Dear customer!
Thank you for choosing this quality product from ASKO. We hope it will
meet your expectations and fulfi l your needs for many years to come.
Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.

Operating instructions

MICROWAVE OVEN

BO4SM3L1-77 OM8456S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BO4SM3L1-77 OM8456S and is the answer not in the manual?

Questions and answers

Related Manuals for Asko BO4SM3L1-77 OM8456S

Summary of Contents for Asko BO4SM3L1-77 OM8456S

  • Page 1: Operating Instructions

    Dear customer! Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfi l your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.
  • Page 2 Instructions for installation and connection are supplied on a separate sheet. Instructions for use are also available at our website: www.asko.com / < http://www.asko.com /> Important information Tip, note...

  • Page 3: Table Of Contents

    CONTENTS MICROWAVE OVEN TECHNICAL SPECIFICATIONS CONTROL UNIT IMPORTANT SAFETY INSTRUCTIONS BEFORE CONNECTING THE OVEN: BEFORE USING THE APPLIANCE FOR THE FIRST TIME SWITCHING ON THE APPLIANCE FOR THE FIRST TIME STEPS OF THE COOKING PROCESS (1–7) STEP 1: CHOOSING THE BASIC COOKING MENUS AND SETTINGS STEP 2: TIMER FUNCTIONS –...

  • Page 4: Microwave Oven

    MICROWAVE OVEN (DESCRIPTION OF THE OVEN AND EQUIPMENT – DEPENDING ON THE MODEL) The fi gure represents one of the built-in appliance models. Since the appliances for which these instructions were drawn up may have diff erent equipment, some functions or equipment may be described in the manual that may not be present in your appliances.
  • Page 5 WIRE GUIDES The wire guides allow preparation of the food on four levels (please note that the levels/guides are counted from the bottom up). OVEN DOOR SWITCH The switches deactivate the microwave heating when the oven door is opened during the cooking process. When the door is closed, the switches turn the microwaves back on.

  • Page 6: Control Unit

    CONTROL UNIT MICROWAVES MY RECIPES EXTRA GENERAL AUTOMATIC QUICKIES FUNCTIONS SETTINGS ON/OFF KEY OVEN Selection and MINUTE START/STOP LIGHTING CONFIRMA- MINDER/ ON/OFF KEY TION KNOB ALARM Long touch: START Select the setting by rotating the knob. Long touch during operation: STOP Confi...

  • Page 7: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAREFULLY READ THE INSTRUCTIONS AND SAVE THEM FOR FUTURE REFERENCE. This appliance may only be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if supervision or instructions are provided to them concerning use of the appliance in a safe way and if they understand the hazards involved.

  • Page 8: Before Connecting The Oven

    Safe use of the microwave oven WARNING: If your oven allows combined operation (microwaves combined with other cooking modes), do not allow the children to use the oven without supervision of an adult person since the oven will reach very high temperatures in such operation modes. WARNING: If the door or door sealing is damaged, do not use the oven until it is repaired by an adequately trained service technician.

  • Page 9: Before Using The Appliance For The First Time

    BEFORE USING THE APPLIANCE FOR THE FIRST TIME Remove all equipment, accessories, and utensils from the oven and clean them with warm water and regular detergent. Do not use any abrasive cleaners. Before using the oven for the fi rst time, heat it with the upper and lower heater system at 200 °C for approximately one hour.

  • Page 10: Switching On The Appliance For The First Time

    SWITCHING ON THE APPLIANCE FOR THE FIRST TIME SETTING THE CLOCK After connecting your appliance or after an extended power outage, 12:00 will fl ash on the display. Set the time of day. Confi rm each setting by pressing the KNOB. Press the KNOB to set the time.

  • Page 11: Steps Of The Cooking Process (1-7)

    STEPS OF THE COOKING PROCESS (1–7) STEP 1: CHOOSING THE BASIC COOKING MENUS AND SETTINGS The process of preparing food in your oven can be controlled in several ways: Rotate the KNOB and select the symbol. The symbol will turn white. The NAME of the selected menu will appear at the top.
  • Page 12 A) COOKING BY SELECTING THE TYPE OF FOOD (Auto mode) Confi rm each setting by pressing the KNOB. Rotate the KNOB and select the Auto mode. Confi rm the setting by pressing on the KNOB. Select the type of food and the dish. Confi rm the selection.
  • Page 13 B) COOKING WITH MICROWAVES Confi rm each setting by pressing the KNOB. Rotate the KNOB and select Microwaves. Confi rm the setting by pressing on the KNOB. Select the settings by rotating the KNOB and pressing it to confi rm. 1 Microwave system 2 Cooking power 3 Cooking duration...

  • Page 14: Step 2: Timer Functions - Duration

    STEP 2: TIMER FUNCTIONS – DURATION The »Duration« setting can be selected in the basic Microwave mode. Setting the cooking time In this mode, you can defi ne the duration of oven operation (cooking time). Set the desired cooking time and confi...

  • Page 15: Step 3: Step Cooking

    STEP 3: STEP COOKING This mode allows you to combine three diff erent cooking modes successively in a single cooking process. Choose diff erent settings to cook your food just the way you want it. The »Step Cook« setting can be selected in the basic Microwave mode.

