Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 3
• To prevent scratching or damaging the pen display, replace your pen nibs regularly, and do not use felt nibs on the display. • For additional information about recycling programs for electronics please go to http://www.wacom.com/ewaste. DTH2242_DTK2241_QSG_E.indb 2 DTH2242_DTK2241_QSG_E.indb 2...
Page 4
Wacom's exacting quality standards. To ensure that you get the most out of your new Wacom product, please read this Quick Start Guide and browse the User's Manual. If you cannot fi nd the answers you need, please contact us.
Supplied accessories Power adapter Power cable USB cable VGA to DVI-I cable DVI-D to DVI-I cable Installation CD Pen holder Screw Pen tether Some accessories are not supplied with all models. See the User's Manual for information on replacing the pen nib. DTH2242_DTK2241_QSG_E.indb 2 DTH2242_DTK2241_QSG_E.indb 2 2012/11/21 14:47:17...
Page 6
Connecting the pen display 1 Turn off your computer. 2 Select the proper video cable for your computer. Connect to the DVI-I IN connector on the pen display, then to the video output connector on your computer. DTH2242_DTK2241_QSG_E.indb 3 DTH2242_DTK2241_QSG_E.indb 3 2012/11/21 14:47:18 2012/11/21 14:47:18...
Page 7
3 Connect the power adapter to the power connector on the pen display and to the power cable, then connect the power cable to an AC outlet. DTH2242_DTK2241_QSG_E.indb 4 DTH2242_DTK2241_QSG_E.indb 4 2012/11/21 14:47:18 2012/11/21 14:47:18...
Page 8
4 Connect the USB cable to the USB connector on the pen display and a USB connector on your computer. 5 Turn on the pen display. The power LED will light orange. When a video signal is detected, the LED turns blue. 6 Turn on your computer.
1 Insert the installation CD of the pen display. If the software installer menu is not automatically displayed, double- click on the Install icon located on the CD. If your computer does not have a CD/DVD drive, download the software of the pen display from www.wacom.com. 2 Click Install Tablet and follow the prompts.
You may want to re-calibrate whenever you signifi cantly change your working position or viewing angle. 1 Open the Wacom Tablet control panel. See page 12 for information on the Wacom Tablet control panel. 2 Click the Calibrate tab. 3 Click Calibrate..
Page 11
Changing the angle of the pen display 1 Pull the stand adjustment lever, and move the display stand to your desired angle. 2 Release the lever to lock the stand in position. DTH2242_DTK2241_QSG_E.indb 8 DTH2242_DTK2241_QSG_E.indb 8 2012/11/21 14:47:18 2012/11/21 14:47:18...
Page 12
Adjusting the pen display to a horizontal position You can lay the pen display fl at on your work surface with the display stand closed. Attaching the pen holder Installation hole Installation hole Pen holder Screw You can turn the pen holder; however, do not turn it more than 180 degrees.
Page 13
Getting to know the pen display 1. Control panel button Pressing the button brings up the control panel. 2. OSD button Pressing this button switches the 5 ExpressKeys on the right to OSD buttons. 3. ExpressKeys • In ExpressKey mode, these buttons allow you to set various shortcut functions.
Page 14
8. Kensington lock 9. Pen storage compartment 10. Stand adjustment lever 11. Connection panel • Power connector • DVI-I out connector • DVI-I in connector • USB connector 12. Pen tether attachment point 13. Display stand 14. Installation hole for the pen holder DTH2242_DTK2241_QSG_E.indb 11 DTH2242_DTK2241_QSG_E.indb 11 2012/11/21 14:47:19...
Page 15
Customizing the pen display To open the Wacom Tablet control panel, press the Settings button (see page 10). A diagram of the current pen display settings appears on your screen. Click a setting to make changes using the Wacom Tablet control panel. You may also follow the procedures below: Windows 7/Vista/XP - Click Start >...
Page 17
설치 CD에 들어 있습니다.주의 사항, 제품 규격, 기타 중요한 정보가 들어 있습니다.사용하기 전에 중요한 제품 정보 이 정보를 잘 읽어보십시오. 펜 디스플레이의 긁힘이나 손상을 방지하려면 정기적으로 펜심을 교체하되, 펠트 펜심을 사용하지 마십시오. • 전자제품 재활용 프로그램에 대한 자세한 내용은 http://www.wacom.com/ewaste에서 확인하십시오. • DTH2242_DTK2241_QSG_E.indb 2 DTH2242_DTK2241_QSG_E.indb 2 2012/11/21 14:47:19...
Page 18
신뢰해 주시는 점에 감사의 말씀을 드리고자 합니다.이 새로운 펜 디스플레이의 기능을 즐기실 수 있기를 바랍니다.이 제품은 귀하께서 더욱 효과적으로 작업하는데 도움을 제공할 수 있도록 설계되었으며, Wacom의 품질 표준을 정확하게 준수하여 제조되었습니다. 새로 출시된 Wacom 제품의 기능을 최대한 활용하려면 본 퀵 스타트 가이드와 사용자 설명서를 읽어 주시기 바랍니다.필요한 답변을 찾지 못 한 경우에는 저희에게 연락해 주십시오.
Page 19
제공되는 액세서리 전원 어댑터 전원 케이블 USB 케이블 VGA - DVI-I 연결 케이블 DVI-D - DVI-I 연결 케이블 설치 CD 펜 펜 홀더 나사 펜 연결끈 일부 액세서리는 모든 모델에 다 제공되지는 않습니다. 펜심 교체에 대한 내용은 사용자 설명서를 참조하십시오. DTH2242_DTK2241_QSG_E.indb 2 DTH2242_DTK2241_QSG_E.indb 2 2012/11/21 14:47:19...
