Camos CN-782 Operating Instructions Manual

Widescreen
Hide thumbs
Table of Contents

Advertisement

Quick Links

CN-780 / CN-782
Operating Instructions

Advertisement

Table of Contents
loading

Related Manuals for Camos CN-782

Summary of Contents for Camos CN-782

  • Page 1 CN-780 / CN-782 Operating Instructions...
  • Page 2 Hints Produced by IMC CAMOS GmbH Copyright © 2007 IMC CAMOS GmbH Printed in Korea All rights reserved Subject to change without prior notice. All product names might be brands or registered trademarks. All rights reserved. Reprint, nor in extracts, is not permitted without our express...

  • Page 3: Table Of Contents

    Content Hints Content Caution Warning Components Controls First Steps Power on Stand-by Battery operation DC operation Installation (Quick) Installation (Advanced, optional) Launcher Menu Play Back of Video Files Play Back of Music Photo Album Play Back of an External A/V Source Connecting a Rear View Camera (Option) Compass Settings Volume and Brightness Power Settings Start Settings Factory Settings Calibration Time Zone Language System Information Specification...

  • Page 4: Caution

    Caution Warning PLEASE FOLLOW THE HINTS BELOW TO WITH RESPECT TO TRAFFIC SAFETY AND PROTECT YOUR HEALTH. LOCAL REGULATIONS YOU MAY NOT ACTI- VATE THIS DEVICE WHILE DRIVING. PLEASE PREPARE DEVICE BEFORE DRIVING. Do not open! Hazardous electrical parts inside! Do not change any settings or input data while driving. Please stop or ask a co-driver to do this. As driver you must focus on traffic.
  • Page 5 Components Please check, if your box is complete INSTRUCTION MANUAL Navigation System Navigation Device Manual 12V Power Cord Gosse Neck CL-9 Remote Control SD Card Navigation Software USB SD-Card Reader Multi Cable Stand CL- TMC Receiver (optional) Rear View Camera (optional) Illustrations might be symbolic.
  • Page 6 Controls Front View ① Touchscreen: Control of the complete system ② Vertical sensor buttons: Increase/reduce volume ③ Horizontal sensor buttons: Increase/reduce brightness ④ Charge of battery: Battery completely charged Battery is charging Side Views ① , mm input for Audio/Video ② , mm input for rear view camera ③...

  • Page 7: First Steps

    First Steps Power on Installation (Quick) Turn on the device on the backside (ON). There are different ways to install the unit in your vehicle. The easiest way is to use the goose neck with suc- tion cup and to power the unit with the spiral cable to the cigar jack.

  • Page 8: Launcher Menu

    Launcher Menu After booting the launcher menu will appear. From here you may start any available function. Navigation AV-IN The functionality of the navigation software is de- If an external A/V source or a rear view camera is scribed separately. Manuals are available on CD/ connected, please use this function for viewing.

  • Page 9: Play Back Of Video Files

    Play Back of Video Files ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑩ Exit: The Video Player enables you to play back mov- Return to main menu. ies on SD card. It is compatible to various formats/ codeces.

  • Page 10: Play Back Of Music

    Play Back of Music ⑩ ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ The Music Player enables you to play back music Select play back mode files on SD card. It is compatible to various formats/ Each title will be played once codeces.

  • Page 11: Photo Album

    Photo Album ⑦ ⑦ ① ② ③ ④ ⑤ ⑥ The electronic photo album is ideal for travelling or HINT visitng friends. Various file formats are supported. For the photo album the sensor buttons show a dif- ferent behaviour: Display Vertical sensor buttons: Album page back/forward (8 pictures) ①...

  • Page 12: Play Back Of An External A/V Source

    Play Back of an External A/V Source ⑥ ① ② ③ ④ ⑤ The AV-In function enables you to watch external sources, i.e. DVD-Player, SAT-Receiver, etc. HINT Display Compatible A/V cables are available in well sorted ① AV/RV shops. Select video input: AV AV-input RV Rear view camera input ②...

