IPM balancedpower plus Installation And Operation Manual

10-300 kva
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTALLATION
OPERATION MANUAL
International Power Machines
BalancedPower Plus
Uninterruptible Power System
SAVE THESE IMPORTANT

SAFETY INSTRUCTIONS

This manual contains important safety instructions
that should be followed during installation and
maintenance of the UPS and Battery Cabinets.
Service Hotline (800) 777-8922
and
for
10-300 kVA
(UPS)
International Power Machines
10451 Brockwood Road
Dallas, Texas 75238-1641
Phone: (214) 342-6100
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the balancedpower plus and is the answer not in the manual?

Questions and answers

Related Manuals for IPM balancedpower plus

Summary of Contents for IPM balancedpower plus

  • Page 1: Safety Instructions

    INSTALLATION OPERATION MANUAL International Power Machines ® BalancedPower Plus 10-300 kVA Uninterruptible Power System (UPS) SAVE THESE IMPORTANT SAFETY INSTRUCTIONS This manual contains important safety instructions that should be followed during installation and maintenance of the UPS and Battery Cabinets.
  • Page 2 Fax: (214) 342-6115 When calling for service assistance, have the following information and a record of readings and alarm lights from the machine’s monitor panel available for the IPM service dispatcher: Serial Number: (On label inside machine’s front door.) Input...

  • Page 3: Important Notice

    Important Notice manufacturer recommends that monitor panel be inspected visually every eight-hour shift to see that lights are operat- ing and no alarm conditions exist. If any unusual conditions exist, call facility mainte- nance personnel IPM/LorTec Service Hotline: (800/777-8922)

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Section I Theory of Operation General ....................Page 1.1 Rectifier/Charger ..................1.1 Inverter......................1.2 Static Bypass Switch..................1.2 Batteries ......................1.2 Control Logic and Control Circuitry ............1.3 Digital Monitoring Panel................1.3 Multi-Level Passwords ................1.4 Phone Home Alarm Reporting ..............1.5 1.10 Dial-Back Security..................1.5 Section II Installation 2.1 General....................
  • Page 5 Table of Contents Section III Operation 3.1 General....................Page 3.1 3.2 Safety Considerations ..................3.1 3.2.1 Cleanliness ....................3.1 3.2.2 Fire......................3.1 3.2.3 Security/Personnel ..................3.2 3.3 Radio Frequency Energy Hazard ..............3.2 3.4 Digital Monitoring Panel .................3.3 Figure 3.1 Digital Monitoring Panel ..............3.3 3.4.1 Indicator Lights ..................3.4 3.4.2 Message Screens..................3.5 3.4.3 Display Select Pushbuttons................3.9 3.4.4 Parameter Adjust Pushbuttons ..............3.9...
  • Page 6 Table of Contents Section IV, Maintenance (continued) 4.4.2 Status/Alarm Indicators ................4.4 4.5 Fuses ......................4.5 4.6 Battery Maintenance..................4.5 4.6.1 Safety Precautions ................4.5 4.6.2 Maintenance Shutdown of Battery Pack ..........4.6 4.6.3 Inspection and Periodic Maintenance........... 4.7 4.6.4 Battery Test..................4.8 4.6.5 Battery Replacement ................

  • Page 7: How To Use This Manual

    HOW TO USE THIS MANUAL A proper understanding and use of this operating and maintenance manual will enhance UPS system reliability. Therefore, the manual should be given equal status with the tools and equipment used to align and maintain the system. Conversely, improper understanding or application of the principles set forth can result in impaired system operation, loss of power to critical equipment loads, injury to personnel and/or damage to the UPS.
  • Page 8 Damage Documentation It is the responsibility of the recipient to file claim with the carrier for damages to the equipment or notify IPM, depending on the f.o.b. point. Any and all damage noted upon receipt of the UPS, battery pack and/or PDU should be clearly identified in detail on the Bill of Lading.
  • Page 9 3-phase UPS Warranty Page vi BP+15-150,2.9X 5/95...
  • Page 10 Purchaser shall not operate the system outside the specifications as stated in the system manual, and shall follow all operating instructions therein. Any necessary repairs made during the period of this warranty shall be made by IPM or by others with IPM’s written concurrence.

