- Page 1 CN-800 Mobile Navigation System USERS MANUAL http://www.camos-multimedia.com IMC GmbH Nikolaus-Otto-Str.16 22946 Trittau, Germany Tel. +49(0)4154 / 7093202-0 Fax +49(0)4154 / 7093202-20...
-
Page 2: Table Of Contents
Product specifications ..........35 Produced by CAMOS Europe GmbH Copyright © 2010 CAMOS Europe GmbH Design and specifications are subject to change without notice. All product and brand names are trademarks or registered trademarks of their respective holders. All rights reserved. Restricted copies, even just parts of them, duplication or dissemina- tion by means of electronic media is only permitted through written authorization of Camos Europe GmbH. -
Page 3: Safety Information
Do not put pins or needles into the product or electric cord of product. • In case of damage, please switch-off the product and contact your dealer or the CAMOS customer service. • This product is only made for 12-24V DC use. Please be careful while connecting. -
Page 4: Package Contents
Package contents Stand / suction base CN-800 Cigarette lighter cable TMC Module (optional) AV cable (optional) RV cable (optional) -
Page 5: Installation
Make sure that the placement of the CN-800 and cable does not inter- fere with the operation of vehicle safety devices, such as air bags. You assume the risks associated with damage to your vehicle or vehicle’s occupants as a... -
Page 6: Basic Operations
To turn ON the CN-800 push the power button on the top side. The first time you turn on your CN-800, it may take up to 5 seconds to start. To power OFF the device, push the power button 2 seconds. -
Page 7: Connectors And Control Buttons
Connectors and control buttons Front and top components Press short to switch LCD on/off. Power button Hold (2 sec.) for suspend with connected power, or power on/off in battery mode Back to main menu or open quick overlay Mode button menu Increase / decrease volume level Volume up/down... - Page 8 Connectors and control buttons Rear, right and left side components MIC input To connect external microphone RS-232 port To connect via RS-232 Audio output Line-Out Rear-Cam To connect rear-view camera AV-In To connect external video device DC Input 12~24V DC Input Connect USB cable for charging or active- Mini USB sync, connect optional TMC module...
- Page 9 Connectors and control buttons Mounting holes To connect stand or suction base This connector(under dust cover) allows use of an optional external GPS antenna External GPS with magnetic mount, which may be antenna port positioned on top of the car for better GPS signal reception in areas with poor reception Ext.
-
Page 10: Main Screen
Main Screen CN-800 has two different main screens. The default main screen like shown below. And another main screen where you can set an image or photo from the photo application as wallpaper. Change main screen mode Adjust display brightness... -
Page 11: Time, Speed And Direction
Time, speed and direction This screen provides information about time, your current speed an direction. The accuracy of the speed shown by the speedometer depends on the satellite signal strenght. Sometimes it may not be correct. It also may not show the same as the speedometer of your vehicle, because there are tolerances and other things that may affect the shown speed. -
Page 12: Split Screen And Quick Overlay
Split screen and quick overlay By pressing the mode button while you are in navigation mode you can open a quick overlay menu. It is possible to run naviga- tion and another applica- tion like phone, AV-In, video or music player at the same time. -
Page 13: Bluetooth Phone Control
If you are prompted to enter the pin code (or pass key) on your mobile phone, tap the pass key specified by the CN-800 (the default is ‘0000’) and tap OK. You will see the phone main screen after the pairing is completed. The sta- tus bar at the bottom shows the name of the mobile phone connected. -
Page 14: Placing A Call
Bluetooth phone control Placing a call After pairing with your mobile phone, you can place a call using any of the three buttons (call and call history) on the phone main screen. By tapping the call button on the phone main screen, you can enter the telephone number with the onscreen keypad. -
Page 15: Phone Book
Bluetooth phone control Phone book CN-800 is supporting Phone Book Access Profile (PBAP) and you can down- load the phone book data from your phone. You can tap to transfer phone book data from your phone after paired your phone and CN-800. -
Page 16: Receiving A Call
Tap pairing the device you want to use as a hands-free. When prompted to enter the passkey in your mobile phone, please, input the passkey requested by CN-800 and tap OK. NOTE: To use the service of a remote device with Bluetooth capability, make sure that the remote device is in discoverable mode. - Page 17 Bluetooth phone control Pair Mode By tapping the pair mode button on the phone main screen, you can manually set your device to pair mode. Within the duration of 4 minutes, you can initiate the pairing process on your mobile phone to discover your device as a hands-free device or a headset.
