Panasonic MJ-M171PWTQ Service Manual

Juicer / blender
Hide thumbs

Advertisement

Quick Links

SPECIFICATION
POWER SOURCE
POWER CONSUMED
ROTATION SPEED
SWITCH CONTROL
POWER CORD (U)
DIMENSIONS (H x W x D) JUICER
DIMENSIONS (H x W x D) BLENDER
NETT WEIGHT (kg) JUICER
NETT WEIGHT (kg) BLENDER
RATED CAPACITY BLENDER
RATED CAPACITY MILL
CONTAINER MATERIAL BLENDER
ATTACHMENT
HONG KONG & RUSIA : AC220V~240V, 50 - 60Hz
210-230W
JUICER : 12,000 - 13,100 rpm / BLENDER : 11,700 - 12700 rpm
JUICER : ON/OFF PUSH BUTTON TYPE / BLENDER : 2 SPEED PUSH BUTTON AND PULSE
RUSIA : 0.9m (WITH C2 PLUG)
MJ-M171PWSS
MJ-M171PWSD
MJ-M171PWTQ
HONG KONG : 0.9m (WITH S3 PLUG)
323 X 288 X 212 mm
382 X 288 X 171 mm
3.0Kg
3.4Kg
1,000ml
50g COFFEE BEAN
GLASS
CLEANING BRUSH
© 2010 Panasonic Manufacturing Malaysia Berhad
(6100-K). Unauthorized copying and distribution is a
violation of law.
Order Number: PMMA100101CE
Juicer / Blender
TAIWAN : 110V
145W
TAIWAN: 0.9m (WITH A2 PLUG)

Advertisement

loading

  Summary of Contents for Panasonic MJ-M171PWTQ

  • Page 1 NETT WEIGHT (kg) JUICER 3.0Kg NETT WEIGHT (kg) BLENDER 3.4Kg RATED CAPACITY BLENDER 1,000ml RATED CAPACITY MILL 50g COFFEE BEAN CONTAINER MATERIAL BLENDER GLASS ATTACHMENT CLEANING BRUSH © 2010 Panasonic Manufacturing Malaysia Berhad (6100-K). Unauthorized copying and distribution is a violation of law.
  • Page 2: Table Of Contents

    CONTENTS Page 1 PRECAUTIONS (Strictly follow these instructions) ................................... 2 SCHEMATIC DIAGRAM ................................................ 3 BASIC WIRING DIAGRAM ..........................................4 TROUBLESHOOTING GUIDE ........................................4.1 The Juicer, the Blender commons 4.1.1 SYMPTOM: Motor doesn’t rotate. 4.1.2 SYMPTOM: Motor “roars” but doesn’t rotate. (Turn the switch off immediately) 4.1.3 SYMPTOM: Motor overheats.
  • Page 3: Precautions (Strictly Follow These Instructions)

    1 PRECAUTIONS (Strictly follow these instructions.) 2 SCHEMATIC DIAGRAM 3 BASIC WIRING DIAGRAM...
  • Page 4: Troubleshooting Guide

    4 TROUBLESHOOTING GUIDE...
  • Page 6: Disassembly Instructions

    5 DISASSEMBLY INSTRUCTIONS Upper cap Stopper spring Upper cap screw...
  • Page 9: Parts Location

    6 PARTS LOCATION...
  • Page 10: Replacement Parts List

    REPLACEMENT PARTS LIST SAFETY REF. NO. PART NAME PART NO. REMARKS PART PLUNGER AJD08-129-W4 CONTAINER LID UNIT ASSY AJD93-142-H2 SPINNER COMPLETE AJ08QK5200 CONTAINER UNIT ASSY AJD98-142-W4 SPOUT COVER AJD07-1291W4 CONNECTOR INSULATION RUBBER AJF03-123 AJF02M1141 TOOTH LOCK WASHER AJJ03M1141 CONNECTOR COMPLETE AJ07QA0600 CLAMP B AJG04-1291W4...
  • Page 11: Small Standardized Metal Parts

    SMALL STANDARDIZED METAL PARTS SAFETY REF. NO. PART NAME PART NO. REMARKS PART TAPPING SCREW XTN4+16BFJ PAN HEAD TAPPING SCREW XTN4+20BFJ TAPPING SCREW XTN4+16BFJ HEXAGONAL NUT XNG5EFJ U-CLIP XUE6FP E-CLIP XUC7FJ TAPPING SCREW XTN4+16BFJ PACKING SPECIFICATIONS SAFETY REF. NO. PART NAME PART NO.