  • Page 11: Rectifier/Charger

    SECTION I Theory of Operation 1.1 General The BalancedPower Plus® (BP+) Uninterruptible Power System (UPS) presented in this manual is a solid state, on-line system designed to provide high quality, continuously filtered and conditioned ac power to computers, their peripherals and/or other critical equipment loads. Most commonly, the UPS is configured as a single, stand-alone unit.

  • Page 12: Inverter

    SECTION I Theory of Operation Inverter The inverter changes dc voltage to precision ac voltage through pulse width modulation (PWM) inversion. Output isolation transformers and an output filter provide “clean”, computer grade ac which is then sent to the critical load. When utility power is available, the rectifier supplies power to the inverter.

  • Page 13: Control Logic And Control Circuitry

    SECTION I Theory of Operation 1.5 Batteries (continued) The rectifier/charger normally provides a maintaining or “float” charge to the batteries. Following periods of discharge when the batteries have supplied power to the inverter, the rectifier/charger increases power to the batteries in order to recharge them.

  • Page 14: Multi-Level Passwords

    SECTION I Theory of Operation 1.8 Multi-Level Passwords A password is required to access and make use of the UPS Maintenance Menu, described in Section 3.6.3. This menu, with five subsections, makes possible the performance of a variety of maintenance functions including transfer and retransfer to bypass, password changes and adjustment of time and date.

  • Page 15: Phone Home Alarm Reporting

    1.9 Phone Home Alarm Reporting When this UPS is activated for phone home operation and the UPS senses one of several pre-selected alarm conditions, the UPS automatically dials IPM’s Field Service computer without human assistance and notifies IPM’s Field Service personnel of a system problem requiring attention.

  • Page 16: Theory Of Operation

    SECTION I Theory of Operation 1.10 Dial-Back Security (continued) controls. In this way high level security is provided since the remote operator must know the dial-back and access passwords and be calling from the proper associated phone number. An internal modem and a dedicated telephone line are required. Dial-Back Security can be activated only with a Field Service level of password.

  • Page 17: Mechanical Preparation Of Ups

    SECTION II Installation 2.1 General Your International Power Machines BalancedPower Plus UPS is UL-listed and designed for installation on the computer room floor. Its attractive computer- like appearance and quiet operation eliminate any necessity of creating special facilities to house the UPS and its battery component. Since all modern computer rooms utilize environmentally controlled conditions, installation in such a locale will normally suffice to meet the needs of the UPS.
  • Page 18 Tighten locking nut to keep it there. If an IPM battery pack is to be attached to the left side of the UPS, perform this sequence. If the battery cabinet is not to be attached to the left side of the UPS, skip Step 6.
  • Page 19 SECTION II Installation 2.2 Mechanical Preparation of UPS (continued) DO NOT REMOVE RED GLASTIC GUARD PANEL FROM LEFT SIDE OF UPS. Page 2.3 BP+10-150 12/95...
  • Page 20 Tighten locking nut to keep it there. 2. If an IPM battery cabinet is to be attached to the left side of the UPS, remove the fiberboard shipping panels from the left side of the UPS and the right side of the battery cabinet by forcing out the fasteners.

  • Page 21: Signal Wiring

    SECTION II Installation Mechanical Preparation of the Battery Cabinets (continued) If Battery Cabinet #1 is to be fastened to the left side of the UPS, place it adjacent to the UPS, but don’t bolt them together. If additional battery cabinets are to be fastened together to the left of Cabinet #1, place them adjacent to #1 and each other, but don’t bolt them together.