- Page 18 Bluetooth phone control Advanced Audio Distribution CN-800 supports advanced audio distribution function via Bluetooth. You can hear music from the memory of your phone using the navigation and you can control simple functions as shown in the following screenshot.
-
Page 19: Av/Rv/Ir Input
AV/RV/IR input AV/RV input Tap AV or RV button to choose the screen you want to show. You can use PIP (Picture in Picture) function with Navigation with button for multi tasking. IR input (External DVD Player - optional) You can control an external DVD player via the IR-input by using the DVD- control buttons. -
Page 20: Music Player
Playing music files If your files are in a storage card, insert the card into your device. If they are on an USB device, connect it to CN-800. Tap the Music button on the main screen to start the program. - Page 21 Music player Music playback controls Play / Pause Start or pause the playback RWD/F.FWD Play rewind or fast forward Previos / Next Play the previos or the next file Volume Control volume Close the program and return to Exit main screen Quick menu Multitasking with navigation List...
-
Page 22: Picture Viewer
To exit the program, tap button. Preparing the pictures for your device Copy the JPEG/GIF/BMP/PNG files to a storage card or an USB device like an USB-HDD or an USB memory stick and connect it to the CN-800. NOTE: Supported resolution of Photos •... - Page 23 Picture viewer Viewing a picture in full screen When you tap a picture once in the list view, the picture is displayed in full screen. To go back to the list view, tap on the screen to display the picture list screen.
-
Page 24: Movie Player
Playing Movie Files If your files are in a storage card, insert the card into your device. If they are on an USB device, connect it to CN-800. Tap the Movie player button on the main screen to start the program. - Page 25 Movie player main screen. Settings CN-800 is supporting full screen view and ‘smi’ subtitle file as extension and you are able to set various values such as caption size and color of these op- tions from the below setting screen.
-
Page 26: Utilities
Utilities In CN-800 you find four kinds of applications with useful functions. Calculator This is an useful application that is used to perform numerical calculations, especially addition, subtraction, multiplication, and division. - Page 27 This is application is working as memo note on which you can just draw and hand write on the screen. And you can save this as image file. Games CN-800 is providing three games for personal entertainment. E-book CN-800 is providing E-book function and you can read txt formatted files through this application.
-
Page 28: Settings
To select the application which will run when you switch on the device, tap Specific application. You can choose from standard applications by tapping their appropriate icon. If you want to start your CN-800 with the application which was loaded when you switched it off choose Latest application. -
Page 29: Fm Transmitter
Settings - FM Transmitter / RV FM Transmitter settings You can transmit all sounds from your CN-800 to your car radio by using FM transmitter. After you turn on the FM Transmitter (ON), find a frequency that is not used by a radio station on your car radio. -
Page 30: Language
Settings - Language / Touch screen Language settings NOTE: To change the language of the Map navigation software, use Map settings. Tap the Up/Down arrow button to scroll the list. Tap language button to select the language. Touch screen (Calibration) You can calibrate the touch screen if it is not responding accurately to your taps. -
Page 31: Date / Time
Settings - Date/Time / Power Date / Time settings To set Date/Time and Time Zone Set all required information and tap button to confirm. Power settings Set up the power saving feature: You can set a timer for Power off: - automatically turn off your device when it is idle for a set period of time. -
Page 32: Quick Menu
(‘M’ key) instead of screen quick menu in running map software. Mini USB settings If you choose , you are able to connect CN-800 to PC via ActiveSync. If you choose , CN-800 will be detected as an external memory de-... -
Page 33: Version Information & Upgrade
Settings - Version information & Upgrade / Default Version information & Upgrade You can check the software version of CN-800 in this screen and also you are able to upgrade the device with new versions. See http://www.camos-multimedia.com for more information. -
Page 34: Trouble Shooting
If you have any problem that could not be solved by those tips, please feel free to contact our support. IMC GmbH Camos Europe Nikolaus-Otto-Straße 16 22946 Trittau Phone: +49 (0) 4154 / 7093202-0 Fax: +49 (0) 4154 / 7093202-20 e-mail: info@camos-multimedia.com... -
Page 35: Product Specifications
Product specifications SIRF PRIMA 600MHz + 300MHz Memory Mobile DDR 256 MB 1GB Nand Flash Memory expansion SD card socket Operating system Microsoft® Windows CE.NET 6.0 GPS chipset SiRF V5 64 channels GPS antenna Embedded type Battery Built-in Rechargeable Li-Polymer, 1,100mAh Up to 2h 30min Display 7”...