  • Page 16: Step 4: Start The Cooking Process

    STEP 4: START THE COOKING PROCESS The START/STOP key will fl ash before the start of the cooking process. Start the cooking process by briefl y touching the START/STOP key. Rotate the KNOB to change the current settings during cooking. STEP 5: END OF COOKING AND SWITCHING OFF THE OVEN Start the cooking process by pressing the START/STOP key and holding it for a while.

  • Page 17: Step 6: Selecting Additional Functions

    SAVING USER-DEFINED PROGRAMS (MY RECIPES) Choose the symbol and enter the name by rotating the KNOB and confi rming respective letters. If necessary, delete a character using the arrow; use the check mark or touch the START/ STOP key to confi rm the name. Select the type of food.
  • Page 18 CHILD LOCK Activate it by touching the LOCK key (key symbol). The following message will appear on the display: »Child lock activated.« Touch the key again to deactivate the child lock. If the child lock is activated with no timer function engaged (only clock is displayed), then the oven will not operate.If the child lock is activated after a timer function has been set, then the oven will operate normally;...

  • Page 19: Step 7: Choosing The General Settings

    STEP 7: CHOOSING THE GENERAL SETTINGS Choose Settings in the main menu to display the menu for various settings. Rotate the KNOB to navigate the menu.Confi rm each setting by pressing the KNOB. Language Select the language for the text on the display. Time Set the time of day after the appliance is connected to the power mains for the fi...

  • Page 20: Descriptions Of Systems (Cooking Modes) And Cooking Tables

    DESCRIPTIONS OF SYSTEMS (COOKING MODES) AND COOKING TABLES If your desired food cannot be found in the cooking table, fi nd information for similar food. The information displayed applies to cooking in a single level. Cooking times are rough estimates and may vary subject to some conditions.
  • Page 21 MICROWAVE SYSTEMS MICROWAVES Microwaves are used for cooking and defrosting. Power levels: 90, 180, 360, 600, 750, 100 W. Place the glass baking dish into the 1st guide. Defrosting Type of food Weight (g) Power (W) Defrosting time (min) Ground meat ** 1000 Cubed meat ** 1000...
  • Page 22 Reheating Type of food Amount Power (W) Reheating/ cooking (min) FOOD Escalopes/steaks 300 g Fish 200 g Mixed vegetables * 500 g Side dishes * 500 g Sauces * 500 g Soups/stews * 5 dl Pizza 500 g Chicken medallions 500 g Open sandwiches Popcorn...
  • Page 23 VEGETABLES Potatoes 500 g 1000 5-10 Eggplant / aubergines 500 g 1000 5-10 Courgettes 500 g 10-15 Carrots 500 g 1000 10-15 Onions 200 g 1000 String beans 500 g 10-15 Broccoli 1000 g 15-20 Bell peppers 500 g 1000 Caulifl...

  • Page 24: Maintenance & Cleaning

    MAINTENANCE & CLEANING CONVENTIONAL OVEN CLEANING You may use the standard cleaning procedure to clean Be sure to unplug the appliance from the power supply stubborn dirt in the oven (using cleaners or an oven and wait for the appliance to cool down. spray).

  • Page 25: Clean The Oven

    USING THE AQUA CLEAN FUNCTION TO CLEAN THE OVEN Pour 0.6 l water into the deep baking tray and place it in the lower guide. Choose ”Extra/Additional Functions” in the main menu and select the Aqua Clean symbol. Press the START key. After 4 minutes, food residues on the oven enamel walls will have softened and they will be easy to clean with a damp cloth.

  • Page 26: Removing And Cleaning The Wire Guides

    REMOVING AND CLEANING THE WIRE GUIDES Only use conventional cleaners to clean the guides. Undo the screw. Use a screwdriver. Remove the guides from the holes in the back wall. Take care not to lose the spacers fi tted on the wire guides.

  • Page 27: Replacing The Bulb

    REPLACING THE BULB The bulb is a consumable and therefore not covered by warranty. Before changing the bulb, remove the trays, the grid, and the guides. Use a Phillips (cross) screwdriver. (Halogen lamp: G9, 230 V, 25 W) Undo the four screws on the cover. Remove the cover and the glass.

  • Page 28: Troubleshooting Table

    TROUBLESHOOTING TABLE Problem/error Solution There is no response of the Disconnect the appliance from the power mains for a few minutes (undo the fuse sensors; the display is frozen. or switch off the main switch); then, reconnect the appliance and switch it on. The main fuse in your home trips Call a service technician.

  • Page 29: Disposal

    DISPOSAL Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials are labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste.

  • Page 30: Cooking Test

    COOKING TEST Food tested in compliance with the EN 60350-1 standard. Microwaves Dish Note Guide (from Power System Time (minutes) the bottom) 15-20 Custard creams 5-10 Sponge cake 1000 20-30 Meat loaf 90 W* (auto 20:30 Defrosting ground meat program) * Preheat for 10 minutes.
  • Page 32 SOLO MW_DM_45 en (05-16)