  • Page 22: Optional Remote Status Panel (Tb2)

    SECTION II Installation 2.4 Signal Wiring (continued) (TB1) 2.4.1 Remote Control (continued) Battery Trip and Position 24 Vdc UVR control for battery disconnect, 0.6 amp max. Contact indicates position of battery disconnect. Remote On-Generator Condition Isolated contact closure signals — UPS logic that a generator is supplying UPS input power.

  • Page 23: Optional Site Interface Assembly (A26)

    SECTION II Installation 2.4 Signal Wiring (continued) 2.4.5 Optional Site Interface Assembly (A26) This board mounts on top of the Customer Interface Board. The following connections are available from this interface: Computer Shutdown Interface (AS400) 9 pin D-sub plug. System 38 BNC connector (jack). 12 sets of NO and NC contacts are provided for monitoring UPS status and alarm conditions.

  • Page 24: Connecting The Cabinets

    SECTION II Installation 2.6 Connecting the Cabinets 1. If Battery Cabinet #1 is to be attached to the left side of the UPS, fasten the two cabinets together using the four (4) 5/16” x 1” bolts, nuts and washers packed with the leveling feet (see Figure 2-2).

  • Page 25: Ac Power Connection

    SECTION II Installation 2.8 AC Power Connection Make sure that all circuit breakers and the battery DC disconnect are open. Solderless compression type lugs are provided for cable connections. All power connections to the UPS terminal blocks must be torqued in accordance with the table below.
  • Page 26 UPS ground terminal. The neutral must be grounded and the UPS can only supply power to 3-phase, 3-wire loads. No single-phase loads can be connected to the UPS. For any other configurations consult IPM Application Engineering.

  • Page 27: Activating The Battery Cabinet(S)

    SECTION II Installation 2.8 Power Connections (continued) Bypass Input Voltage Configuration (Dual Input UPS) Bypass input voltage configuration must be the same voltage, frequency, phase sequence and configuration as the UPS ac voltage configuration, i.e., 3- phase, 4-wire plus ground. The UPS output can feed WYE (4-wire) loads or DELTA (3-wire) loads: WYE systems require neutral connections for both bypass input and UPS output;...

  • Page 28: Battery Cabinet #1

    SECTION II Installation 2.9 Activating the Battery Cabinet(s) (continued) • Make sure that all packing material and shipping straps have been removed from the battery cabinets. • Make sure that the electrical signal and power connections have been made between Battery Cabinet #1 and any additional cabinets. •...

  • Page 29: Battery Cabinet #2

    SECTION II Installation 2.9 Activating the Battery Cabinet(s) (continued) 2.9.1 Battery Cabinet #1 (continued) 6. Using a dc voltmeter, carefully measure the dc voltage at the top of the battery disconnect circuit breaker. The voltage should be slightly above the nominal battery voltage (for example: 380 volts dc for a nominal 360 volt battery cabinet;...

  • Page 30: Battery Cabinets #3 And #4

    SECTION II Installation 2.9 Activating the Battery Cabinet(s) (continued) 2.9.3 Battery Cabinets #3 and #4 11. Repeat Steps 8, 9 and 10 for the additional battery cabinet(s). 2.9.4 Final Battery Cabinet Connections 12. When connections and polarity have been checked on each additional battery cabinet, verify that there is one connection left unplugged in each cabinet (Steps 7 and 10).
  • Page 31 SECTION II Installation 2.9 Activating the Battery Cabinet(s) (continued) 6 battery trays Figure 2-3 10 battery trays Page 2.15 BP+10-150 12/95...

  • Page 32: Safety Considerations

    SECTION III Operation 3.1 General This section contains safety considerations, UPS operational procedures, and an overview of the monitoring panel and operating controls for the system. Prior to operation, ensure that the UPS has been installed correctly as outlined in Section II of this manual.