Page 20
펜 디스플레이 연결 1 컴퓨터를 끕니다. 2 컴퓨터에 맞는 올바른 비디오 케이블을 선택합니다.펜 디스플레이의 DVI-I IN 커넥터에 케이블을 연결한 후 컴퓨터 의 비디오 출력 커넥터에 연결합니다. DTH2242_DTK2241_QSG_E.indb 3 DTH2242_DTK2241_QSG_E.indb 3 2012/11/21 14:47:19 2012/11/21 14:47:19...
Page 21
3 전원 어댑터를 펜 디스플레이의 전원 커넥터에 연결한 후 전원 케이블에 연결합니다.그 다음에 전원 케이블을 AC 콘센트에 연결합니다. DTH2242_DTK2241_QSG_E.indb 4 DTH2242_DTK2241_QSG_E.indb 4 2012/11/21 14:47:20 2012/11/21 14:47:20...
Page 22
4 USB 케이블을 펜 디스플레이의 USB 커넥터와 컴퓨터의 USB 커넥터에 연결합니다. 5 펜 디스플레이를 켭니다.오렌지 색 전원 LED가 점등됩니다.비디오 신호가 탐지되면 LED가 파란색으로 바뀝니다. 6 컴퓨터를 켭니다. DTH2242_DTK2241_QSG_E.indb 5 DTH2242_DTK2241_QSG_E.indb 5 2012/11/21 14:47:20 2012/11/21 14:47:20...
Page 23
1 펜 디스플레이 설치 CD를 삽입합니다.소프트웨어 설치 프로그램 메뉴가 자동으로 표시되지 않으면 CD에 있는 설치 아이콘을 두 번 클릭합니다. 컴퓨터에 CD/DVD 드라이브가 없는 경우, 펜 디스플레이 소프트웨어를 www.wacom.com에서 다운로드하십시오. 2 타블렛 설치를 클릭한 후 화면의 지시 내용을 따릅니다. 대화에서 중요 제품정보 메뉴를 클릭해서 펜 디스플레이에 대한 중요 제품정보 설명을 확인하십시오.
Page 24
펜 디스플레이 보정 최적의 성능을 발휘하도록 하려면 펜 디스플레이를 보정해서 화면 커서를 디스플레이 화면의 펜 위치와 맞추어야 합니다.보 정 작업은 보기 각도를 보정하고 시각 변위를 조정하기 위해 필요합니다.펜 디스플레이의 위치를 작업하는 각도에 놓은 후 아 래의 보정 절차를 따르십시오. 작업 위치나 보기 각도가 크게 달라질 때마다 다시 보정할 수 있습니다. 1 와콤...
Page 25
펜 디스플레이 각도 변경 1 받침대 조절 레버를 밀어서 디스플레이 스탠드를 원하는 각도에 맞춥니다. 2 받침대를 원하는 위치에 고정시키려면 레버를 놓습니다. DTH2242_DTK2241_QSG_E.indb 8 DTH2242_DTK2241_QSG_E.indb 8 2012/11/21 14:47:20 2012/11/21 14:47:20...
Page 26
펜 디스플레이 수평 위치 조정 디스플레이 받침대를 닫아서 펜 디스플레이를 작업 표면에 밀착시킬 수 있습니다. 펜 홀더 장착 장착 구멍 장착 구멍 펜 펜 홀더 나사 펜 홀더는 돌릴 수 있으나 180도 이상 돌리지 마십시오. DTH2242_DTK2241_QSG_E.indb 9 DTH2242_DTK2241_QSG_E.indb 9 2012/11/21 14:47:20 2012/11/21 14:47:20...
Page 27
펜 디스플레이 소개 1. 제어판 버튼 이 버튼을 누르면 제어판이 나타납니다. 2. OSD(화면조정) 버튼 이 버튼을 누르면 오른쪽에 있는 5개의 익스프레스 키가 OSD 버튼으로 전환됩니다. 3. 익스프레스키 익스프레스키 모드에서는 이 버튼들로 다양한 바 • 로가기 기능을 설정할 수 있습니다. OSD 모드에서는 이 버튼들로 다양한 디스플레이 •...
Page 28
8. 보안 슬롯 9. 펜 보관용 칸 10. 받침대 조정 레버 11. 연결 패널 전원 커넥터 • DVI-I 출력 커넥터 • DVI-I 입력 커넥터 • USB 커넥터 • 12.펜 연결끈 부착 위치 13. 디스플레이 받침대 14.펜 홀더 장착 구멍 DTH2242_DTK2241_QSG_E.indb 11 DTH2242_DTK2241_QSG_E.indb 11 2012/11/21 14:47:20 2012/11/21 14:47:20...
Page 29
멀티-터치 기능은 DTH-2242로만 이용할 수 있습니다. 멀티-터치 기능으로 펜 디스플레이 화면에서 손가락만으로 컴퓨터와 상호 작용할 수 있습니다.펜 디스플레이로 터치를 이용 하는 방법은 사용자 설명서를 참조하십시오.또한 www.wacom.com에서 와콤 제스처 가이드도 다운로드할 수 있습니다. 펜 디스플레이 등록 및 추가 혜택 이용 드라이버를 설치할 때 펜 디스플레이를 등록할 수 있습니다.일부 지역의 경우 추가 혜택을 이용하려면 펜 디스플레이를 반...
