be compatible with Microsoft Internet Explorer 6.0, and higher version, Firefox 1.0 and higher version,...

  • Page 27: Appendix Q&A

    Model: -MBD-R100H 4. Appendix Q&A No SIM card Please plug out SIM tray and insert SIM card in correct way. Please check whether the SIM card has been damaged or out of service. Please reset the router. SIM card recognized, no internet connection Please check the network profile of 3G.
  • Page 28 Model: -MBD-R100H and the router’s IP address must in same IP segment. No WPS function You need to install the quick setting software on your terminal. Plugging out SIM card when router is working. It’s not allowed to take our SIM card when router is working, which might damage the router.
  • Page 29 Model: -MBD-R100H 10. Router working logs Not available 11. WAN ping function Before sending ping command to router from public network computer, you need enable WAN ping in web server. 12. Remote web management Before managing web servers remotely please enable remote management and WAN ping firstly, then enable DDNS server.
  • Page 30 Model: -MBD-R100H Not available 19. Telnet Support 20. Fail to enter into Web server Please check the connection to router. Please reset router manually. 21. “UNKNOW” network operator Please clear the buffer of IE, then reset the router manually.