  • Page 33: Security/Personnel

    SECTION III Operation 3.2 Safety Considerations (continued) 3.2.3 Security/Personnel Access to the UPS should be limited to a minimum of personnel. Module doors should be kept locked. All personnel who operate or maintain the UPS should be proficient in normal and emergency operational procedures. A refresher briefing or test at specific intervals is recommended to maintain this proficiency.

  • Page 34: Digital Monitoring Panel

    SECTION III Operation 3.4 Digital Monitoring Panel The Digital Alarm Panel consists of eight (8) LED Indicator Lights, one (1) LCD message screen, two Display Select pushbuttons, three (3) Parameter Adjust pushbuttons, an ALARM SILENCE pushbutton and an EMERGENCY POWER OFF (EPO) pushbutton.

  • Page 35: Indicator Lights

    SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.1 Indicator Lights The Indicator Lights (LED’s), located in the upper part of the panel, are: • UPS Normal (green) - This indicates that the critical load is being powered from the inverter. The LED normally is on and, when this is the only LED lighted on the panel, it represents a fully normal condition.

  • Page 36: Message Screens

    SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.1 Indicator Lights (continued) This condition may occur when the UPS is loaded close to 100% and a large disk drive or other motor load is started. These loads draw currents many times their normal level for a few seconds when first started.
  • Page 37 SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.2 Message Screens (continued) If the UPS is operating on battery power, this screen will appear instead. It can be Time Left monitored to determine the battery run time hhH mmM ssS remaining during a power outage.
  • Page 38 SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.2 Message Screens (continued) 3.4.2.3 Input Current: Input Van This is a readout of the input current, Input Vbn measured in amps per phase. Input Vcn 3.4.2.4 Bypass Voltage Bypass Vab This is a readout of the bypass voltage between Bypass Vbc phases.
  • Page 39 SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.2 Message Screens (continued) 3.4.2.7 Output Power Output KW A readout of the output kVA, kW and Output KVA power factor. Output PF 3.4.2.8 Output Voltage: Output Van A readout of output voltage phase to Output Vbn neutral.

  • Page 40: Display Select Pushbuttons

    SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.2 Message Screens (continued) The next message is “UPS Operating Normally.” 3.4.2.13 Other Messages Under certain conditions other messages may appear on the message screens. 3.4.3 Display Select Pushbuttons pushbuttons are used to select the desired display on the Message Screen, as described in Paragraph 3.4.2.

  • Page 41: Emergency Power Off Pushbutton

    SECTION III Operation 3.4 Digital Monitoring Panel (continued) 3.4.6 Emergency Power Off Pushbutton To be used only for emergency conditions where instant shutdown of the UPS is required. The red EPO pushbutton is normally illuminated so that it may be located easily, even in the dark. Depressing the EMERGENCY POWER OFF (EPO) pushbutton results in immediate shutdown of operations, opening all UPS breakers and the DC (battery) disconnect, the audible alarm sounds and all power to the critical load is shut off.

  • Page 42: Ups Operating Procedures

    SECTION III Operation 3.5 System Controls (continued) BYPASS CIRCUIT BREAKER: Used primarily for maintenance purposes. When closed, it enables the UPS to be de-energized for maintenance procedures while continuing to supply power to the critical load. STATIC SWITCH BYPASS CIRCUIT BREAKER: (On dual input units only.) When closed, allows reserve input to supply power to the Static Switch.
  • Page 43 SECTION III Operation UPS Operating Procedures (continued) 3.6.1 System Startup Procedure (continued) Normally, turning on the UPS CONTROL switch should illuminate the following LED’s: AC Input Failure Transfer Not Available Retransfer Inhibited Battery Not Available Checksum Good … and this screen which will be displayed for a short time, .
  • Page 44 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.1 System Startup Procedure (continued) Waiting 4..This screen will appear for a short DC Link = time, then -- XXX.X VDC When this instruction appears on the Close Message Screen, close the DC (Battery) Dis- BATTERY connect switch.

