KNOB/BUTTON
PWR/VOL
SQUELCH
DISTRESS
CH16
MENU
MENU
More than 1 s.
DUAL
DUAL
More than 1 s.
ESC/F
CH/WX
HL/ENT
ESC/F
CH/WX
HL/ENT
STR-6000D SUMMARY
Power On/Off/Speaker Volume Control
SQUELCH Control
Pressing and holding down this button for 3s will allow users
to input the own ship ID in order to transmit the distress call.
(※ Trial transmission is strictly forbidden !! )
This converses to the current channel and Channel 16.
This moves to DSC MENU (Refer to Page. 45)
This moves to each setup MENU.(Refer to Page. 29)
This works on reception, conversing to the current channel
and Channel 16.
This starts scanning onto the current SCAN mode.
(Press again to stop)
This operates as Escape in MENU but as Function button in
the others.
This converses to weather channel.
At normal time, this alternates 25W and 1W in power output.
In MENU, this is used as Enter (Select items and Input
confirmation).
This is used to move CHANNEL and to move items in
MENU.
(Short pressing – 1 time, Long pressing – continuous
operation).
This changes the SCAN kinds.(ALL, TAG)
This leads only to TAG-designated channels.
This is for changes between nations. (ITU, USA, CAN)
In scanning, scan the tag-designated channel .This is for
setup and cancellation of TAG
FUNCTIONS
2