  • Page 13: Connecting A Rear View Camera (Option)

    Connecting a Rear View Camera (Option) ⑥ ① ② ③ ④ ⑤ The AV-In function can be used as full video rear view system, too HINT Functionality Connecting the red cable via a rocker switch to Please connect the optional multicable to the device +12V ACC, it can be activated as rear view system and a compatible rear view camera.

  • Page 14: Compass

    Compass ④ ① ② ③ This function shows current speed and altitude based on the GPS signal. Display ① Compass: Shows north direction ② Altimeter: Shows current altitude above sea level (Nor- mal Null) ③ Speedometer: Shows current velocity. ④ Exit: Return to main menu.

  • Page 15: Settings

    Settings In the settings menu you can adopt the system to your personal habit. Volume / Brightness Calibration Adjust brightness and volume. Adjust the touch screen. Power Setting Time Zone Optimize the system to get maximum power safe Set time zone and adjust date/time. results.
  • Page 16 Volume and Brightness ④ ① ② ③ Adjust basic volume and brightness. Display ① System Volume Use +/- for adjustment ② AV Volume Use +/- for adjustment ③ System Brightness Use +/- for adjustment ④ Exit: Return to main menu.
  • Page 17 Power Settings ④ ① ② ③ Optimize the system to your personal usage. HINT Display The battery lifetime depends on the usage of the ① Timer for sleep mode system, i.e. listening to pure music, watching video Activate/deactivate the timer that can be ad- or navigating.
  • Page 18 Start Settings ④ ① ② ③ Set up the start-up application of your device after a cold start. HINT Display This function is helpful if you often use ON/OFF ① Start with specific application switch on the back side to safe battery power. It has After switching-on (ON/OFF) the selected ap- no effect on the sleep mode, because the system plication will be started automatically:...
  • Page 19 Factory Settings ③ ① ② Reset the device to factory settings. HINT Display The navigation software is not affected by this. All ① Set Default values and settings will remain. All values will return to default values, this will require a re-boot of the system. ②...
  • Page 20 Calibration ② ① Please run the calibration, if you have the feeling that the touchscreen does not react exactly to your com- mands. HINT Display This procedure cannot be cancelled and must be ① Blue mark passed most accurately. Follow the instructions on the screen and touch the moving cross mark.
  • Page 21 Time Zone ④ ① ② ③ Select your time zone and/or adjust date and time. Activate/deactivate daylight saving option. HINT Display If time zone is correctly set, the internal clock will ① Time Zone automatically adjusted by the GPS signal. Normally Select your local time zone.
  • Page 22 Language ② ① Select you preferred language. This change requires a reboot. HINT Display The navigation software is not affected by this. All ① Language values and settings will remain. Language is to be You may select among those seven langu- changed within the navigation software itself.
  • Page 23 System Information ② ① This information is only needed for service and support. Display ① System informationen: Operating system and software version. ② Exit: Return to main menu.

  • Page 24: Specification

    Specification Processor Type Samsung ARM9 SC20A Clockrate 00 MHz Storage SDRAM 6 MB Flash ROM 6 MB Removable Memory 2GB SD Card Screen Type 7“ Touchscreen Resolution 80 x 2 Colours 1670 K GPS-Module Type SiRFstarIII™ External Antenna Optional TMC-Module Type External, optional Audio...
  • Page 25 Connection Scheme Camera CM-2 (optional) 12V+ for Camera RS-22 12V DC Multi Cable TMC-Module (optional) TIPP Connect the 12V+ wire for the camera via a switch. Thus you can enable permanent rear view by one touch. 12V+ Ignition 12V+ for Camera 12V+ Rear Gear...
  • Page 26 Notes...
  • Page 27 Notes...
  • Page 28 IMC Camos GmbH, Carl-Zeiss-Str. 7, 2296 Trittau Tel 01 / 808 - 0 info@imc-multimedia.com Version 01_20070626 Printed in Korea...