  • Page 45: Alarm Identity/History

    SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.1System Startup Procedure (continued) Wait 8. This screen will show for a short time. Retransfer Pending 9. Then this screen will appear, indicat- ing that the UPS is now in normal operation. Operating Normally 3.6.2 Alarm Identity/History...

  • Page 46: Table 3-1, Typical Alarm History Screens

    SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.2 Alarm Identity/History (continued) The principal use of the Alarm History screen is to identify the source of audible alarms so that corrective action can be taken. When the audible alarm sounds, press until this Alarm History screen appears.
  • Page 47 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.2 Alarm Identity/History (continued) Table 3-2 Screen Message Description Corrective Action inp bkr open Input Circuit Breaker open Follow System Startup procedure to close Input Circ. Brkr. inp bkr clsd* Input Circuit Breaker closed Verifies that Input Circuit Brkr.
  • Page 48 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action dc volt norm* DC (battery) voltage normal No action required rct fus norm* Rectifier fuses normal No action required rct bin fusA Rectifier fuse A blown Test/replace rectifier fuses on Al power assembly.
  • Page 49 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action inv bIn fusB Inverter fuse B blown Test/replace inverter fuses on A2 power assembly. inv bIn fusC Inverter fuse C blown Test/replace inverter fuses on A3 power assembly. inv PS fail Power supply failure Test/replace inverter drive boards on A1, A2and A3 power assemblies.
  • Page 50 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action maint by fIt Maintenance bypass fault Maintenance bypass breaker is closed with inverter operating. Follow Startup procedure to open bypass breaker. dc hi shtdn’ Rectifier shutdown due to dc Verify that rectifier automatically output overvoltage restarts...
  • Page 51 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action out cur high Output current high Reduce load on the UPS out cur norm* Output current normal No action required out bkr open UPS Output Circuit Breaker Follow Startup procedure to close (Switch) open out bkr clsd* UPS Output Circuit...
  • Page 52 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action ups amb shdn UPS ambient temp. shutdown Room is too hot. Lower temperature. byp volt hi Static Bypass Switch by-pass Verify SBS input voltage. Decrease if voltage high necessary. byp volt low Static Bypass Switch by-pass Verify SBS input voltage.
  • Page 53 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action sbs inhibit Static Bypass Switch inhibited Review other SBS alarms for cause sbs normal* Static Bypass Switch normal No action required ups summary UPS summary alarm Review all alarms for cause ups inhibit UPS inhibited Review all alarms for cause...
  • Page 54 SECTION III Operation Table 3.2 (continued) Screen Message Description Corrective Action PS inp normal* Power supply input normal No action required bat vlt nrml* Battery voltage normal No action required sbs scr normal* Static bypass switch ----normal No action required rct on util* Rectifier served by utility power No action required...
  • Page 55 SECTION III Operation Screen Message Description Corrective Action ph fail* Phone home connection attempt failed No action required ‘ out overload The load on the UPS has Reduce the load exceeded 100% load normal* The load on the UPS is < or = 100% No action required bln trap fuse The input trap fuse has blown...

  • Page 56: Ups Maintenance Menu

    SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu Maintenance Menu performs a variety of maintenance functions including password changes and adjustment of date and time. It is divided into the following secondary menus in the order stated. The detailed instructions for each are given on the following subparagraphs.
  • Page 57 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 4. Now depress to activate the second Enter Password digit. Press until the “F” shows, like this: Enter Password 5. Depress to activate the third digit. The screen will show: Enter Password 6.
  • Page 58 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.1 Rectifier Maintenance Menu (continued) 2. This message will appear on the Confirm screen. To confirm the previous action, press again, Yes =UP No=DN Reset Rect Faults - returning the screen to –...
  • Page 59 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.2 Inverter Maintenance Menu (continued) 2 Press to obtain this screen. The Output CF A B C crest factors shown here are for information XX.X XX.X XX.X only.

  • Page 60: Bypass/Shutdown Procedure

    SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.2 Inverter Maintenance Menu (continued) 8. Press to return to the Inverter Inverter Maintenance Menu. Maintenance Menu 3.6.3.3 SBS Maintenance Menu 1. Press to advance to the SBS Maintenance Menu.
  • Page 61 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.3 SBS Maintenance Menu (continued) 5. When this message appears, open the Open OUTPUT SWITCH or CIRCUIT BREAKER. [On Output single-input UPS, when the input voltage does Breaker not equal the output voltage, place the rotary switch in “maintenance”...

  • Page 62: Manual Transfer To Bypass

    SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.3 SBS Maintenance Menu (continued) 10. This message indicates that the Bypass/ Maintenance Bypass Shutdown procedure is Shutdown complete. Complete 11. You may turn off the UPS CONTROL You may switch.
  • Page 63 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.3 SBS Maintenance Menu (continued) 15. If it is desired to manually retransfer Man Transfer to primary UPS input, press and wait 10 /Retransfer seconds for this screen to appear. This will turn Inv Running off all the LED’s except UPS Normal.
  • Page 64 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4 System Maintenance Menu (continued) 2. Press to obtain this screen. The Software Rev. “X.XX” represents the latest software release Level number. X.XX 60 Hz 3. Pressing the key will obtain this LED/Lamp screen.
  • Page 65 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4 System Maintenance Menu (continued) 7. Press to obtain this message in the Confirm language displayed in Step 6. The message screens will now all be in that language. Press Yes=UP No=DN to confirm that this is the desired language.
  • Page 66 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4 System Maintenance Menu (continued) 13. Press . The screen will ask you to Confirm confirm that you want to reset the time. If you do not wish to reset the time, press . Yes=UP No=DN 14.
  • Page 67 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4 System Maintenance Menu (continued) Save 19. Pressing will return to this Personality screen. UP=Save 3.6.3.4.1 Alarm Configuration Menu Alarm 20. Press to obtain this screen, Configuration beginning the Alarm Configuration Menu.
  • Page 68 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.2 Latching Alarms Menu (continued) 25. If you press after step 23, you will Set all alarms latching obtain this screen. Pressing will ask you to confirm that you wish to clear all latched UP = Yes alarms.
  • Page 69 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.2 Latching Alarms Menu (continued) 32. Press to go to the following screen. UPS Overload Latching 33. Press to proceed. Return to Previous Menu 3.6.3.4.3 Communications Menu Communications 34.
  • Page 70 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.3 Communications Menu (continued) NOTE 2: COM1 and COM2 in some of the following displays will apply only to an optional modem or RS232 customer interface described fully in Section VII.
  • Page 71 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.3 Communications Menu (continued) 40. Pressing ^ will select the desired Save Changes? baud rate and will bring back the previous COM1 screen. Yes = UP No = DN 41.
  • Page 72 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.3 Communications Menu (continued) 45. Pressing will select the desired Save Changes? program and will bring back the previous COM2 screen. Yes = UP No = DN 46.
  • Page 73 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.4 UPS Identification Menu (continued) 51. Press and this confirmation screen Confirm will appear asking whether you want to enter a name. Yes = UP No = DN Enter Name 52.
  • Page 74 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.4 UPS Identification Menu (continued) 57. Press again if you do wish to enter Enter unit ID: a unit identification. This screen will appear: Notice the blinking cursor at the bottom line. Pressing will change the character under the cursor (originally a space).
  • Page 75 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.4 UPS Identification Menu (continued) Notice the blinking cursor at the bottom line. Pressing will change the character under the cursor (originally a space). You can move through the available characters faster by holding down the ALARM SILENCE button while pressing .
  • Page 76 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.4.4 UPS Identification Menu (continued) Notice the blinking cursor at the bottom line. Pressing will change the character under the cursor (originally a space). You can move through the available characters faster by holding down the ALARM SILENCE button while pressing .
  • Page 77 SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.5 Password Maintenance Menu (continued) 2. Press to obtain this screen. There No Password are four (4) levels of passwords. Press as often Password as necessary to reach the desired level. The Menu number in the lower left will change, indicating the level attained.

  • Page 78: System Shutdown

    SECTION III Operation 3.6 UPS Operating Procedures (continued) 3.6.3 UPS Maintenance Menu (continued) 3.6.3.5 Password Maintenance Menu (continued) 8. Press to obtain this screen. Return to Previous Menu 9. Press to return to the Password Password Maintenance Menu. Maintenance Menu 10.

  • Page 79: Safety Precautions

    SECTION IV Maintenance 4.1 General Proper maintenance, both preventive and remedial, is the key to optimal operation of the UPS and will ensure a long and useflil life of the equipment. Preventive maintenance includes regularly performed procedures designed to prevent system malfunction and obtain maximum operational efficiency. Re- medial maintenance consists of troubleshooting the system in order to effect repairs.

  • Page 80: Preventive (Periodic) Maintenance

    SECTION IV Maintenance 4.2 Safety Precautions (continued) 3. Never wear metal jewelry such as rings or wrist watches when working on the UPS equipment. 4. Keep cabinet doors closed and secured during normal operation. 5. Never guess about safety procedures. If any doubt exists, ask someone who knows.

  • Page 81: Cable Connections

    4.4.1 General When properly installed, operated and maintained your International Power Machines BalancedPower Plus UPS will provide long, reliable power protection with little need of remedial or corrective maintenance actions. However, this section contains information as to problem isolation techniques and recommended actions to be taken so as to effect repairs on the UPS.

  • Page 82: Status/Alarm Indicators

    If such immediate action does not remedy the situation, contact the 1PM 24-Hour Hotline for assistance. In general the BalancedPower Plus UPS is designed so that the operator should not find it necessary to have access to any area of the equipment except the Digital Monitor Panel and the circuit breakers, switch and fuses inside the right- hand door.

  • Page 83: Fuses

    SECTION IV Maintenance 4.5 Fuses There are four (4) fuses adjacent to the UPS CONTROL switch inside the front door. If one of these fuses is blown, the control logic will not become energized at startup. Once the UPS is started, it will operate even though one or more of the fuses is blown.

  • Page 84: Maintenance Shutdown Of Battery Pack

    4.6.2 Maintenance Shutdown of Battery Pack This procedure is for shutting down the IPM battery pack. It does not require that the protected load be removed from the UPS. Perform the following steps in the order presented: 1. Verify that each UPS attached to the...

  • Page 85: Inspection And Periodic Maintenance

    SECTION IV Maintenance 4.6 Battery Maintenance (continued) 4.6.3 Inspection and Periodic Maintenance This procedure should be performed annually or whenever batteries need to be replaced. 1. Place the battery pack in Maintenance Shutdown condition (Para- graph 4.6.2). 2. Open the front doors of each battery pack and visually inspect the inside of the cabinet for: Leaking acid.

  • Page 86: Battery Test

    The procedure described is for individual batteries and requires the use of a Balkamp 700-112 Battery Tester or equivalent. The Balkamp unit is available at most NAPA auto parts stores or from IPM. The tester is rated for 100 amps, 12 vdc. It checks voltage under load.
  • Page 87 SECTION IV Maintenance 4.6 Battery Maintenance (continued) 4.6.4 Battery Test (continued) 3. Test each battery separately. 4. Using a digital voltmeter which can be read to 0.01 vdc, check the voltage across the posts of the batteries, one at a time. Record the voltage readings for each battery.

  • Page 88: Battery Replacement

    SECTION IV Maintenance 4.6 Battery Maintenance (continued) 4.6.5 Battery Replacement 1. Perform Maintenance Shutdown procedure (Paragraph 4.6.2). 2. Disconnect the desired battery tray, unbolt it from its slide and slide it out onto a lift hand truck. CAUTION battery tray weighs much 200 lbs (91 kg).

  • Page 89: Reactivating The Battery

    SECTION IV Maintenance 4.6 Battery Maintenance (continued) 4.6.6 Reactivating the Battery Pack (continued) 6 battery trays Figure 4-1 10 battery trays Figure 4-2 Polarity of Batteries in Tray Page 4.11 BP+2.9X 11/95...

  • Page 90: Battery Manufacturer's Torque Specifications

    SECTION IV Maintenance Battery Manufacturers' Torque Specifications Johnson Controls: Item Bolt Wrench Initial Annual Size Size Torque Retorque UPS 12-140FR 7/16 40 lb-in 30 lb-in UPS 12-170FR 7/16 40 lb-in 30 lb-in UPS 12-270FR 7/16 40 lb-in 30 lb-in UPS 12-310FR 7/16 65 lb-in 50 lb-in...
  • Page 91 International Power Machines can supply any of several recommended Spares Levels to meet differing requirements. The desired Mean-Time-To-Repair and the travel time from IPM's nearest Service Center would normally determine the approximate level of spares to be stocked. This section lists typical spare parts for a UPS of the size shown on the cover page of this manual.

  • Page 92: Continuing Maintenance

    5.2 Training To insure that our customers derive maximum benefit from their UPS and related equipment, IPM offers a variety of training classes tailored to specific interests and requirements. These courses include a one-day Operator Seminar, a Basic Maintenance class for facilities personnel and specialized training for unique equipment configurations.
  • Page 93 SECTION VI Glossary Alternating current (normally "AC"). AC POWER - AC input to the UPS. Also identified as "UPS Input." ALARM - An abnormal condition within the UPS. ALARM SIGNAL - A loud piercing electronic tone signaling an alarm condition. APPARENT POWER (kVA) - The product of voltage and current.
  • Page 94 SECTION VI Glossary EMERGENCY POWER OFF (EPO) - A means of cutting power from the UPS in emergency situations. The EPO switch is located on the Monitor Panel. EQUALIZE - See RECHARGE. FLOAT CHARGE - A dc voltage applied to a battery at a level which maintains the battery in a fully- charged state.
  • Page 95 SECTION VI Glossary REAL POWER (kW) - The portion of apparent power which actually performs work or generates heat. RECHARGE - A dc voltage applied to a battery for a given period of time which will equalize unevenly charged cells. After an emergency discharge, it will restore the batteries to full charge.
  • Page 96 SECTION VII Remote Video Terminal 7.1 General An optional remote video terminal, supplied by LorTec or by the customer, is plugged into the optional RS232 communication or telephone modem port. If this port was not purchased, this section does not apply to your UPS. The remote monitor is to be a video display terminal capable of emulating a VT100 or equivalent.

  • Page 97: Rs232 Interface

    SECTION VII Remote Video Terminal 7.2 RS232 Interface (continued) The lower segment shows the keyboard keys to be used to change the message screens (in place of the pushbuttons on the monitor panel). Briefly, the functions of these keys are as follows: Function [N]ext Scrolls data up the display area.

  • Page 98: Ups Maintenance Menu

    SECTION VII Remote Video Terminal 7.3 UPS Maintenance Menu The description given in Section 3.6.3 for the UPS Maintenance Menu applies equally to its use from a remote terminal. Make sure that "UPS Maintenance Menu" is in the upper left-hand area of the CRT screen. Then use the keys that correspond to the pushbuttons described in this manual.

  • Page 99: P-Record

    SECTION VII Remote Video Terminal 7.5 P-Record P-Record format is for users who need to query the UPS periodically for information as to its status or develop custom monitoring software. It is used also when the "phone home" capability is enabled. For additional information on the P-Record protocol, refer to document 950-010-A416, Revision C, UPS Remote Monitor Protocol.
